Argos DAISY ASSEMBLY INSTRUCTIONS

Issue 2 - 16/06/14

Width - 96cm
Depth - 216cm
Height - 99.5cm

Important - Please read these instructions fully before starting assembly

258/5712

Daisy Sleigh Storage White Frame

Dimensions

Assembly Instructions - Please keep for future reference

If you need help or have damaged or missing parts, call the Customer Helpline:

Argos = 0345 640 0800

1

Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.

Important - Please read these instructions fully before starting assembly

!

Safety and Care Advice

IMPORTANT!
KEEP FOR
FUTURE
REFERENCE

Keep children and animals
away from the work area, small

parts could choke if swallowed.

To reduce the
likelihood of
damaging your
product please

ensure that your
power drill is set on a low torque
setting.

Remove all fittings from the
plastic bags and separate them
into their groups.

Check you have all the
components and tools listed on
the following pages.

Make sure you have enough
space to layout the parts before
starting.

Assemble the item as close
to its final position (in the same
room) as possible.

During assembly do not stand
or put weight on the product,
this could cause damage.

Improper use of electrical tools
will crack the components.

Assemble on a soft level
surface to avoid damaging the
unit or your floor.

Parts of the assembly will be
easier with 2 people.

Care and maintenance

This product should not be
discarded with household

waste. Take to your local
authority waste disposal centre.

From time to time check that
there are no loose screws on
this unit.

Only clean using a damp cloth
and mild detergent, do no use

bleach or abrasive cleaners.

Warnings

Place the bed tight to any

wall or have a gap of 300mm
between the wall and the side
of the bed.

Not suitable for children under

4 years.

Regularly check and ensure
that all bolts and fittings are
tightened properly.

The recommended mattress
size is L1900 x W900 mm.

This product should only be
used on firm, level ground.

Make sure the legs remain in
contact with the ground.

This product is intended for
children in the age of 4 to 13
years old.

Prohibit your children from
bouncing and jumping on the
bed.

Do not place this child's bed
near heat sources, windows
(blind cords, curtain pulls or
other strings or cords) and other
furniture.

THIS BED COMPLIES WITH

BS8509:2008+A1:2011

Retailer: Argos Ltd. MK9 2NW

Handy Hints

Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts.

Regularly check and
ensure that all bolts and
fittings are tightend
properly.

Do not use this child's bed if
any part is broken, torn or
missing.

Please check you have all the panels listed below

Components - Panels

2

If you have damaged or missing components, call the

Customer Helpline: Argos = 0345 640 0800

Headboard (92 x 74cm)

1

Footboard

(92 x 43cm)

2

Left headboard leg

(99.5 x 14cm)

3

Side x 2

(190 x 14cm)

7

Right headboard leg

(99.5 x 14cm)

4

Left footboard leg

(68.5 x 12cm)

5

Right footboard leg

(68.5 x 12cm)

6

Drawer front (188 x 15cm)

8

Drawer back

(185 x 10cm)

9

Left drawer side

(93 x 10cm)

10

Right drawer side

(93 x 10cm)

11

Drawer bottom x 3

(62 x 92.6cm)

13

Support bar x 2

(91.6 x 9cm)

12

Note: The quantities below are correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.

Please check you have all the fittings listed below

Components - Fittings

Tools required

A

B

70mm Screw x 8

Washer x 8

Nut x 8 40mm Dowel x 16

30mm Screw x 8

C

D

E

Allen key x 1

Spanner x 1

75mm Screw x 6

F

60mm Screw x 2

G

Barrel nut x 6

H

Drill

Eye protection
(when using a
hammer or glue)

Ruler/tape
measure

Small
hammer

Suitable drill bit
(for use with wall plug)

Flatblade screwdriver
(medium)

Philips screwdriver
(medium & large)

0

10

20

30

40

50

60

70

80

90

100 110 120 130

140

150

3

170

160

150

140

130

120

110

100

9080

70

60

50

40

30

20

10

0

5 15

25

35 45

55 65

75

85 95

105

115 125 135 145 155 165

Ruler - Use this ruler to help correctly identify the screws

The screws length is measured from the head to the point (30mm screw shown).

The bolts length is measured from inside of the head to the point
(60mm bolt shown).

I

J

Cam x 8

Locking pin x 8 30mm Dowel x 8

K

L

M

N

O

P

35mm Screw x 4 14mm Screw x 12 Caster x 6
