Sophia 5 Drawer Chest
Assembly Instructions - Please keep for future reference
496/6834
459/4127
483/9019
Dimensions
Width - 80cm
Depth - 41.5cm
Height - 115.6cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800.
For further assistance please visit http://www.argos-support.co.uk/.
Issue 1 - 05/05/16
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
·Check you have all the
components and tools listed on
pages 2 and 3.
·Remove all fittings from the
plastic bags and separate them
into their groups.
·During assembly keep children
and animals away from the work
area due to possible risk of injury
and small parts could choke if
swallowed.
Care and maintenance
·Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
·Do not stand or put weight on
the product, this could cause
damage.
·Assemble the item as close to
its final position (in the same
room) as possible.
·Assemble on a soft level
surface to avoid damaging the
unit or your floor.
·Parts of the assembly will be
easier with 2 people.
·From time to time check that
there are no loose screws on
this unit.
·To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torgue
setting.
·This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Handy Hints
·Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
·Regularly check and ensure
that all bolts and fittings are
tightend properly.
1
If you have damaged or missing componets, call the
Components - Panels
Customer Helpline:03456 400800.For further
assistance please visit http://www.argos-support.co.uk/
Please check you have all the panels listed below
Left Side × 1 (92 × 38.6cm) Right Side × 1 (92 × 38.6cm)
Top × 1 (80× 41.5cm)
1
Base frame × 1 (80 × 41.5cm)
4
Drawer side, left × 5 (30 × 12cm)
7 9
2
Leg × 4 (20 × 4.5cm)
5
8
Drawer side, right ×5 (30 × 12cm)
3
Drawer front × 5 (65 × 18cm)
6
Drawer back × 5 (60.5 × 11.7cm)
10
Drawer base × 5 (61.6 × 29.9cm)
13
Top rail × 1 (65.4 × 2.4cm)
11
Drawer support rail x 5
(28.8 × 5.7cm)
14
Central rail x 2 (65.4 × 6.8cm)
Back panel × 2 (93.1 × 33.1cm)
12
2
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
Wooden dowel
× 12
Ø3.5×25mm
Screw × 32
G
J K
M N
P
Allen key × 1
300mm Runner,
outside left × 5
300mm Runner,
inside right × 5
Q
washer× 4
B
Large locking
pin × 18
Small locking
pin × 25
H I
Handle × 10
300mm Runner,
outside right × 5
Ø3.5×15mm
Screw × 70
Ø6×40mm
Screw × 4
C
Large locking
nut × 18
FED
Small locking nut
× 25
D5/32''×7/8''
Screw × 10
L
300mm Runner,
inside left × 5
O
Washer × 6
R
Ø3.5×30mm
Screw × 2
S
Back panel
support × 2
T U
Ø3.0×15mm
Screw × 4
V
H shape plastic
bar × 1
Tools required
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Ruler - Use this ruler to help correctly identify the screws
0 101520253035404550556065707580859095100
5
105
Wall strap × 2
Rubber
mallet
110115120125130135140145150155160165170
3
Assembly Instructions
Step 1
a:Insert Wooden dowels
A
into Left side and
Right side .
b: Fix Runner Outside
J
Left onto Left side
by using Screws .
c: Fix Runner Outside
K
Right onto Right side
by using Screws .
2
3
2
N
3
N
2
d: Insert Large locking
B
Pin into Left side
and Right side .
2
3
Note: Insert locking pin
as shown.
Do not over tighten.
Fitting dowels
Insert Wooden dowels
A
into Central rail .
14
Repeat this step to
another Central rail .
14
3
14
4
Assembly Instructions
Step 3
Fitting locking pins
Insert Large locking Pin
into Top .
1
Note: Insert locking pin
as shown.
Do not over tighten.
B
B ×6
Step 4
Fixing legs to Base
frame
Fixing Legs to Base
Fram by using Screw
Washer & and
turn Allen Key clock
wise to fix.
Repeat this step to
fixing another 3 legs.
5
4
×4
O
5
G
5
5
4
5
5
Assembly Instructions
Fitting locking pins
Fitting Locking pins to
Base Fram .
Note: Insert locking pin
as shown.
Do not over tighten.
4
4
Step 6
2
3
13
14
13
C
3
14
14
×6
C
2
C
6
Assembly Instructions
Step 7
Attach the Sides unit to
Base frame .
4
Insert Large locking nut
to the sides as show on
picture.
Use screw driver turn
locking nut clockwise
C
to lock.
Step 8
C
3
2
×6
C
4
Insert back panel
Connect 2 Back panels
by H shape plastic bar ,
12
V
then Slip the Back panels
to the groves on the Sides.
V
12
12
7
Assembly Instructions
Step 9
Attaching Top
Attach Top to the
1
unit.
Insert Locking Nuts
C
to the Sides where
shown and use a screw
driver to turn locking nuts
C
clockwise to lock.
1
C
R ×2
×6
C
Step 10
Fix Back panel:
Fix Back panel onto
the unit by using Screws
.
T
Fix Wall straps
Fix Wall Straps by
Back panel support
Washer and Screw
O
.
12
U
S
×2
D
×2
O
U
×2
S
×2
×4
T
12
D
12
8
Assembly Instructions
Step 11
Drawer assembly
a: Insert Small locking
pin into holes shown
on back of Drawer front
6
.
Note: Insert Locking pin
as shown.
Do not over tighten.
b: Attach Drawer sides
8
and Drawer support
11
rail to Drawer front
6
.
Insert Small locking nuts
into Drawer Sides
and Drawer support rail .
Use a screw driver to
turn locking nuts
clockwise to lock.
b
a
6
7
7
c
d
D
9
c: Slip Drawer base into
grooves on Drawer
sides.
d: Fix Drawer back
onto sides by using 6
Screws .
e: Fix Runners inside left
L
and Runner inside
right to the underside
of Drawer sides by using
Screws .
f: Fix Handles to the
Drawer front by using
Screw .
D
M
N
10
9
H
e
N
×6
M
f
L
H
Repeat a - f to finish
another 4 drawers.
9
Assembly Instructions
Step 12
Insert drawers
Carefully put in
drawers.
Step 13
Fixing to wall
The Chest should be
fixed to a wall.
Move Chest into position.
Mark fixing holes on wall
and remove chest.
Drill holes and insert
wall plugs.
Warning:
Before drilling,
check wall for
hidden pipes
and cables.
Reposition Chest and fix
wall straps using screws.
Assembly is finished.
If you need help or have damaged or missing parts,call the Customer Helpline: 03456 400800
Retailer: Argos
Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9,2NW
For further assistance please visit http://www.argos-support.co.uk/
10
A Guide to - Wall Mounting & Fixings
Important note:
If plastic wall plugs
are supplied with your
product:
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect xings is the
responsibility of the installer.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well tted and are a tight t in the
drilled hole.
Types of walls
No.1 “General Purpose” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist tting in this case. For light
loads, general purpose wall plugs can
be used.
No.2 “Plasterboard” wall plug
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
No.3 “Cavity Fixing” wall plug
For use with plasterboard partitions or
hollow wooden doors.
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
For use with walls stuck with
plasterboard. The hammer xing allows
it to be xed to the wall rather than the
plasterboard. Always check the xing
is secure to the retaining wall.
No.6 “Shield Anchor” wall plug
Heavy loads
For use when attaching light loads on
to plasterboard partitions.
Care &
Maintenance
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
Revision 2 - 7/10/09
