Argos IVY4109 ASSEMBLY INSTRUCTIONS

Assembly lnstructions - Please keep for future reference
Foley 3 Drawer TV Unit
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Important - Please read these instructions fully before starting assembly
Issue 1- 27-11-14
360/3679
Dimensions
Depth -
40
cm
Height -
40cm
Safety and Care Advice
Check you have all the components and tools listed on pages 2 and 3. Remove all fittings from the plastic bags and separate them into their groups. Keep children and animals away from the work area, small parts could choke if swallowed. Make sure you have enough space to layout the parts before starting.
Assemble the item as close to its final position (in the same
room) as possible.
Assemble on a soft level surface to avoid damaging the unit or your floor.
Assembly requires 2 people.
Do not fully tighten bolts until the whole bed is assembled. Do not overtihgten the nuts to avoid causing damage to the threads.
We do not recommend the use of power drill/drivers for
inserting screws,
as this could damage the unit. Only use hand screwdrivers and
Allen keys.
Dispose of all packaging carefully and responsibly.
1
Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
From time to time check that there are no loose screws on this unit.
This product should not be discarded with household waste. Take to your local authority waste disposal centre.
This product has been finished using natrual materials. As a living material, you may notice some variation in the grain and colour shade between the different components.
Unlike a synthetic or man-made material which has a uniform finish, a feature of natural wood is its variation in grain and colour. We wish to reassure you that this is quite normal and is not the result of any manufacturing fault.
Where sheets of wood are joined together, a line may be detected. Again, this is normal and is not an imperfection.
The natural finish should be cared for by the periodic application of a good quality 'was' based domestic furniture polish (Not silicone!!). Occasional / small spills should be removed immediately using a damp cloth.
Do not allow hot articles to come into contact with the surface, as damage will occur!
Components - Parts
2
lf you have damaged or missing components. call the Customer Helpline : 0345 6400 800
6
Shelf x 3 (38x37x1.5cm)
5
Divider x 2 (25x37x1.5cm)
4
Side panel(left) x 1 (25x40x1.5cm)
8
1
Top panel x 1 (120x40x1.5cm)
2
Base panel x 2 (120x40x7.5cm)
3
Side panel (right) x 2 (25x40x1.5cm)
7
Back Panel x 1 (118x25.8x0.3cm)
Drawer front (right) x 1 (38.2x13x1.5cm)
9
Drawer front (middle) x 1 (39.2x13x1.5cm)
10
Drawer front (left) x 1 (38.2x13x1.5cm)
11
Drawer side (right) x 3 (30x10x1.2cm)
12
Drawer side (left) x 3 (30x10x1.2cm)
13
Drawer back x 3 (33.4x10x1.2cm)
14
Drawer base x 3 (29.4x34.2x0.3cm)
15
Feet x 4 (3.8x3.8x12cm)
Underside Underside
Inside
Inside
Top
Bottom
3
12 x 10mm Locking nut x 12
0345 6400 800
B C
D E F
M4 x 16mm screw x 330mm Wood screw x 12
A
F
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Tools required
0
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150
1 2 3 4 5 6
Ruler/tape measure
Components - Fittings
G
Metal dowel x 40
15 X 20mm Locking nut x 28 M6 x 30mm Wooden dowel x 8
H
Drawer handle x 3
Phillips screwdriver (Not supplied)
Allen key x 1
M6 x 50mm Allen screw x 8
J
K L M
Spring washer x 8
Plain washer x 8 12mm screw x 24
14mm screw x 8
Plastic bracket x 8
PN
4
Preparing panels
Assembly Instructions
1
A
A
A
A
15
15
15
15
2
2
H
J
K
H
J
K
a: Carefully place base
panel upside down onto the floor.
Assemble legs to base
panel using fixings ,
and .
b: Turn-over base panel
flat onto the floor with the fixing holes facing up.
Repeat for top panel .
Screw metal dowels into both panels and
as shown.
Note: Screw metal dowels
as far as shown.
Do not overtighten.
2
15
2
H
J
K
2
1
a:
b:
A
2
A
1
2
15
5
Assembly Instructions
X2
5
5
3
4
A
A
A
A
3
6
5
B
Locate shelf onto right side panel and secure from the underside using locking nuts .
Assemble divider onto the other side of shelf and secure using locking nuts .
Assembling shelf
a: Place side panels
and flat on the floor.
Screw metal dowels into the side panels as
shown.
b: Screw metal dowels
into both sides of dividers
.
3
4
A
A
5
b:
a:
6
3
B
5
6
B
B
Preparing panels
Right
A
Turn over
6
Assembly Instructions
6
B
B
B
6
5
a: Repeat step 3
procedure to assemble middle shelf .
6
a:
b: Repeat to assemble
divider onto shelf as shown.
b:
5
c: Repeat again for the
last shelf .
c:
6
d: Repeat again to
assemble left side panel onto shelf .
4
4
d:
6
Right
Right
Right
Right
6
6
6
B
B
Left
1
7
B
B
B
C
C
Assembly Instructions
Assembling back panel
Insert wood dowels into the top edges of side panels and .
Locate top panel into position and secure using locking nuts in the location shown.
7
Assembling top
C
3
4
1
B
4
3
Ensuring the 3 cable access holes will be at the
top, carefully slide back panel into the grooves in side panels and .
7
3
4
4
3
B
Bottom
Top
2
B
B
B
B
C
A
A
A
E
E
8
9
10
8
14
E
Assembly Instructions
Assembling drawers
Insert wood dowels into the bottom edges of
side panels and .
Locate base panel into position and secure using locking nuts in
the locations shown.
8
Assembling base
a: Assemble left and right
drawer side panels and together with back panel using screws .
3
4
2
B
11
12
13
D
D
D
12
13
a:
b:
c:
b: Slide drawer base
into the grooves as
shown.
Repeat for all 3 drawers.
14
c: Place drawer fronts
and flat on the
floor.
Screw metal dowels into each drawer front as
shown.
Assemble drawer fronts to drawer bodies and secure using locking nuts .
8
9
10
A
E
C
B
3
4
C
E
A
9
10
11
Assembly Instructions
F
G
8
9
10
9
Fitting drawers
Assemble drawer handles
to drawer fronts ,
and using screws
.
Assembling drawer
handles
Important: Drawer fronts
, and are
different.
Take care to ensure they
are correctly located as
shown.
Engage the drawer runners and push gently inwards until they click into place.
G
F
8 9 10
8 9
10
8
9 10
Right side
Left
side
Assembly lnstructions
10
M
N
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW
Fit plastic brackets
around the edge of back
panel using screws .
M
7 N
N
M
7
