Argos 833/4448 User guide

Hygena Insert Tallboy

833/4448

35cm 30cm

170cm

Issue 1 - 4/19/13

Components - Panels

Please check you have all the panels listed below

If you have damaged or missing components, call the Customer Helpline:08456 400800

1

Under left side panel

4

Top panel

2

Under right side panel

5

Bottom panel

3

Under back panel

Adjustable shelf x 2

6

9

Shelf x 2

Door panel

7

11

Upper left side panel

2

8

Upper back panel

12

Upper right side panel

10

Back rail

13

Middle fixed shelf

Components - Fittings

Please check you have all the fittings listed below

Note:The quantities below are the correct amount to complete the assembly .In some cases more fittings may be supplied than are required.

A

Locking Pin x 20

D

Magnetic Catch x 1

G

Metal Support x 8

J

Back panel hook x 4

M

Wooden dowel x 8

B C

Locking Nut x 20

E

Strike Plate x 1

H

Hinge x 2

F

12mm Screw x 11

I

Metal handle x 1 18mm Bolt x 2

K

L

35mm Screw x 416mm Screw x 4

N

Wall plug(for solid

walls only) x 2

O

45mm Screw x 2

Tools

required

Phillips screwdriver (medium & large)

Flatblade screwdriver (medium)

Drill

0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 0 1 2 3 4 5 6

7mm Suitable drill bit (for use with wall plug)

Ruler - Use this ruler to help correctly identify the screws

105

0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100

110 115 120 125 130 135 140 145 150 155 160 165 170

Small hammer

Ruler/tape measure

Eye protection (when using a hammer or glue)

3

Assembly Instructions

Step 1

Assembling the upper unit

NOTE:It would be useful to ask someone to help you at this stage.

a:Screw locking pins into upper left side panel and upper right side panel .

Insert dowels into back rail .

11

12

M

Insert locking nuts into shelf .

9

Attach upper left side panel to right

side panel with shelf and back rail in the middle.

10

A

10

B

9

a:

12

B

A

B

9

B

9

10

A

B

A

B

A

11

A

M

Tighten the locking nuts to secure the unit.

b: Screw locking pins into the top panel .

4

Insert locking nuts into side panels and .

11

Carefully attach top panel to

A

B

12

4

the unit,Pls make sure the grooves are aligned.

Tighten the locking nuts to secure the unit.

b:

M

A

11

B

9

12

9

B

Continued on next page

4

B

A

4

Assembly Instructions

Step 1 - continued

Assembling the upper unit

c:Carefully slide the upper back panel into the groove of the unit.

NOTE:Pls make sure the holes in the upper back panel match the back rail .

Insert dowels into upper side panel & ,attach middle fixed shelf to the upper side panels with 35 screws .

Screw locking pins into middle fixed shelf.

Use 12mm screws to fix magnetic catch on middle fixed shelf.

13

8

11

8

10

M

12

L

A

F

D

c:

L

A

L

A

M

12

F

13

A

8

D

M

11

A

F

D

Step 2

Assembling bottom panel

NOTE:It would be useful to ask someone to help you at this stage.

Screw locking pins into under side panel & .

1

Insert locking nuts into bottom panel .

5

Carefully attach bottom panel to under side panels. Pls make sure the grooves are aligned.

A

2

B

A

2

B

1

B

Tighten the locking nuts to secure the unit.

5

A

5

A

B

A

B

Assembly Instructions

Step 3

Assembling the unit.

NOTE:It would be useful to ask someone to help you at this stage.

a:Carefully slide under back panel

3

into the under unit.

a:

b:

4

J

Insert locking nuts into under lelf side panel and right side panel .

2

B

1

Attach the upper unit onto the under unit , tighten the locking nuts

B

to secure the unit.

b:Insert back panel hook into the groove of under side panel and use 16mm screw to fix back

J

122

K

panel hook to the under unit.

K

J

3

B

J

K

1

K

J

B

6

Assembly Instructions

Step 4

Assembling door panel

NOTE:It would be useful to ask someone to help you at this stage.

a:Use 12mm screw to fix strike

plate onto the door panel .

E

F

7

a:

F

H

E

Use 18mm bolts to fix metal handle onto door panel.

H

Use 12mm screws to fix hinges

C

onto the door panel.

I

F

I

F

C

b:

7

C

F

b:Attach door panel onto the

unit by fixing hinge with screw .

7

C

F

7

F

C

F

7

Assembly Instructions

A

Step 5

Fixing to the wall

NOTE:It would be useful to ask someone to help you at this stage.

Use 45mm screws and wall

plugs to fix the unit on the wall.

J

N

O

N

O

Step 6

Assembling adjustable shelf panel

NOTE:It would be useful to ask someone to help you at this stage.

Insert metal supports into side

panels .

Carefully put the adjustable shelf panel on it.

NOTE: Please make sure the unit is secure before use.

G

2

1

22

6

G

6

G

6

The assembly is now complete.

8

NOTE:If you have damaged or missing components, call the Customer Helpline:08456 400800

Argos LTD,489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW

A Guide to - Wall Mounting & Fixings

Important note:

If plastic wall plugs are supplied with your product:

- these are only suitable for use in masonry walls.

If you are in any doubt about the correct wall plugs for your wall, seek professional advice.

Failure of the product due to using incorrect xings is the responsibility of the installer.

Important: When drilling into walls always

check that there are no hidden wires or pipes etc.

Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualiﬁed tradesperson if you are unsure.

Hints:

1: General rule: Always use a larger screw and wall plug

if you are not sure.

2: Ensure you use the recommended drill bit to match the wall

plug and hole size.

3: Ensure you drill the hole horizontally, do not force the drill or

enlarge the hole.

4: Take extra care when drilling high walls, ceilings and ceramic

tiles. Ensure wall plugs are inserted beyond the thickness of the ceramic tiles to avoid the tiles splitting or cracking.

5: Ensure wall plugs are well tted and are a tight t in the

drilled hole.

Types of walls

No.1 “General Purpose” wall plug

Generally aerated blocks should not be used to support heavy loads, use a specialist tting in this case. For light loads, general purpose wall plugs can be used.

No.2 “Plasterboard” wall plug

You can use one of the following types of wall plug if your walls are made of brick, breeze block, concrete, stone or wood.

No.3 “Cavity Fixing” wall plug

For use with plasterboard partitions or hollow wooden doors.

No.4 “Cavity Fixing-Heavy Duty”

wall plug

No.5 “Hammer Fixing” wall plug

For use with walls stuck with plasterboard. The hammer xing allows it to be xed to the wall rather than the plasterboard. Always check the xing is secure to the retaining wall.

No.6 “Shield Anchor” wall plug

Heavy loads

For use when attaching light loads on to plasterboard partitions.

Care & Maintenance

For use when tting or supporting heavy loads such as shelving, wall cabinets and coat racks.

Safety: Always check the ﬁtting and location to ensure your safety in and around the home.

For use with heavier loads such as TV & HiFi speakers and satelite dishes etc.

Fitting: From time to time check the ﬁtting to ensure the wall plugs or screws do not become loose.

Revision 2 - 7/10/09

SAFETY WARNING INFORMATION BS7449 : 1991

y

Keep these instructions for future use: Catalogue Number: 833/4448(D)

Manufacture date: Apr.8th.2013

Retailer: Argos

Retailer address: 489-499 Avebury Boulevard

Saxon Gate West Central Milton Keynes

WARNINGS Bucks, MK9 2NW

*Do not place very hot or very cold items against or in close proximity to glass surface unless an adequately This unit contains tempered glass of a nominal thick insulating material is used to prevent such items thickness of 4 mm, which is not required to be from coming into contact with the glass. classified to BS6206 Class C.

*Do not strike the glass with hard or pointed items.

* Do not sit or stand upon horizontal glass surfaces. If a glass is chipped or broken replace with *When cleaning glass panels or mirrors use a damp glass of the type described on this label. Consult the

or leather with washing up liquid or soft soap if necessar do not use washing powders or any other substance obtaining a manufacturing specification and shape for containing abrasive since these substances scratch glass. replacement glass quoting the model number, and batch

*It is essentail that this unit is fixed to a wall with the fixings provided.

manufacturer, retailer, or agent with regard to

number or date of manufacture.
