Under Basin Unit
Assembly Instructions- please keep for future reference
833/2763
Dimensions
Width - 48cm
Depth - 30cm
Height - 60 cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Issue 2 - 09/09/10
Page 2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 1 and 2.
• Remove all ttings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp
cloth and mild detergent, do
not use bleach or abrasive
cleaners.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its nal position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your oor.
• Parts of the assembly will be
easier with 2 people.
• From time to time check that
there are no loose screws on
this unit.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
Page 3
Components - Panels
Please check you have all the panels listed below
1
Top x 1
(48(w)cm x 30(d)cm)
4
Base x 1
(40(w)cm x 28(d)cm)
7
Right door x 1
(49.2(h)cm x 19.7(w)cm)
2
Left side x 1
(58.5(h)cm x 28.5(d)cm)
5
Bottom rail x 1
(6.9(h)cm x 40(w)cm)
8
Back panel x 2
(52(h)cm x 10(w)cm)
3
Right side x 1
(58.5(h)cm x 28.5(d)cm)
6
Left door x 1
(49.2(h)cm x 19.7(w)cm)
9
Internal shelf x 1
(42(w)cm x 25.6(d)cm)
1
Page 4
If you have damaged or missing components,
Components - Fittings
call the Customer Helpline: 0845 640 0800
Please check you have all the ttings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more ttings
may be supplied than are required.
A
35mm Male camlock x 8 Female camlock x 8 14mm Screw x 2 Magnetic catch x1
E
Back panel screw x 10 Wooden dowel x 5 Hinge x 4 Knob x 2
I
16mm Screw x 2 Catch plate x 2 10mm Screw x 2 Shelf bracket x 4
B
F
J
C
G
K
D
H
L
Tools required
Phillips screwdriver
(medium & large)
Ruler – Use this ruler to help correctly identify the screws
105
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
Assembly Instructions
Step 1
Screw 4 x 35mm male
camlock
underside of the top
panel
Connect the magnetic
catch
screw
A
into the
1
as shown.
D
using 2 x 14mm
C
.
A
1
D
C
2
Page 5
Additional Components
Please check you have all the ttings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more ttings
may be supplied than are required.
M
30mm Screw x 1 Rawl plug x 1 Safety strap x1 20mm Screw x 1
N
O
P
Tools required
Drill
(for wall drilling only)
Supplementary Assembly Instructions
Step 1
In order to prevent
accidental toppling it is
recommended to secure
the unit to a wall using
the supplied safety strap.
Connect safety strap
O
to rear of the unit as
shown using 1 x 20mm
screw
screw replaces the back
panel screw
in the main instructions).
P
(note: this
E
detailed
Step 2
Secure safety strap to
wall using 30mm screw
M
and rawl plug N as
shown.
Note: please refer to the
reverse of this instruction
sheet for additional wall
xing options.
Warning:
Before drilling,
check wall for
hidden pipes
and cables.
P
O
N
M
833/2763 • 833/2811
Page 6
Assembly Instructions
Step 2
Insert 4 x female
camlock
underside of base
B
into the
4
shown.
Step 3
Screw 2 x 35mm male
camlock
holes at the bottom of
the left side
side
A
into the
3
as shown.
2
and right
B
as
4
B
A
3
B
Insert 2 x female
camlock
B
into the
holes at the top of the
left side
side
2
and right
3
as shown.
Step 4
Insert 5 x wooden dowel
F
into the bottom rail 5
as shown.
A
2
F
5
3
Page 7
Assembly Instructions
Step 5
Connect bottom rail 5
to underside of base
as shown.
Step 6
Connect assembly
completed in Step 5 to
left side
2
as shown.
4
4
5
Tighten female camlocks
a:).
2
in underside of base
with a screwdriver (
Note: you should feel a
click when the camlocks
are secured.
Step 7
Connect right side 3 to
other end of assembly
completed in Step 5 as
shown.
Tighten female camlocks
in underside of base
with a screwdriver (see
Step 6
a:).
2
a:
2
3
Note: you should feel a
click when the camlocks
are secured.
Note: it may be helpful
to have assistance from
another person with this
stage.
4
2
Page 8
Assembly Instructions
Step 8
Connect knobs H to
doors
16mm screws
shown.
Connect catch plates
J
using 10mm screws
as shown.
Insert a hinge
top and bottom of doors
6
Note: it may be helpful
to have assistance from
another person with the
next stage.
Locate door hinges in
place in base as shown,
then connect the top
panel
top hinges of doors
slot into place (
tighten female camlocks
on inside of left and right
side with a screwdriver
(see Step 6
6
and 7 using
I
as
to doors 6 and 7
K
G
into the
7
and
as shown.
1
ensuring that
b:), and
a:).
J
1
K
7
6
H
H
I
G
b:
Note: you should feel a
click when the camlocks
are secured.
5
Page 9
Assembly Instructions
Step 9
Connect back panels
using 10 x back panel
screw E as shown.
8
8
8
E
Step 10
Insert 4 x shelf bracket
L
inside the unit at the
desired height as shown
and set internal shelf
in place.
Assembly complete.
9
L
9
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
LP 255.96.799
Page 10
A Guide to Wall Mounting & Fixings
Important note:
If plastic wall plugs (rawl plugs)
are supplied with your product,
e.g.:
- these are only suitable for use in
masonry walls.
If you are in any doubt about the
correct wall plugs for your wall,
seek professional advice.
Failure of the product due to
using the incorrect xings is the
responsibility of the installer.
Types of walls
Important: when drilling into walls always check
that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used are suitable for
supporting your unit. Consult a qualied tradesperson if you
are unsure.
Hints:
1: General rule:
not sure.
2: Ensure you use the recommended drill bit to match the wall plug and
hole size.
3: Ensure you drill the hole horizontally; do not force the drill or enlarge
the hole.
4: Take extra care when drilling high walls, ceilings and ceramic tiles.
Ensure wall plugs are inserted beyond the thickness of the ceramic
tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well tted and are a tight t in the
drilled hole.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
always use a larger screw and wall plug if you are
No.1 “General Purpose” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist tting in this case. For
light loads, general purpose
wall plugs can be used.
No.2 “ Plasterboard”
wall plug
No.3 “Cavity Fixing” wall plug
For use with plasterboard partitions
or hollow wooden doors.
No.4 “ Cavity Fixing – Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
For use with walls stuck with
plasterboard. The hammer xing
allows it to be xed to the wall
rather than the plasterboard.
Always check the xing is secure
to the retaining wall.
No.6 “ Shield Anchor” wall plug –
heavy loads
For use when attaching light loads
onto plasterboard partitions.
Care &
Maintenance
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
Safety: always check the tting and
location to ensure your safety in and
around the home.
For use with heavier loads such as
TV and HiFi speakers and satellite
dishes etc.
Fitting: from time to time check the
tting to ensure the wall plugs or
screws do not become loose.
