Page 1
ASHWELL
Spare Parts
www.argos-support.co.uk
0370 112 1928
Customer Support
0345 640 2020
Issue 1 - 22/05/20
Page 2
Safety and Care Advice
Product Details
806/3922 Ashwell 80x80cm table oak
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough space
to layout the parts before
starting.
• This product has been
constructed to be used in the
domestic environment only and
not for commercial purposes.
Care and maintenance
Only
and mild detergent.
abrasiv
product, furniture polish is
not recommended.
clean using a damp cloth
Do not use
e cleaners.
Use a dry cloth to clean the
Assemble the item as close
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit
• From time to time check that there
are no loose screws, nuts or bolts.
If there are please re-tighten.
We do not
recommend the
use of power
drill/drivers for
inserting screws
as this could damage the unit.
Only use hand screwdrivers.
Parts of the assembly will be
easier with 2 people.
Dispose of all packaging
carefully and responsibly.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
Additional Guidance
● Assemble all parts and bolts loosely during assembly, only once the product is complete should you
fully tighten the bolts.
Regularly check and ensure that all bolts and fittings are tightend properly .
●
●
This product is compliant BS EN 12521, FIRA 6250.
Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered
Sainsbury's plc.
2
Page 3
Fittings (Shown to scale)
Bag 1
A
M10x60mm Bolt x 8
C
Flat washer M10 x 8 S
B
Spring washer M10 x 8
D
panner x 1
3
Page 4
Tools required
Phillips screwdriver
(small & medium)
Phillips screwdriver
(small & medium)
Small
hammer
Large hammer
Ruler/tape
measure
Eye protection
(when using a
hammer or glue)
4
Page 5
Hardware
1
Table top (80x80 cm) x 1
2
Pt. No
Table leg (73.2x 6cm) x 4
Pt. No
5
Page 6
A
M10x60mm Bolt x 8
B
Spring washer M10 x 8
A
M10x60mm Bolt x 8
B
Spring washer M10 x 8
1
C
Flat washer M10 x 8 S
Repeat
x2
D
panner x 1
C
Flat washer M10 x 8 S
A
D
C
B
D
panner x 1
Pt. No
Rotate
Product
6
