Chrome Tidy Rail
Assembly Instructions
Please keep for future reference
-
8757049
Dimensions
Width - 84.5cm
Depth - 42.5cm
Height - 99.5/167cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 08456 400800
Page 2
Safety and care advice
Important - Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them into
their groups.
• Keep children and animals away
from the work area, small parts
could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Assemble the unit as close to its
final position (in the same
room) as possible.
• Assemble on a soft level surface
to avoid damaging the unit or your
floor.
• Parts of the assembly will be
easier with 2 people.
• If using power tools, please
follow the safety instructions
supplied with the tools.
• We do not
recommend the use
of power drill/ drivers
for inserting screws,
as this could damage
the unit. Only use hand
• Dispose of all packaging carefully
and responsibly.
screwdrivers.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
1
• From time to time check that
there are no loose screws on this
unit.
• This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
Note: if required the next page
can be cut out and used as a
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
Page 3
Components - Parts
Please check you have all the panels listed below
Rail x 1 (84cm)
1
Bottom Tube x 2
2
Lower Side Support x 2
3
Upper Side Support x 2
4
(78cm)
(86cm)
(78cm)
5
Foot x 2
(42cm)
Castor x 4
6
2
Page 4
Components - Fittings
If you have damaged or missing components,
call the Customer Helpline: 08456 400800
Please check you have all the fittings listed below
The quantities below are the correct amount to complete the assembly. In some cases more fittings
Note:
may be supplied than are required.
A B
Connector x 2 Lock x 2
Tools required
Small
hammer
Ruler - Use this ruler to help correctly identify the screws
105
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
3
Page 5
Assembly Instructions
Step 1
Fitting the Feet
NOTE: It would be useful to ask
someone to help you at this stage.
5
a:
a:
Insert Bottom Tubes into Feet
5
5 .
2
b:
2
2
5
b:
Insert Lower Side Supports
into Feet .
5
3
3
5
3
5
4
Page 6
Assembly Instructions
Step 2
a:
Fitting the Rail
NOTE: It would be useful to ask
someone to help you at this stage.
a: Insert Rail
A .
A
b: Insert Upper Side Supports
into
Connectors .
1
into Connectors
A
4
A
b:
1
A A
4
A
4
c: Insert Castors 6 into Feet
5
5 .
5
6
c:
5
6
5
6
Page 7
Assembly Instructions
Step 3
Finishing the Unit
NOTE: It would be useful to ask
someone to help you at this stage.
a: Insert Locks B onto the Top
of Lower Side Support . . Align
the Screw on Lock
B
3
into the
B
hole on Lower Side Support .
Insert Upper Side Support
into the
Locks .
B
4
b: Set the height of the unit
using the Upper Side Support .
Ensuring the Locks
loosened, slide the tubes to the
desired height and tighten the
Locks to fix in position.
Adjustment Range: 99.5-167cm.
B
B are
4
a:
B
B
3
3
3
b:
Note:Please hold Upper Side
Support and pull dowmward. It
will be fixed if locked or will
be glided downward if unlocked.
c: With help, place the unit in
the intended position.
The assembly is now complete.
If you need help or have damaged or missing parts, call the
Customer Helpline: 08456 400800
6
