Argos Bush Instruction Manual

Instruction manual

DVB-T2 PVR MPEG4

2

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

You’ll soon be enjoying your new set-top box.

It all begins here, with your instructions. Don’t worry,
there’s nothing too technical coming up. Just simple,
step-by-step guidance to get you up and running
quickly. Sound good? Then let’s get started.

Help and Guidance

We’re here to help you get the most from your set-top box. Should you require any
guidance, a simple solution can often be found online at:

www.argos-support.co.uk

If you still require further assistance, call one of our experts on 0345 604 0105

3

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Contents

Media Browser 34

Digital Teletext 36

Settings 37

Configuration 38

Language 40

Installation 41

First Time Installation 42

IP Settings 42

Other information

Technical specifications 46

Product support

Troubleshooting 50

OSD Warning Messages 51

Hard Disk 52

Help and assistance 53

Disposal 54

Guarantee 55

6

7

Safety information

Power Safety 6

Hard Disk Safety 7

Safe Use of the Equipment 7

Getting to know your set-top
box

Ready? Let’s begin 12

Accessories 12

Overview of the Remote Control 13

Overview of the Set-Top Box 14

Connections

Connecting the Set-Top Box to a TV Set 18

Power Connection 19

First Time Installation 20

Auto Power Down 21

Standard features

Changing Channels 24

Adjusting the Volume 24

On-Screen Information 24

Instant Recording 24

Menu System 25

Internet Portal 25

Advanced features

Managing Stations: Channel List 28

Electronic Programme Guide (EPG) 30

Configuring Timers 31

Recordings Library 32

Time Shifting (Pause Live Recording) 34

1

2

3

4

5

This page is left intentionally blank

1Safety information

Safety information

Important - Please read these instructions fully before

installing or operating

Safety information6

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Power Safety

Power source

• Always use the provided AC adaptor.

• Operate only from the power source specified on
the AC adaptor.

• The power adaptor may become hot during normal
operation. This is not a malfunction.

• Please make sure that the adaptor is not covered
while in operation. Leave a space of 15 cm
(minimum) around the AC adaptor.

• The rating information and safety caution of the AC
adaptor are provided on the adaptor.

WARNING: When the set-top box is not in use for a
long time, disconnect it from the power.

Power Cord

• Do not place the unit, a piece of furniture, etc., on
the power cord, or pinch the cord.

• Handle the power cord by the plug. Do not pull out
the plug by tugging the cord.

• Never touch the power cord when your hands are
wet as this could cause a short circuit or electric
shock.

• Never make a knot in the cord or tie it with other
cords.

• The power cords should be routed in such a way
that they are not likely to be stepped on.

• A damaged power cord can cause fire or give you
an electrical shock.

• Check the power cord once in a while. When you
find it damaged, ask closest service agent for help.

• Please do not place the set in a place subject to
direct sun light, excessive dust or mechanical shock
or in a location near heat sources.

• The device should be placed on a solid and safe
base.

• Do not place the apparatus on a soft surface such
as a rug that might block the ventilation holes on
the bottom.

• The selected location should not have a high
humidity. Condensation, that may arise in a kitchen
for example, may cause a malfunction or damage
the device.

• Heating or other thermal radiation under the set
also may cause malfunction or damage the device.

• The hot air, which arises during operation, should
be ventilated with sufficient air circulation. Please
do not put the device into closed areas and do not
cover it.

• Please avoid contact of the device with water or
humidity. Do not put into operation near bath,
swimming pools.

• Take care to provide good air circulation. Place the
device in a location with adequate ventilation to
prevent heat build-up in the device.

• Should any solid object or liquid fall into the cabinet,
unplug the device and have it checked by qualified
personnel before operating it any further.

• The device should not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the device.

Batteries

Batteries shall not be exposed to excessive heat, for
example sunshine or fire.

Connection to a Television Distribution
System (Cable TV etc.) from Tuner

Device connected to the protective earthing
of the building installation through the mains
connection or through other apparatus with a
connection to protective earthing-and to a television
distribution system using coaxial cable, may in some
circumstances create a fire hazard.

Connection to a cable distribution system has therefore
to be provided through a device providing electrical
isolation below a certain frequency range (galvanic
isolator, see EN 60728-11).

Safety information

Important - Please read these instructions fully before

installing or operating

Safety information 7

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Hard Disk Safety

This Recorder has a built in hard disk (abbreviated
as HDD ) for recording and playback. Beware of
the following points when setting up and using the
Recorder. Failure to observe precautions may cause
damage to the HDD itself or its content, failure of the
disk to operate, or recording of noise.

• Do not subject the Recorder to any vibration or
impact.

• Do not place the Recorder in a cramped location
which might block the ventilation port on the back
of the Recorder.

• Do not place the Recorder in a location with severe
temperature variation.

• If the Recorder is set up in a location with severe
temperature variation, dew may form on and inside
the Recorder. If the Recorder is used with internal
dew formation present, this may cause HDD
damage or malfunction. We recommend keeping
variation in room temperature within 10˚C per hour.

• Do not place the Recorder in a location with high
humidity.

• Place the Recorder horizontally, never at an incline.

• Do not place a magnetic device (magnet etc.) close
to the recorder.

• When the power is on, do not unplug the AC
adaptor from the AC outlet, turn off the breaker for
the area where the Recorder is set up, or move the
Recorder.

• When moving the Recorder, first turn off the power
and then unplug the power cord from the AC
outlet.

Note: If a message indicating an HDD error is displayed
(such as ERROR IN HDD. CANNOT OPERATE.) and
the HDD has malfunctioned, you cannot replace the
HDD by yourself. If you disassemble the Recorder, the
warranty will become void. Also, recovery of data is
impossible.

Safe Use of the Equipment

This equipment has been designed and manufactured
to meet international safety standards but, like any
electrical equipment, care must be taken if you are to
obtain the best results and to ensure its safety.

DO read the operating instructions before you attempt
to use the equipment.

DO ensure that all electrical connections (including
the mains plug, extension leads and inter-connections
between the pieces of equipment) are properly made
and in accordance with the manufacturer’s instructions.
Switch off and remove the mains plug before making
or changing connections.

DO consult your dealer if you are ever in doubt about
the installation, operation or safety of your equipment.

DO be careful with glass panels or doors on
equipment.

DO route the mains lead so that it is not likely to be
walked on, crushed, chafed, or subjected to excessive
wear and tear or heat.

DON’T remove any fixed cover as this may expose
dangerous voltages.

DON’T obstruct the ventilation openings of the
equipment with items such as newspapers, tablecloths,
curtains, etc. Overheating will cause damage and
shorten the life of the equipment.

DON’T allow electrical equipment to be exposed to
dripping or splashing, or objects filled with liquids, such
as vases, to be placed on the equipment.

DON’T place hot objects or naked flame sources
such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and
lead to fires.

DON’T use makeshift stands and NEVER fix legs with
wood screws - to ensure complete safety always fit the
manufacturer’s approved stand or legs with the fixings
provided according to the instructions.

Safety information

Important - Please read these instructions fully before

installing or operating

Safety information8

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

DON’T use equipment such as personal stereos or
radios so that you are distracted from the requirements
of traffic safety. It is illegal to watch television whilst
driving.

DON’T listen to headphones at high volume, as such
use can permanently damage your hearing.

DON’T leave equipment switched on when it is
unattended unless it is specifically stated that it is
designed for unattended operation or has a stand-by
mode.

Switch on the equipment and make sure that your
family know how to do this. Special arrangements may
need to be made for infirm or handicapped people.

DON’T continue to operate the equipment if you are in
any doubt about it working normally, or if it is damaged
in any way - switch off, remove the mains plug and
consultyour dealer.

ABOVE ALL

• NEVER let anyone especially children push anything
into holes, slots or any other opening in the case ­this could result in a fatal electrical shock;

• NEVER guess or take chances with electrical
equipment of any kind

• It is better to be safe than sorry!

Safety information

Important - Please read these instructions fully before

installing or operating

Safety information 9

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

This page is left intentionally blank

This page is left intentionally blank

Getting to know your

set-top box

2

Getting to know your set-top box

You’ll be up and running in no time

Getting to know your set-top box

12

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Ready? Let’s begin...

Please read these instructions carefully. They contain
important information which will help you get the best
from your set-top box and ensure safe and correct
installation and operation.

If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.

Accessories

.

Power adaptor HDMI cable

RF cable

Remote control

Fig 1.

Batteries User guide

Quick start guide

Getting to know your set-top box

You’ll be up and running in no time

Getting to know your set-top box

13

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Overview of the Remote Control

Standby Mute

Favourite List

Media Browser

Volume Up/Down

Exit

Info

OK/Channel List

Pause

Search/Backward

Display Teletext

Subtitles

Switch between TV and Radio

Numeric Buttons (0-9)

Library of Recordings

Channel Up/Down

Previous Programme

Menu

Back

Navigation (Up/Down/Left/Right)

Stop

Search/Forward

Settings

Lang.

Electronic Programme Guide

Portal

Play

Record

Channel List

Change HDMI Resolution

Audio Left/Right

Fig 2.

Getting to know your set-top box

You’ll be up and running in no time

Getting to know your set-top box

14

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Overview of the Set-Top Box

Front view

Rear view

1

1. USB INPUT: To connect external USB storage

devices.

2. OPTICAL AUDIO OUT: You can use this connector

to output the digital audio to an external device.
See your audio system instruction book for further
information.

3. ANTENNA IN: Aerial input.

4. ANTENNA OUT: To watch channels on the TV.

5. HDMI IN: HDMI connection.

6. LAN: Ethernet Input.

7. SCART OUT: If your TV has a scart connector, you

can connect the box to your TV using a scart cable.

8. POWER CABLE: DC IN (12V).

823 4 56 7

Make sure that you connect all cables and connections before you plug the unit into the mains supply. After you
connect the unit to the mains supply, the LED light located on the front panel will be red (Standby mode).

Fig 3.

Fig 4.

Getting to know your set-top box

You’ll be up and running in no time

Getting to know your set-top box

15

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

This page is left intentionally blank

This page is left intentionally blank

Connections

3

Connections

Bringing it all together

Connections18

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Connecting the Set-Top Box to a TV Set

You can connect the set-top box to your TV by using the scart socket or HDMI input. Use a scart or HDMI cable to
connect the set-top box to your TV.

The set-top box gives RGB or CVBS output from scart or high definition quality from HDMI output.

Antenna Connection

This illustration shows how to connect an antenna.

Use ANTENNA IN to connect to an antenna system.

Fig 5.

Fig 6.

Connections

Bringing it all together

Connections 19

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Power Connection

IMPORTANT: The set-top box is designed to operate

on 12 V DC. For this, an adaptor is used which gives
12 V voltage. Connect this adaptor to a system that
supplies 220-240V AC,50Hz.

After unpacking, allow the set-top box to reach the
ambient room temperature before you connect the set
to the mains.

Inserting Batteries in the Remote Control

1. Remove the battery cover located on the back of
the remote control by gently pulling backwards
from the indicated part.

2. Insert two AAA/R3 (2 X 1.5Volt) or equivalent type
batteries inside. Place the batteries in the correct
direction observing the polarity symbols (+/-) and
replace the battery cover..

While using the remote control, you should direct it
towards the front panel of the receiver. Remote range is
approximately 7m/23ft.

If your receiver no longer responds to the remote
control. it is probable that the batteries are exhausted.
If so you can still use the local buttons of the receiver.
You can replace batteries after they are exhausted.

Note : Remove the batteries from the remote control
when it is not to be used for a long period. Otherwise it
can be damaged due to batteries leaking.

Power On-O

Connect all cables before plugging into the mains.

After plugging in the AC adaptor for the set top box to
the mains supply, a red light will be seen on the front
panel (Standby mode).

When the set top box is first powered up please wait
until the box is initialized before activating the receiver
as booting of software will take some time. Please wait
until unit is initialized. This may take almost a minute.

This product conforms with the latest European Union
Power Consumption Regulations and features a low
power standby mode. The product enters into the low
power standby mode approximately 30 seconds after
the standby button is pressed to turn off the unit.

Until low power mode is activated, a clock will be
displayed at the display and light will be OFF. When the
low power mode is activated, the display will be shut
down and light will be red.

When you press the standby button during low
power mode, it may take a minute until the product
is initialised. However, if you press the standby button
before the low power mode is activated, the unit will
be initialized in a couple of seconds (Active standby
mode).

When the box is on mode, a channel number will be
displayed on the display and light will be OFF.

Although it is not recommended for enviromental
reasons, you may disable low power mode in your
product using the setup –configuration menu. If low
power mode is disabled, only the clock is displayed in
standby mode.

Fig 7.

Fig 8.

Connections

Bringing it all together

Connections20

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

First Time Installation

IMPORTANT: Ensure that the aerial is connected

before switching on the set top box for the first time.

When the set top box is operated for the first time,
installation wizard will guide you through the process.
First, TV Type selection on-screen menu will be
displayed:

By pressing the

/ buttons select the TV type you
want to set and press OK button. Afterwards, “Select
HDMI resolution” OSD will appear on the screen.Select
your desired resolution by pressing the

/ button

and press the OK button.

Then “Do you want to start an automatic channel
scan?” pop-up menu is displayed. Auto search can be
started by selecting the “Yes” button. The box will
automatically find the channels and store them.

To start installation process, select Yes by using the

/ buttons and then press the OK button.

The box will start to search available stations. The
progress bar will move along the line. You should allow
the set top box to complete the search to store all
available stations.

Note: You can press the MENU button to cancel.

Fig 9.

Fig 10.

Fig 11.

Fig 12.

Connections

Bringing it all together

Connections 21

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Auto Power Down:

This box will automatically switched from active mode
into standby mode, after less than three hours in active
mode, following the last user interaction and/or a
channel change with an alert message two minutes
before going in to standby mode. The Automatic
power-down can be set as disabled, 2 hours, 3 hours,
4 hours, 6 hours or 8 hours from the configuration
menu.

Important Note : If there is any ongoing programme
recording or if any EPG programme recordings and/
or manual recordings are set to a nearby time, the
unit does not switch to low power mode and remains
in active standby mode until recording tasks have
been finished. In low power mode, the unit initializes
a couple of minutes before the actual time of the
incoming recording task.

Important Note : The unit initializes from time to time
to receive updates from the EPG broadcast in order
to synchronize EPG recording tasks properly. After
getting updates, the unit switches to low power mode
automatically. This takes a short while and it is not a
malfunction.

This page is left intentionally blank

Standard features

4

Standard features

Simple everyday use

Standard features24

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Changing Channels

You can change channels with the following methods.

• You can press the numeric buttons (0–9) to directly

enter the channel number. You can press numeric
buttons consecutively to enter two or more digits.

• Press the P +/ P - buttons to move up or down to

the next available channel.

Note: You can press OK button to display the channel
list.

Adjusting the Volume

Volume Up / Down

You can increase or decrease the volume by using the
V+ / V- buttons.

The volume level selected will remain set, even when
the receiver is turned off and on again, until you
change volume again.

The audio volume adjustment for the receiver is
independent of the volume control on your TV set.

IMPORTANT: You should be careful that both volume
controls are kept within reasonable levels so that when
switching on, or when first turning on your TV set, the
sound level is not too high.

Mute

You can press to mute the sound of your set top
box. The sound will be muted once this button is
pressed.

To cancel mute, you can press button again or use
the V +/ V - buttons.

On-Screen Information

You can press the INFO button to display on-screen
information. Details of the station and current
programme will be displayed on the information
screen.

The information screen will then display the current
event name, next event name, starting and ending
time, duration bar, programme mode and the channel
number and name.

Instant Recording

Press (RECORD) button to start recording an event
instantly while watching a programme. The following
OSD appears on the screen:

Record OSD will then be displayed for a short time and
the current event will be recorded.

Fig 13.

Fig 14.

Fig 15.

Standard features

Simple everyday use

Standard features 25

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Press the (STOP) button to cancel instant recording.
The following OSD will be displayed:

Select Yes by using the

/ or OK buttons to cancel

instant recording.

Note: When two recordings are active, you can only
watch channels which are on the same multiplexes.

No upper limit is defined to schedule recordings for
events by Instant Recording.

Menu System

Viewing the Main Menu

Press the MENU button to view main menu.

You can move between menus using the navigation
( / / / ) buttons on the remote control.

You can enter, select or confirm a menu option by
using the OK button.

In some sub-menus, you can use the BACK button to
return to a previous menu screen.

To exit from a menu screen, you can press the MENU
button.

The following items are located in the main menu
screen:

Internet Portal

You can access internet portal using your set-top box.
To do this, an active internet connection is required.

After the connection is established, you can select
Internet Portal option from the main menu to activate
the portal. You can access several applications using
this portal.

Use navigation buttons to make selections.

Fig 16.

Fig 17.

Fig 18.

This page is left intentionally blank

Advanced features

5

Advanced features

Getting the most from your TV

Advanced features28

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Managing Stations: Channel List

The set top box keeps all stored stations in the Channel
List.

Press the MENU button to view main menu. Select the
Channel List item by using the

/ buttons. Press OK

to view the menu contents.

Note: You can also press the OK button to view
channel list.

Operating the Channel List

Press the / buttons to select the channel that will
be processed.

Press the

/ buttons to select a function on Channel

List menu.

Press the P +/ P - buttons to page up or down.

Press the BLUE button to view filtering options.

Press the YELLOW button to tag/untag a channel.

Press the GREEN button to tag all channels.

Press the INFO button to view more information.

Press the MENU button to exit.

Selecting a Specifi c Channel

Select option should be highlighted by using the /
buttons.

To watch a specific channel, you should highlight the
desired channel using the

/ buttons and press the

OK button. The selected channel will be displayed.

If the selected channel is password protected, the
parental lock password will be required.

Deleting Channels

Select the channel that you want to delete and select
Delete option using the / buttons. Press the OK
button to continue.

A message will be displayed to confirm your decision.
Select YES to delete the selected channel or select NO
to cancel. Press the OK button to continue.

Deleting Multiple Channels:

1. Select Delete and highlight the channel you want
to delete.

2. Press the YELLOW key. The channel will be marked.
Move to the next channel you want to delete.

3. Mark the other channels you want to delete like the
same way and press OK.

4. You will see a confirmation menu. Select YES in the
menu. The selected channels will be deleted.

To mark all the channels in the channel list at once you
can use the GREEN key.

Note: A channel currently being watched cannot be
deleted.

Renaming Channels

Select the channel that you want to rename and select
Edit Name option using the

/ buttons. Press the

OK button to continue.

Fig 19.

Advanced features

Getting the most from your TV

Advanced features 29

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Pressing the / buttons moves to the previous/next
character. Pressing the / buttons toggle the current
character (i.e., ‘b’ character becomes ‘a’ by pressing
and ‘c’ by pressing ).

Pressing the numeric buttons (0-9) replaces the
highlighted character with the characters printed above
the button one by one as the button is pressed.

Press the MENU button to cancel editing.

When finished, press the OK button to save the new
name.

Adding Locks to Channels

1. Select the channel that you want to lock and select
Lock option using the / buttons.

2. Press the OK button to continue.

3. You will be asked to enter parental control PIN

code.Enter the PIN number.

4. Press the OK button to lock/unlock the channel.
Lock symbol will be displayed next to the selected
channel. You can repeat the same action to cancel
the lock.

Note: Default PIN code is 0000 and it can be changed
using the Configuration Menu.

Locking Multiple Channels:

1. Select Lock item and highlight the channel you
want to lock. Press the YELLOW key. The channel
will be marked.

2. Move to the next channel you want to lock and
press the YELLOW key.

3. Mark the other channels you want to lock the same
way and press OK.

4. Enter the pin code in the menu displayed and press
OK.

The selected channels will be locked.

To mark all the channels in the channel list at once you
can use the GREEN key.

Setting Favourites

Select Favourites by using the / buttons and press
the OK button.

You can set various channels as favourites so that only
the favourite channels are navigated.

Select a list by pressing the

/ buttons. Then, select
a channel by using the / buttons. Press the OK
button to add selected channel to the favourites list.

A star icon indicates that the selected channel is on the
favourites list.

You can press the OK button again to remove the
selected channel from the list.

Button Functions:

OK: Adds/removes a station.

BLUE: Displays filtering options.

YELLOW: Tags/untags a channel.

GREEN: Tags/untags all.

Fig 20.

Advanced features

Getting the most from your TV

Advanced features30

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Electronic Programme Guide (EPG)

You can view the electronic programme guide (EPG) to
view information about available programmes. The set­top box gets channel & programme information weekly
by means of 8 day EPG. Select Programme Guide
from the main menu by using the

/ buttons. Press

OK to continue.

HINT: You can also press the GUIDE button to view the
EPG menu.

Press the

/ buttons to navigate through channels.

Press the / buttons to navigate through the
programme list.

Please note that event information is updated
automatically. If there are no event information data
available for channels, EPG will be displayed with
blanks.

Red button (Prev Day): Displays the programmes of
previous day.

Green button (Next day): Displays the programmes of
the next day.

Yellow button (Zoom): Expands programme
information.

Blue button (Filter): Views filtering options.

INFO (Details): Displays the programmes in detail.

: Records the selected programme.

Numeric buttons (Jump): Jumps to the preferred
channel directly via numeric buttons.

OK (Options): Displays programme options including
Select Channel option.

: Scrolls page left.

: Scrolls page right.

Text (Search): Displays “Guide Search” menu.

(Now): Shows the current programme.

Event Options

In EPG menu, press the OK button to enter the Event
Options menu.

Select Channel

Highlight it and press the OK to switch to the selected
programme.

Record Programme

Highlight it and press the OK button to set the
programme to recording.

Record Series/Delete Series

In the EPG menu, after you have selected a
programme, press the OK button and select the
Record Series option and press the OK button again.
The selected programme will then be set for series
recording.

With this feature, you can record a programme and
all of its following parts within 8 days. The information
belonging to the selected programme will be saved
from the software and following parts of the selected
programme which are not included in the period of 8
days, will be automatically added day by day. The letter
“s” denotes that these recordings are series records.

Fig 21.

Fig 22.

Advanced features

Getting the most from your TV

Advanced features 31

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

To cancel an already set series recording, highlight that
programme and press the OK button and select the
option Delete Series. The recordings will be cancelled.

Note: Series programme information should be
broadcasted by the broadcaster.

Split Record

When you select a programme to be recorded, if there
is another part of the programme available, it will also
be set to record automatically. The programme’s
following episode is also underlined in the picture. To
do this, you have to press only the RECORD button
once. The programme you selected will be framed red.

Note: Split programme information should be
broadcasted by the broadcaster.

Confi guring Timers

Select Timers from the main menu and press the OK
button.

To add a timer, press the YELLOW button on the
remote control. The Add Timer window appears.

Channel: the

/ buttons will navigate the user

through the TV or Radio list.

Record Type: Displays recording type.

Date: Starting date is entered using the

/ buttons

or the numeric buttons.

Fig 23.

Fig 24.

Fig 25.

Advanced features

Getting the most from your TV

Advanced features32

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Start: Starting time is entered using the / buttons
or the numeric buttons.

End: Ending time is entered using the / buttons or
the numeric buttons.

Duration: Duration between Start and End time.

Repeat: Sets the repeating preference.

Playback: Sets playback control.

Change/Delete: permits or prohibits any modifications

for other users.

You can save the adjustments by pressing the GREEN
button or cancel the process by pressing the RED
button.

You can edit the timers list using the GREEN button
and delete with the RED button. You can sort recorded
programme by pressing the BLUE button. You can also
press the OK button to display other options.

Recordings Library

To view the list of recordings, press the MENU button
to display the main menu and use the / buttons to
highlight the Recordings Library and press the OK
button. The recordings Library will then be displayed
with available recordings which are kept in a list.

Red bar: Indicates the used space of the recordings on
the hard disk.

Green bar: Displays the approximate capacity required
for the timers currently set.

RED button (Delete) :Erases the selected recording.

GREEN button (Edit): Makes changes on the selected

recording.

YELLOW button (Tag): Tag/untag a recorded
programme.

BLUE button (Sort): Changes the order of the
recordings. You can select from a wide range of sorting
options.

OK button: Displays playing options:

(Resume): Resumes the playback.

Note: Viewing main menu and menu items will not be
available during the playback.

INFO (Details): Displays the short extended
programmes in detail.

Play Options

Play from start: Plays the recording from the

beginning.

Resume: Begins playing from the last stopped position.

Resume: Resumes the recording.

Play from offset: Begins playing,from the time which is

entered.

Fig 26.

Fig 27.

Advanced features

Getting the most from your TV

Advanced features 33

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Manage chapters : It will display any marked chapters
(To set chapter marks, press the Menu button during
playback and enter the Chapter Options menu) and
begin with playback from the selected chapter.

Create archive (Archive management): To use this
feature, you should tag the files to be archived first by
using the YELLOW button. When all the desired
recordings are tagged, press the OK button to display
Play Options and then select Create Archive. When
finished, press the Play button to start archiving.

Edit Recordings

Press the OK button when Edit Recordings is
highlighted. Then select the recordings that are to be
archived.

When finished, press the OK button and the following
menu will be displayed:

In this menu, only the Start recording at and Stop
recording at options are active. If you have already
split the recording, you can select any chapter. If it is
not split in chapters, the beginning and ending time of
the recording will automatically be the beginning and
ending time of the archiving.

Main Title

If you want to display a main title, select Include. If not,
select Skip.

Text

After you have selected the Include option in the Main
Title menu, you can edit the main title.

Duration

Set the duration of the appearance of the main title on
the screen.

Recording Title

If you want to display a recording title, select Include. If
not, select Skip.

Display

You can add name,start date/time or length
information to your archived file by using display
option.

Duration

Set the duration of the appearance of the Edit
recording title menu main title on the screen.
Displaying Chapter Options.

During playback of a recording, if you press the MENU
button, the Chapter Options menu will be displayed.

Fig 28.

Fig 29.

Advanced features

Getting the most from your TV

Advanced features34

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Create New Chapter Mark: You can set a chapter mark
anywhere you want.

Forwards to Next Chapter: Goes to the next chapter if
there is more than one chapter available.

Back to Start Of Chapter: Goes to the beginning of
the current chapter. This is the last played chapter.

Back to Previous Chapter: Goes back to the previous
chapter if there is more than one chapter available.

Time Shifting (Pause Live
Recording)

Pause Live Recording is a feature that enables you to
pause a live broadcast. The live broadcasting can be
stopped any time.

Press

PAUSE button to timeshift the broadcasting.

In the INFO banner the timeshift will commence.

The duration of Timeshift can be adjusted from
Recordings in the Configuration menu.

To stop the timeshift press PLAY, PAUSE or OK
button. The paused recording can be watched in
different speeds using the

or keys. To cease the

timeshifting press STOP button.

Media Browser

To display the Media Browser, select Media Browser in
the main menu using the

/ buttons and press OK.

Note: Available media servers, connected to the same
network will be dispayed too. Press the

/ buttons
to select one and press OK to browse the selected
media server.

Viewing USB Disk Contents

You can play music, video and picture files from a
USB memory stick, but only music and picture can be
played from an external Hard Disk Drive.

Note: Some USB compliant devices may not be
supported.

If the USB stick is not recognized after power off/on or
First Time Installation, first, unplug the USB device and
power off/on the set-top box. Plug the USB device in
again.

Fig 30.

Fig 31.

Fig 32.

Advanced features

Getting the most from your TV

Advanced features 35

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Playing Video Files

Select USB Drive option from the main media browser
screen and press OK button. Select the folder (if
available). All media files will be displayed.

Jump (Numeric buttons): Jumps to the selected file
using the numeric buttons.

OK / PLAY(

) buttons: Opens the Play Options menu.

Blue Button (File Operations): Displays options of
Delete, Rename, Move to HDD, Copy to HDD. Press
BACK to exit.

Next page / Previous Page: Jumps to previous or next

page.

Back: Goes back to main folder.

Play (

button): Play files.

Pause ( button) : Pauses the playback.

Stop (

button) : Stop the playing file.

Rewind ( button) : Goes backward.

Fast Foward ( button) : Goes foward.

GREEN : Jumps to the selected time.

LANG : Set subtitle or audio.

Playing MP3 Files

Select USB Drive option from the main media browser
screen and press the OK button. Select the folder (if
available). All media files will be displayed. Select a
music file and press OK to play.

Playing JPEG Files

OK: Shows the selected image in full screen.

Slideshow (

button): Starts slideshow.

Jump (Numeric buttons): Jumps to the selected file
using the numeric buttons.

Next page / Previous Page: Jumps to previous or next
page.

Back: Goes back to main folder

BLUE (File Operations): Displays options of Delete,
Rename, Move to HDD, Copy to HDD. Press BACK to

exit.

Fig 33.

Fig 34.

Fig 35.

Advanced features

Getting the most from your TV

Advanced features36

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Slideshow Options

Pause: Pauses slideshow

Play ( button): Resumes the slideshow.

Stop ( button) : Back to the file list.

Rotate (

/ buttons): Rotate the picture using up/

down buttons.

Previous/Next ( / buttons): Jumps to previous or
next file.

Info: Shows/hides the info bar.

RED: Activates Shuffle mode.

GREEN: Activates Loop mode.

Digital Teletext

• Press the TEXT button. The digital teletext

information appears.

• Operate it with the coloured buttons, cursor buttons

and OK button.

The operation method may differ depending on the
contents of the digital teletext.

Follow the instructions displayed on digital teletext
screen.

When ‘Press OK button’ or similar message appears on
the screen, press the OK button.

When the TEXT button is pressed, the TV returns to
television broadcasting.

With digital terrestrial broadcasting (DVB-T), in addition
to digital teletext broadcasting together with the
normal broadcasting, there are also channels with just
digital teletext broadcasting.

The aspect ratio (picture shape) when watching
a channel with just digital teletext broadcasting is
the same as the aspect ratio of the picture viewed
previously.

When you press the TEXT button again, the digital
teletext screen will be displayed.

Many digital terrestrial television channels broadcast
pages of information on the programmes, the weather,
news and other topics.

This digital teletext can be displayed by your set
top box. Indeed, some channels broadcast teletext
information entirely.

When such a channel is selected, it will usually display
the opening page of information automatically, after a
short break.

Some channels mostly have digital teletext pages
broadcast along with the television programme.

Fig 36.

Fig 37.

Advanced features

Getting the most from your TV

Advanced features 37

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Settings

Select Settings from the main menu by using the /
buttons and press the OK button to display.

Recordings

To configure the playback/recording options select the
Recordings option from the configuration menu.

Max Time Shift

Select the maximum time allowed for timeshifting.
See Time Shifting section for more information on
timeshifting

Auto Discard

Discard: When the HDD is full and a timer is set to
record, the unit will automatically discard previous
recordings based on this setting. The options are as
follows:

• None: The unit will not discard any recordings and
the timer will not record the requested programme.

• Oldest: Starting with the oldest, recordings will be
deleted to make space for the requested timer.

• Longest: Starting with the longest, recordings will
be deleted to make space for the requested timer.

• Shortest: Starting with the shortest, recordings will
be deleted to make space for the requested timer.

• Unplayed: If this option is set to EXCLUDED any
unplayed recordings will NOT be deleted. If this
option is set to INCLUDED, unplayed recordings
WILL be deleted.

• Watershed: Use these settings to change the
watershed time period. Press MENU button to exit.

Any recording which is made during the watershed
period will have Playback set to Disallowed when it
appears in the library. You can only play the recording if
you enter the PIN.

One Touch Recording :

HD alternatives :You can adjust this setting to suit your
preference.

Fig 38.

Fig 39.

Advanced features

Getting the most from your TV

Advanced features38

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Confi guration

You can configure the main settings of your set top box
using the configuration screen.

Select Configuration from Setup & Retune menu and
press OK to continue.

You can press BACK button to exit.

Active channels

You can select broadcasts to be listed in the channel
list. To display specific types of broadcast, you should
use Active channel list setting.

Select Active Channels by using the / buttons.

You can select a broadcast type option from the list
by using the

/ buttons. Available modes are: TV
Only, Radio Only, Text Only, Favourites or Show All (if
available).

Press the MENU button to save the recent changes and
exit.

Scan Encrypted

When this setting is on, search process will locate the
encrypted channels as well. If it is set as Off, encrypted
channels will not be located in automatic search or
manual search.

Use the

/ buttons to highlight Scan Encrypted and

the / buttons to select YES or NO.

Output Settings

TV Type

Digital terrestrial television channels can be broadcast
in a widescreen format which must be output
differently to normal and widescreen TV sets.

This function defines the screen format of the
connected TV to enable broadcasts’ being displayed
correctly.

Select 4:3 if you have a standard TV set with 4:3 aspect
ratio.

Select 16:9 if you have a widescreen TV.

Note: This function also enables you to change the TV
Type that you have previously selected during the first
time installation.

TV Out

The set top box can output RGB and CVBS signal via
the TV SCART connector located on the rear panel.

Some devices might not support the RGB format.

Receiver Upgrade

Fig 40.

Fig 41.

Advanced features

Getting the most from your TV

Advanced features 39

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

To ensure that your set-top box always has the most
up to date information, you can use this setting. For the
proper operation, please ensure that the box is set to
standby mode.

The set-top box automatically powers up at 3.00 A.M.
every day and searches for any new software that may
be broadcast. If found, the box will download new
software automatically. This operation will normally
take approximately 30 minutes.

You can enable or disable automatic upgrade by
setting Automatic Scanning option.

You can manually search for new software by selecting
Scan for upgrade.

You can also update your set-top box by using the USB
upgrade option.

Parental Settings

This setting configures menu locking.

Select the Menu Locking option by using the /
buttons.

Press OK button to enter the menu.

To display parental lock menu options, PIN number
should be entered. Factory default PIN number is

0000. After coding the correct PIN number, parental
settings menu will be displayed:

Set Pin

Press OK to display the “Set PIN” window. Use numeric
buttons to enter the new pin number. You will need
to input your new pin a second time for verification
purposes.

The factory default pin number is 0000. If you change
the pin number make sure you write it down and keep
it safe.

Menu Lock

Menu lock setting enables or disables the menu access.
You can disable access to the installation menu or the
whole menu system.

Guidance

Guidance setting enables or disables the menu access.

Low Power

If you enable low power option, low power mode
will be activated. In low power mode the power
consumption is less then 0.5W (in standby). If you
disable low power option the power consumption will
be high in standby mode .However the opening time
will be shorter and aerial RF loop_through is operative
in stand-by when the Low Power is set to NO.

Auto Standby

Use the / buttons to select Auto Sleep.

Use the

/ buttons to set the Auto Sleep to

Disabled, 2 Hours, 3 Hours, 4 Hours, 6 Hours or
8 Hours.

After the timeout value is reached, the box will switch
off.

Fig 42.

Fig 43.

Advanced features

Getting the most from your TV

Advanced features40

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

About

Select About and press the OK button to display
system information.

Audio Description

This function enables or disables the audio description
feature by pressing the / buttons. Audio description
refers to an additional narration track for blind and
visually impaired viewers of visual media, including
television and movies. The description narrator talks
through the presentation, describing what is happening
on the screen during the natural pauses in the audio
(and sometimes during dialogue, if deemed necessary).
You can use this feature only if the broadcaster
supports this feature.

Available Langs.

You can see available languages in this section.

Preferred Language (Optional)

Use the / buttons to change the preferred audio
description language.

This setting can be used, only if it is available.

Relative Volume (Optional)

Using this option, the Audio Description volume level
can be increased or decreased relatively, according to
the general volume.

Language

• You can operate the TV’s language settings using
this menu.

• Select Language from the Setup menu and press

OK to continue.

Menu: shows the language of the system.

Preferred

These settings will be used if available. Otherwise
current settings will be used.

• Audio: Sets the preferred audio language.

• Subtitle: Sets the subtitle language. Selected

language will be seen in subtitles.

• Guide: Sets guide language.

Current (*)

(*) These settings can be changed if only the
broadcaster supports it. Otherwise, the settings will not
be available to be changed.

• Audio: Changes the audio language for the current
channel.

• Subtitle: Sets the subtitle language for the current
channel.

Fig 44.

Fig 45.

Advanced features

Getting the most from your TV

Advanced features 41

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Installation

The Installation menu will help you to retune your set
top box in order to store new services or stations.

Select Installation from the Setup menu by using the

/ buttons and press OK to continue.

Installation menu includes the following items:

Automatic Channel Scan / Retune

Select Automatic Channel Scan / Retune by using the

/ buttons and press the OK button.

The following message will be displayed on the screen:

Highlight Yes or No using the

/ buttons and press

the OK button to confirm.

• If Yes is selected, automatic search starts.

• Selecting No cancels automatic search.

After the scanning is completed, your set top box will
store all the available channels.

Manual Channel Scan

This feature can be used for direct broadcast entry.

Select Manual Channel Scan by using the /
buttons and press the OK button.

In manual channel scan, the number of the multiplex
is entered manually and only that multiplex is searched
for the channels.

For each valid channel number, signal level and signal
quality are shown on the screen.

In both manual and auto search, any existing channel
in the database is not re-stored to avoid duplicates of
that channel.

Format Disk

If you want to format the internal hard disk, you can
use the Format Disk option. ALL the data stored on

the hard disk will be lost in such a case.

• Press OK when the Format Disk option is
highlighted. A menu appears, requiring you to enter
the pin number. If you have not changed the pin
number, the factory default is 0000.

• After you enter the correct PIN code, a pop-up
menu appears on the screen to ensure that the hard
disk should be formatted.

• Select YES and press OK to format the hard disk, or
select NO and press OK to cancel.

Fig 46.

Fig 47.

Fig 48.

Advanced features

Getting the most from your TV

Advanced features42

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

First Time Installation

• If you want to load default settings of your set top
box, you can perform first time installation.

• Select First Time Installation by using the

/

buttons and press the OK button.

• The following message will be displayed:

• Highlight No by using the

/ buttons to cancel

installation.

• Highlight Yes by using the

/ buttons and press

OK button to start first time installation.

• After you select Yes, factory settings will be loaded.

• The Installation wizard will guide you through the
installation process. See the section, First Time
Installation (page 20) for more information on this
process.

IP Settings

You can configure your receiver’s IP settings by using
this menu screen.

• Use the YELLOW button to set static IP settings.

• Use the BLUE button to configure dynamic IP
settings.

• Use the RED button to disable IP configuration.

In order for the ethernet host to work correctly with
your internet connection it needs to have a unique IP
address. In most cases all of the parameters can be
provided by the DHCP server in their router. In this case
you should use the Dynamic option.

In the unlikely event that you do not have a DHCP
server in your router, or if you prefer to assign your
own IP address, then the Static option can be used.
You will need to enter a unique IP address along with
the default gateway and DNS server. In most domestic
networks the default gateway and DNS server will both
be the IP address of the router.Available MAC address
will be displayed on MAC address line.

Fig 49.

Fig 50.

Advanced features

Getting the most from your TV

Advanced features 43

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

This page is left intentionally blank

This page is left intentionally blank

Other information

6

Other information

Helpful technical information

Other information46

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Technical Specifi cations

General characteristics

Power supply for set-top
box

12 V DC 2 Amp

Preferred DC adaptor 220 - 240 V AC, 50 -60 Hz
Input frequency 470 MHz - 862 MHz
Frequency band UHF
Maximum power

consumption

17.5 W

Standby power
consumption

0.5 W

Operating temperature 5°C to +40°C
Storage temperature -15°C to +55°C
Humidity 25 to 75 % rel
Physical dimensions 231 x 137 x 43 mm
Weight 0.9 kg

Hardware Confi guration

Main processor BCM7230
Flash memory 128 Mb
DDRRAM 512 Mb

Digital Capabilites

Transmission standards

MPEG2, MPEG4 HD
DVB-T-2

Frequency band UHF

Demodulation

COFDM with 2K/8K FFT mode

FEC

for all DVB modes
(automatically found)

16QAM, 64QAM, 256QAM with 1k, 2k, 4k, 8k, 16k, 32k
FFT mode

Video

All MPEG-4 (part 10) MP@ML Video Decoder

Aspect ratio 4:3, 16:9 with pan vector

RGB analogue outputs

BM ≥ 5 MHz at 0.5 to
5 MHz sweep signal

CVBS analogue output

Profi les

MPEG-4 H.264/AVC HP@L 4.0, MP@L 4.00 (HD)

• H.264/AVC MP@L 3.2, HP@L 3.2 (SD)

• MPEG-2 MP@HL, MP@ML (SD)

Audio

MPEG Layer 1 and 2

Sampling frequencies
supported

32 kHz, 44.1 kHz or 48 kHz

Output can be programmed as STEREO, LEFT only or
RIGHT only (on both outputs). This is useful for dual mono
channelsin order to select the correct sound track, which is
stored for every channel.

Wide dynamic range 16-bit resolution

Remote Control

Operating distance 7m max.
Batteries 2 x 1.5V micro (R-03/AAA)

Tuners

1 x RF In IEC-type, female (75Ohm)
1 x RF Out (loop through) IEC-type, male (75Ohm)

Hard Disk

Hard disk capacity 320 GB, 500 GB, 1 TB

Front Panel

Display Seven segment display
Remote control keys On / Off, Down, Up

Other information

Helpful technical information

Other information 47

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Audio

Output

2 Vrms,
0 dBfs / Z = 10 kohm

Digital Audio

Output Optical SPDIF

A/V & Data In/Out

Scart TV scart
RGB Video Output TV scart
Analog Audio Output TV scart
Digital Audio Output Optical output

File Extensions Supported By The Media
Browser

Media Extension

Picture jpeg, jpg, jpe, jfif
Video ts, avi, mp4, wmv, mkv
Audio mp3
Subtitle srt, sub

Fig 51.

This page is left intentionally blank

Product support

7

Product support50

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Product support

Help is always at hand

Troubleshooting

The LED indicator does not glow

Power Adaptor is not connected or low power is disabled.

Check that the AC adaptor is plugged into the power socket and the set-top box is in low power standby mode.
Low power setting can be modified under the configuration menu.

No picture or sound

No signal or weak signal.

Changes in the settings have not taken e ect

The set top box was unplugged without first switching to standby mode.

Make sure that the box is in standby mode before unplugging it from the mains.

The remote control is not working

• The set top box is in standby. Press the STANDBY button.

• Remote control is out of range. Check that the remote control range is clear.

• The batteries are exhausted. Replace the batteries with new ones.

Product support 51

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Product support

Help is always at hand

OSD Warning Messages

No Signal

When the box receives no signal (e.g. the antenna cable is disconnected), NO DIGITAL SIGNAL AVAILABLE
message will be displayed on the screen.

No Channels Have Been Added Yet

When there are no channels stored in the box, Channel List menu will not be displayed and channel navigation will
not be available.

In such cases, the following error message will be displayed.

Fig 52.

Fig 53.

Product support52

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Product support

Help is always at hand

Hard Disk

Recording Format

HDD recording is done using the variable bit rate format (VBR) for more efficient recording. The following
phenomena may occur.

With the variable bit rate format, the remaining amount which can be recorded may increase or decrease relative
to the display of the remaining amount of HDD space.

When the display indicates that the remaining amount of HDD space is low, first delete unnecessary programmes,
and then record with an extra margin in the amount of remaining space. There is an option in the configuration
menu to discard the recordings.

You can choose between three options:

Deleting:

1 – Oldest recordings

2 – Largest recordings

3 – Shortest recordings

When the HDD is out of space, it will operate regarding one of these options and delete the recordings.

Even if you delete a programme, the remaining amount may not increase by the amount of deleted time. When
recording new video, record with an extra margin in the amount of remaining space.

Unrecordable Material

In the unlikely event that there is some problem like loss of recorded video or audio content due to an HDD
malfunction, please be aware beforehand that we will bear no responsibility to compensate for the content which
could not be recorded or edited, for the loss of recorded or edited video, or for other related direct or indirect
damages.

If a power failure occurs

• The content being recorded or timer recorded may be damaged if power failure occurs.

• The content being played back may be damaged.

Hard Disk Operation (Recording / Playback / Time Shift Recording)

If the Recorder is used in a cold location (a location at low temperature), the drive will only allow live viewing
after power is turned on until the HDD is ready. During this time, the Recorder will not allow Time Shift Viewing,
recording, display of recording lists or playback of recorded programmes. Please wait until the HDD is ready.

Product support 53

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Product support

Help is always at hand

Help and assistance

If you require any technical guidance or find that your set-top box is not operating as intended, a simple solution
can often be found in the Troubleshooting section of these instructions or online at www.argos-support.co.uk

If you still require further assistance, call one of our experts on 0345 604 0105*. To help give us give you a fast and
efficient service please have the following information ready:

Model Ref.

Serial number

Date of purchase

Local call rates applies*

Lines open 8am-7pm Monday to Saturday and 10am-4pm Sunday.

*Calls to Argos enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tari . Mobile and other
providers costs may vary, see www.bt.com/pricing for details.

For security and training purposes, telephone calls to and from customer service centres may be recorded and monitored. Calls from
Republic of Ireland will attract international call charges.

You can find these on
the rating plate - a small
information panel (usually
a sticker or metal plate) on
the rear of your TV

This will be shown on
your receipt

Product support

Help is always at hand

Product support54

If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Disposal

Instructions for waste disposal:

• Packaging and packaging aids are recyclable and
should principally be recycled. Packaging materials,
such as foil bags, must be kept away from children.

• Batteries, including those which are heavy metal­free, should not be disposed of with household
waste. Please dispose of used batteries in an
environmentally friendly manner. Find out about the
legal regulations which apply in your area.

• Don’t try to recharge batteries. Danger of explosion.

• Replace batteries only with the same or equivalent
type.

Information for Users in European Union
Countries

• The mark shown on the right is in
compliance with the Waste Electrical and
Electronic Equipment Directive 2012/19/
EU (WEEE).

• The mark indicates the requirement NOT to dispose
the equipment including any spent or discarded
batteries as unsorted municipal waste, but use
the return and collection systems available. If
the batteries or accumulators included with this
equipment display the chemical symbol Hg, Cd, or
Pb, then it means that the battery has a heavy metal
content of more than 0.0005% Mercury, or more
than 0.002% Cadmium or more than, 0.004% Lead.

Product support

Help is always at hand

Product support 55

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.

Your Bush Guarantee

This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to
faulty materials or workmanship will be repaired free of charge (or if applicable the product will be replaced or the
purchase price refunded) where possible during this period by the dealer from who your purchased the unit.

Call us now and activate your 12 month guarantee

Thank you for choosing Bush. Your new product is guaranteed against faults and
breakdowns for 12 months. Don’t forget to register it with us today so we can provide you
with our best possible after-sales service and useful updates.

www.bushregistration.co.uk

FREEPHONE*

0800 597 8548

Lines are open 8am - 8pm, 365 days a year. *Calls may be recorded and monitored.

The guarantee is subject to the following provisions:

• The guarantee does not cover accidental damage,
misuse, cabinet parts, knobs or consumable items.

• The product must be correctly installed and
operated in accordance with the instructions
contained in the manual.

• It must be used solely for domestic purposes. The
guarantee will be rendered invalid if the product is

re-sold or has been damaged by inexpert repair.

• Specifications are subject to change without notice.

• Bush disclaim any liability for loss or damage arising
from the breakdown of the product.

• This guarantee is in addition to and does not
diminish your statutory or legal rights.

Important Data Protection Information

If you provide us with information about another
person, you confirm that they have appointed you
to act for them, to consent to the processing of their
personal data including sensitive personal data and
that you have informed them of our identity and the
purposes (as set out in the Important Data Privacy
notice displayed overleaf) for which their personal data
will be processed.

You are entitled to ask for a copy of the information
we hold about you (for which we may charge a small
fee) and to have any inaccuracies in your information
corrected.

For quality control and training purposes, we may
monitor or record your communications with us.

If your personal details change, if you change your
mind about any of your marketing preferences or if you
have any queries about how we use your information,
please let us know by contacting our Data Protection

Officer, Domestic & General, Leicester House

17 Leicester Street, Bedworth, Warwickshire
CV12 8JP.

Guarantor: Argos Limited - 489 - 499 Avebury Blvd. - Milton Keynes - MK9 2NW

Contact:

www.argos-support.co.uk

Helpline: 0345 604 0105
