Argos HALLINGFORD PACKAGE ASSEMBLY INSTRUCTIONS
Assembly Instructions - Please keep for future reference
Issue 5 - 20/05/14
MADE IN
BRITAIN
If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928
or email: Help@ClickSpares.co.uk (quoting your original order number)
Important - Please read these instructions fully before starting assembly
Dimensions
Width - 37.5cm
Depth - 40cm
Height - 58cm
New Hallingford - 3 Drawer Bedside
274/4917
266/4509
258/7693
266/2910
266/7379
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 14kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: If there is any
chance of this unit being pulled
over by children etc. it is
recommended that the unit is
secured to a wall using suitable
fixings (not supplied).
• Dispose of all packaging
carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
2
Components - Panels
Please check you have all the panels listed below
If you have damaged or missing components, call the
Customer Helpline: 0870 112 1928 or email:
Help@ClickSpares.co.uk (quoting your original order number
and the reference numbers below)
1
Left Side (D2307A)
(556 x 372mm)
2
Right Side (D2308A)
(556 x 372mm)
3
4 5
86 7
9 10
Top (D2306A)
(375 x 396mm)
Back (X535-366)
(535 x 366mm)
Rail (D2310A)
(340 x 66mm) x 2
Drawer Front (D2309A)
(362 x 162mm) x 3
Drawer Base (T304-367)
(304 x 367mm) x 3
Drawer Back (W291-124)
(291 x 124mm) x 3
Left Drawer Side (W370-124LH)
(370 x 124mm) x 3
Right Drawer Side (W370-124RH)
(370 x 124mm) x 3
3
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Tools required
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 0870 112 1928 or email:
Help@ClickSpares.co.uk (quoting your original order number
and the reference numbers below)
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Electric drill
(do not use for
fitting screws)
B C
D E F
G H
Small locking
nut (F3) x 6
Nail (F51) x 12
13mm Screw (F52) x 18 13mm Screw (F63) x 18
I
A
Wooden dowel (F22) x 6
19mm Screw (F461) x 6
Metal dowel (F901) x 12
Large locking
nut (F900) x 6
Knock-in Peg (F171GY) x 12
K
R Runner (F160) x 3
b
L Runner (F161) x 3
K
c
L Runner (F159) x 3
K
a
R Runner (F162) x 3
K
d
350mm long
J
Handle (F278) x 3
M
Plastic Nail (F91) x 4
L
Wedgefix (F639) x 6
