Argos Elford - Entertainment Unit ASSEMBLY INSTRUCTIONS

Elford - Entertainment Unit

Assembly Instructions- Please keep for further reference

245/8911

246/6934

Dimensions

Width - 130cm
Depth - 41cm
Height - 53cm

Important – Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline:

Argos = 0345 6403030

BK02560 - Issue 1 - 29/05/2014

Safety and Care Advice

Important – Please read these instructions fully before starting assembly

• Check you have all the
components and tools listed on
pages 2 and 3.

• Remove all fittings from the
plastic bags and separate them
into their groups.

• Keep children and animals
away from the work area, small
parts could choke if swallowed.

• Make sure you have enough
space to layout the parts before
starting.

• Do not stand or put weight on
the product, this could cause
damage.

• Assemble the item as close
to its final position (in the same
room) as possible.

• Assemble on a soft level
surface to avoid damaging the
unit or your floor.

• Parts of the assembly will be
easier with 2 people.

• Due to difference in floor
levels, doors may not be
aligned. Adjustment may be
necessary.

• Do not use extended drawers
to aid standing. Do not stand on
extended drawers.

• Do not over load drawers,
the maximum load per drawer
should not exceed 3kg

• To prevent bowing of shelves
do not over load, and always
distribute weight evenly.

• If a residual aroma is
experienced with your new
furniture after the packaging
is removed simply ensure the
room is well ventilated and this
will assist a speedy removal

• We do not
recommend the
use of power
drill/drivers for

inserting screws,
as this could damage the unit.
Only use hand screwdrivers.

• Dispose of all packaging
carefully and responsibly.

• It is essential that this unit be
fixed to a wall with the fittings
provided.

• Please retain the product label
on the back of the unit, as this
information will help support any
queries.

Care and maintenance - Non compliance with this information may affect your guarantee

• Dust with a clean cloth or, if
required a slightly damp cool
cloth. Do not use household
cleaners, abrasives or polishes
as permanent damage may
occur.

• Do not drag the furniture or lift
it by its top.

• Avoid sharp objects, contact
with water and direct heat on all
surfaces

• Your furniture is finished to the
required colour. Avoid exposure
to strong sunlight as this can
change the colour. Change in
appearence may also occur if
items are permanently left on a
surface.

• You should get assistance
when moving or lifting your
furniture. Furniture consisting of
more than one unit should be
disassembled before attempting
to move it.

• Doors and drawers should
be secured or removed before
moving.

• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.

Handy Hints

• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the
bolts.

• Regularly check and ensure
that all boths and fittings are
tightened properly.

Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.

1

If you have damaged or missing components, call the

Components - Panels

Customer Helpline:

Please check you have all the panels listed below

Argos = 0345 6403030

Entertainment unit

1

(53 x 130 x 41cm)

2

Components - Fittings

Please check you have all the fi ttings listed below

Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings
may be supplied than are required.

A

B C

15mm Screw x 1 15mm Washer x 2

The following components are pre-fi tted and are illustrated for reference only.

Large bar handle x 2

20mm Handle screw x 4

Tools required

Phillips screwdriver
(medium)

Wall strap x 1

Ruler - Use this ruler to help correctly identify the screws

0 5 10 15 20 25 30 35 40 45 50

The screws length is measured from the head to the point (30mm screw shown) .

3

55 60

65 70 75 80

85 90 95 100

105

110 115 120 125 130 135 140 145 150

155 160

165 170
