HOH CAMBRIA LARGE SIDEBOARD
Assembly Instructions - Please keep for future reference
321/1470
Dimensions
Width - 148cm
Depth - 45cm
Height - 95cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0845 6400800
Issue 2 - 28/10/14
!
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
Only clean using a damp cloth
and mild detergent, do not use
bleach or abrasive cleaners.
Do not stand or put weight on
this product during assembly,
this could cause damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
From time to time check that
there are no loose screws on
this unit.
•To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Handy Hints
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
1
• Regularly check and ensure
that all bolts and fittings are
tightend properly.
Note:if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
Components - Panels
Please check you have all the panels listed below
If you have damaged or missing components,
call the Customer Helpline: 0845 6400800
1
Large Sideboard (148x45x95 cm)
2
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
fittings may be supplied than are required.
A
Wall strap x 1
Tools required
0
Ruler/tape
150140130120110100908070605040302010
measure
B
Ø12x1mm Washer x 1
C
Ø3.5x15 mm Screw x 1
Philips screwdriver
(medium & large)
Ruler - Use this ruler to help correctly identify the screws
201005 15 25
35 45 55 65
60504030
70
75
The screws length is measured from the head to the point (30mm screw shown).
3
9080
85 95
130
105 115 125 135 145 155 165
120110100
170160150140
Assembly Instructions
Step 1
Fixing strap to wall.
It is recommended that
the unit is fixed to a wall.
Mark fixing hole on wall,
making sure there is
enough space to the left
and right of the wall strap
for the sideboard.
Fasten wall strap to the
wall using a suitable wall
screw/plug system.
Warning:
!
Before drilling,
check wall for
hidden pipes
and cables.
A
A
!
!
Note: The correct type of wall
screws must be used for your
wall. Please seek professional
advice if in doubt.
93 cm
C
Step 2
Fixing unit to wall.
With the help of another
person move the unit into
position.
Place the wall strap on the
top of the unit.
Fasten the wall strap to
the unit with screw and
washer .
B
C
B
A
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
