Argos 8559A-101, 8559A-130, 8559A-132 ASSEMBLY INSTRUCTIONS

Osaka 3 Drawer Chest
Assembly Instructions - Please keep for future reference
White 2283935
Black 2487865
Dimensions
:
Width
Height
40.0 cm
:
40.0 cm
:
59.6 cm
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Argos Customer Helpline: 0845 640 30 30
350266
Issue 1 - 15-05-2014
Safety and Care Advice
!
Important - Please read these instructions fully before starting assembly
• Check you have all the components and tools listed on pages 2 and 3.
• Remove all fittings from the plastic bags and separate them into their groups.
• Keep children and animals away from the work area, small parts could choke if swallowed.
• Make sure you have enough space to layout the parts before starting.
Care and maintenance
• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
• Do not stand or put weight on the product, this could cause damage.
• Assemble the item as close to its final position (in the same room) as possible.
• Assemble on a soft level surface to avoid damaging the unit or your floor.
• Parts of the assembly will be easier with 2 people.
• From time to time check that there are no loose screws on this unit.
• We do not recommend the use of power drill/drivers for inserting screws, as this could damage the unit. Only use hand screwdrivers.
• Dispose of all packaging carefully and responsibly
• This product should not be discarded with household waste. Take to your local authority waste disposal centre.
.
Note: if required the next page can be cut out and used as reference throughout the assembly. Keep this page with these instructions for future reference.
1
If you have damaged or missing components, call
Components - Panels
the Argos Customer Helpline: 0845 640 30 30
Please check you have all the panels listed below
Top
1
(40 cm x 40 cm)
5
Front rail
(28,2 cm x 6 cm)
6
Back rail
(28,2 cm x 7 cm)
2
Side, left
(51,1 cm x 35 cm)
7
Back
(47,3 cm x 31,5 cm)
3
Side, right
(51,1 cm x 35 cm)
8
Drawer front
(27,6 cm x 15,7 cm)
10
Drawer side, right/left
(35 cm x 9,8 cm)
x
x
4
Post
(58,1 cm x 4,4 cm)
4
9
Drawer front
(27,6 cm x 12,5 cm)
2
x
3
x
Drawer back
11
(24,9 cm x 9,8 cm)
6
350266-03
Drawer bottom
12
(25,9 cm x 34,7 cm)
x
3
2
