Chunky TV Unit
Assembly Instructions - Please keep for future reference
418/5897
Dimensions
Width - 120cm
Depth - 40cm
Height - 58cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400800
issue1 - 18/0 3/1 5
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Check you have all the
components and tools listed on
the following pages.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
●Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
During assembly do not stand
or put weight on the product,
this could cause damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
●From time to time check that
there are no loose screws on
this unit.
We do not
recommend the use
of power drill/ drivers
for inserting screws,
as this could damage
the unit. Only use hand
screwdrivers.
●This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Handy Hints
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
Regularly check and ensure
•
that all bolts and fittings are
tightend properly.
1
Components - Panels
Please check you have all the panels listed below
Top (120 x 40cm)
1
If you have damaged or missing components,
call the Customer Helpline:0345 6400800
Shelf (120 x 40cm) X 2
2
Through hole
2
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
Foot x 4
B
B
Post with short bolt x 4
C
Post with long bolt x 4
3
Assembly Instructions
Step 1
Step 1
Fitting the legs
Note: It would be useful to
ask someone to help you
at this stage.
a: Screw in the post with
short bolt into Top
panel .
B
1
b: Put the shelf panel
2
onto unit.
a:
B
B
B
B
B
B
1
C
B
b:
2
c: Fit Shelf onto the
2
unit, by screw in the post
with long bolt .
C
c:
B
B
C
C
B
2
B
2
B
4
Assembly Instructions
Step 1Step 1
d: Put the shelf panel
2
onto unit again.
d:
2
e: Screw in Foot into
Shelf panel .
A
2
e:
A
A
2
C
2
5
Assembly Instructions
Step 2
Finishing the unit
Turn the unit upright and
place in the desired
location.
Note: Before use always
make sure the unit is
secure.
Assembly is complete.
If you need help or have damaged or missing parts, call the
Customer Helpline : 0345 6400800
