Assembly Instructions - Please keep for future reference
499/5520
459/9342
462/9762
Dimensions
Width - 90cm
Depth - 55cm
Height - 190cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800.
For further assistance please visit http://www.argos-support.co.uk/
Issue 1 - 31/10/14
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
·Check you have all the
components and tools listed on
pages 2, 3 and 4.
·Remove all fittings from the
plastic bags and separate them
into their groups.
·Keep children and animals
away from the work area, small
parts could choke if swallowed.
·Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
·Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
·Do not stand or put weight on
the product, this could cause
damage.
·Assemble the item as close to
its final position (in the same
room) as possible.
·Assemble on a soft level
surface to avoid damaging the
unit or your floor.
·Parts of the assembly will be
easier with 2 people.
·From time to time check that
there are no loose screws on
this unit.
·To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torgue
setting.
·This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Handy Hints
·Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
·Regularly check and ensure
that all bolts and fittings are
tightend properly.
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
Components - Panels
Please check you have all the panels listed below
1
Top plinth bar× 1 (95.6 × 17cm)
Top × 1 (80.6 × 50.2cm)
2
If you have damaged or missing componets, call the
Customer Helpline:03456 400800.For further
assistance please visit http://www.argos-support.co.uk/
Side plinch bar × 2 (52.1 × 5.6cm)
3
Shelf × 1 (95 × 55cm)
6
Left Side, top × 1
4
(142.3× 52cm)
Left Side, bottom × 1
7
(52 × 18.6cm)
Right Side, top × 1
5
(142.3 × 52cm)
Right Side, bottom × 1
8
(52 × 18.6cm)
Base frame× 1 (95 × 55cm)
9
Leg × 4 (20 × 5.6cm)
10
2
Components - Panels
Please check you have all the panels listed below
Door,left × 1
11
(132.6 × 39.9cm)
Drawer front × 1 (80.2 × 18cm)
14
Drawer back × 1 (75.7 × 11.7cm)
17
Door,right × 1
12
(132.6 × 39.9cm)
Drawer side, left × 1
15
(40 × 12cm)
Drawer base × 1 (76.8 × 39.9cm)
18
Back panel, top × 2
13
(136.5 × 40.7cm)
Drawer side, right × 1
16
(40 × 12cm)
Support rail (38.8 × 5.7cm)
19
Back Rail× 1 (80.6 × 6.8cm)
20
3
Back panel, bottom × 1 (81.7× 19.7cm)
21
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
Wooden dowel × 21Large locking pin × 20
Ø6×40mmScrew × 8
G
JK
Ø3.5×25mm
Screw × 7
Hanger rail
support × 2
B
HI
MN
Door hinge × 6
P
Ø5×22mm
Screw × 4
S
Allen key × 1
Q
TU
Cross plate × 6
Ø6×84mm
Locking pin× 6
Back panel
support × 1
Ø3.5×30mm
Screw × 8
Small locking
pin × 5
C
FED
Large locking
nut × 32
Ø3.5×15mm
Screw × 54
Small locking
nut × 5
L
washer× 9washer× 8
O
Handle × 4
R
Wall strap
× 1
400mm Runner,
outside left × 1
V
YZ
400mm Runner,
outside right × 1
Plastic bar
× 1
L=1352mm
W
Hanger rail
× 1
L=797mm
400mm Runner,
inside left × 1
Tools required
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Ruler - Use this ruler to help correctly identify the screws
0101520253035404550556065707580859095100
5
105
X
Ø3.0×15mm
Screw for Back
panel × 4
110115120125130135140145150155160165170
400mm Runner,
inside right × 1
Rubber
mallet
4
Assembly Instructions
Step 1
Fitting dowels
a: Insert Wooden
dowels into Top Left
sides and Top Right
side.
A
4
5
b: Insert Large locking
B
Pin into Top Left sides
4
and Top Right side
.
5
Note: Insert locking pin
as shown.
Do not over tighten.
c: Fixing Hanger rail
support and Cross
plate to Top Left sides
and Top Right side
5
4
by using screws .
J
N
F
b:
55
B
B
B
Step 2
Fitting dowels
Insert Wooden dowel
B
into Support rail
.
19
5
N
Assembly Instructions
Step 3
Fitting dowels and
Locking nuts
Insert Wooden dowel
to Top .
2
A
Insert Large locking pin
to Top Plinth .
1
Note: Insert locking pin
as shown.
Do not over tighten.
Step 4
Attach Top Plinth to
Top panel .
2
Insert Large locking nuts
into Top panel as
shown on picture.
Use a screwdriver to turn
Locking nuts
clockwise to lock.
1
2
C
B
123
C
B
C
Step 5
Attaching sides
Two people are needed
here.
Attach Top panel
and Back Rail onto
the Top sides and
.
Insert Large locking nuts
C
as show on picture
shown.
Use a screwdriver to turn
locking nuts clockwise
to lock.
2
20
45
C
6
Assembly Instructions
Step 6
Fitting Top Side Plinth
Insert Large locking Nut
C
into Top panel as
shown on picture.
Use a screwdriver to turn
Locking nuts
clockwise to lock.
Attach Top Side Plinth
to the Sides as show on
picture and fix by Screw
.
E
2
C
123
C
B
3
Step 7
Fixing back panel
Join 2 back panels by
Plastic bar , then slip
Y
the back panels into the
groves on the sides.
Fix the back panels by
using screws as show
on picture.
FixWallStrap by Back
panel support Washer
and Screw .
K
13
AA
R
T
G
7
Assembly Instructions
Step 8
Fitting dowels
a: Insert Wooden
dowels A into Sides,
bottom and .
A
7
8
b: Fixing Runner
outside left to
Side bottom left
U
7
and Runner outside
right to Side
bottom right by
V
Screw .
F
8
Step 9
Fixing legs
Attach Legs to the
Base frame and fix by
Screw Washer and
and use Allen key turn
clockwise to fix.
10
9
D
L
S
F
V
V
U
F
K
F
U
F
8
Assembly Instructions
Step 10
Insert Large locking pin
to Bottom fram .
Note: Insert locking pin
as shown.
Do not over tighten.
Attaching Shelf and
Bottom Sides
B
B
123
C
B
Attach Shelf and
bottom Sides & to
the top unit by Locking
Q
Pin . Insert Large
Locking Nut as shown
on picture and use a
screw driver turn locking
C
nut clockwise to fix.
C
9
Assembly Instructions
Step 12
Insert bottom back
panel
Slip the bottom Back
panel into the groves
on bottom Sides.
Step 13
Fixing Base frame
Attach base frame to the
unit as show on picture.
Insert Large locking nuts
C
as show on picture
and use a screwdriver to
turn locking nuts
clockwise to lock.
Assembly Instructions
Step 14
Attach hanging rail
Lift the wardrobe unit up
and then attach the
Hanging rail as show
on picture.
Z
Step 15
a. Fixing hinges
Fix door Hings to the
Doors & by Screw
.
F
b. Fixing handles
Fix Handles to the
Doors & by Screw
.
P
M
O
11
Assembly Instructions
Step 16
Assembly doors
a. With help, slot Door
hinges onto Cross
Plate .
b. Tighten screw as
shown to lock hinges in
position.
M
N
Step 17
Adjust the doors up or
down a little bit to make
sure the doors can close
well.
Fix each Cross plate
by another 2 Screws
as show in picture to
finally fixing the doors.
N
F
12
Assembly Instructions
Step 18
Drawer assembly
a: Insert Small locking
H
pin into holes shown
on back of Drawer front
14
.
Note: Insert Locking pin
as far as shown.
Do not over tighten.
b:Fix Drawer sides
16
and and Support rail
19
to Drawer front
.
14
Insert Small locking nuts
into Drawer sides
I
& .
16
Use a screwdriver to turn
locking nuts clockwise
to lock.
I
c: Slip Drawer base
into grooves on Drawer
sides.
15
15
18
c:
b:
d:
G
× 6
d: Position Drawer back
to sides and fix by
17
using Screws .
G
e:Fix Handles onto
Drawer front by using
Screw .
14
P
f: Fix Runner inside left
and Runner inside right
onto the drawer sides of
by using Screws .
F
W
X
f:
13
Assembly Instructions
Step 19
Inserting Drawers
Carefully put in the
drawer.
Fixing to wall
It is recommended that
the Wardrobe is fixed to
a wall.
With help, move
Wardrobe into position.
Mark fixing hole on wall
and remove Wardrobe.
Drill hole and insert
wall plug.
Warning:
The Wardrobe
is heavy.
Lift with care
Reposition Wardrobe
and fix wall strap using
washer and screw.
Warning:
Before drilling,
check wall for
hidden pipes
and cables.
Assembly is finished.
Note: wall plugs are not
supplied.
The correct type of fixing must
be used for your wall, seek
professional advice in doubt.
14
A Guide to - Wall Mounting & Fixings
Important note:
If plastic wall plugs
are supplied with your
product:
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect xings is the
responsibility of the installer.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
Hints:
1:General rule:Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well tted and are a tight t in the
drilled hole.
Types of walls
No.1 “General Purpose” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist tting in this case. For light
loads, general purpose wall plugs can
be used.
No.2 “Plasterboard” wall plug
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
No.3 “Cavity Fixing” wall plug
For use with plasterboard partitions or
hollow wooden doors.
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
For use with walls stuck with
plasterboard. The hammer xing allows
it to be xed to the wall rather than the
plasterboard. Always check the xing
is secure to the retaining wall.
No.6 “Shield Anchor” wall plug
Heavy loads
For use when attaching light loads on
to plasterboard partitions.
Care &
Maintenance
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
Revision 2 - 7/10/09
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
