Argos HD-2371K, HD-2391K ASSEMBLY INSTRUCTIONS
Alderbury 5ft Bed
Assembly Instructions - Please keep for future reference 106/8649
106/9394
Dimensions
Width - 160.2cm
Depth - 212.3cm
Height - 116.5cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
Issue 1 - 09/04/10
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do not use
bleach or abrasive cleaners.
• As you unpack and prepare
for assembly, clear an area for
assembly. The parts should be
placed on a carpeted or padded
area to protect them from
damage.
• Parts of the assembly will be
easier with 2 or 3 people.
• Do not discard any of the
packaging until you have
checked that you have all the
parts and pack of fittings.
• From time to time check that
there are no loose screws on
this unit.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• To ensure an easier assembly,
we strongly advise that all
fittings are only finger tightened
druing initial assembly. Only
upon completion of the
assembly should all fixing points
be fully tightened.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
1
If you have damaged or missing components,
Components - Panels
call the Customer Helpline:
Please check you have all the panels listed below
0845 6400800
1
Headboard frame
(156.7 x 66cm)
Headboard post x 2
4
(Dia3.8 x 47.5cm)
Center support slat x 2
7
(86.7 x 1.8cm)
Footboard frame
2
(156.7 x 87.5cm)
Slat x 12
5
8
Leg x 4
(dia1.8 x 30.5cm)
(153.2 x 3.2cm)
Side rail x 2
3
Slat x 4
6
Finial x 4
9
(202.2 x 9cm)
(153.2 x 3.2cm)
(12.9 x 7.3cm)
2
