argos 709/2925 User guide

Cuggl Elm Forward Facing Twin Pushchair

Assembly & User Instructions- Please keep for future reference

709/2925

Age:0 -36 mon ths
Maxim um user
Weigh t:15k g each
seat

Important-please read these instructions fully before assembly or use

These instructions contain important information which will help you get
the best from your product and ensure safe and correct assembly, use
and maintenance.
If you have any questions, call the Customer Helpline: 03456 400 800

Issue 2-15/ 09/ 17

Parts

If you have any questions,

Stroller x1

Rear wheel X 2

Front wheel X2

Axle X 1

canopy x1

Thank you for choosing our product. Please always read all the instructions provided
carefully before use and remember, your child's safety may be affected if you do not
follow these instructions. Front seat is suitable for baby of 6-36 months. Rear seat is
suitable from birth to 36 months. The maximum load of the pushchair is 30kg
(Maximum 15kg in each seat), never overload.

Pushchair was designed for two children, one children each seat.

Rear seat was designed to be used from birth, we recommend use of the most
reclined position for new born babies.

●WARNING: Front seat of the pushchair is not suitable for children under 6 months.

WARNING:

● Rear seat of the pushchair is suitable for children from birth to 36 months.

WARNING:

● Accessories which are not approved by the manufacturer shall not be used.

WARNING:

● Any load attached to the handle and/or on the back and/ or on the side will
affect the stability of the vehicle.

WARNING:

● Do not use if any part is broken, torn or missing.

WARNING:

● Never leave your children unattended.

WARNING:

● Avoid placing the stroller near naked heat sources such as electric bar fires,
gas fires, etc, or where a child could gain access to any other kinds of hazard.

WARNING:

● Always use the restraint system.

WARNING:

● Always use the harness provided and make sure the harness is correctly fitted.

WARNING:

● The maximum permissible loading for shopping basket is 2kg.

WARNING:

● Ensure all locking devices are engaged before use.

WARNING:

● This product is not suitable for running or skating.

WARNING:

● To avoid injury ensure that your child is kept away when unfolding and
folding this product.

WARNING:

● Do not let your child play with this product.

WARNING:

● The parking device shall be engaged when placing and removing the children.

WARNING:

● Only replacement parts supplied or recommended by the manufacturer/
distributor shall be used.

1

Name of parts

height adjuster button

fold button

rear canopy

handle bar

folding lock

front canopy

basket

rear wheel

footrest adjust button

front wheel

brake pedal

backrest

5-point harness

bumper bar

crotch belt

footrest

rear wheel

axle

2

To unfold the stroller

Release the folding lock, pull the
handle bar backwards until you
hear the “click”.

Front wheel assembly

1.Slide front wheel brackets into
front legs until you hear a click”

“

sound.

2.To remove the front wheels,
press the small button and pull
downwards.

Rear wheel assembly

Fit the wheel on the axle, place
the workpiece part 1 then part 2
then part 3.

To attach t he rear w heels , follo w this or der

3

Use and operation after assembly

To lock the front wheels

1.The front wheels must be turned
in the straight forward position,
then push the fixing lever upwards
until the button locks in place.

2.To release the wheels for free
swivel, push the fixing lever
downwards.

Use the brake

To lock the rear wheel brakes.

1.Press both brake pedals down
until they click” into the locked

“
position. Make sure the brake
pedals are pressed down
completely.

2.Always set both brake pedals
whenever you park the stroller.

To unlock the rear wheel brakes.
Lift both brake pedals until they
“click” into the unlocked position.

UN LOC K

LO CK

*M AKE S URE T O DO TO B OTH S IDE S

Adjust footrest

To adjust the footrest, pull the
footrest adjust button and adjust
the footrest to the correct position.

4

Use and operation after assembly

Use the safety belt

Use always the safety belt. Check
the belt regularly and adjust the
straps when your child is getting
bigger.

The rear seat is designed for a
child from birth to 36 months.
Always use the harness in
described manner when you use
the pushchair.

There are two adjustment positions
for the harness.

From birth to 6 months: Insert the
harness through the slots.

From 6 months: No need to insert
the harness through the slots.

Adjustment of the canopy

The canopy can be adjusted
freely into the desired position by
turning the front bar of the canopy.

To remove the canopy, press the
release buttons and pull outwards.

To install the canopy by inserting
the tip of the canopy to the canopy
holder until you hear a “click”
sound. The rear canopy can not be
detached.

5

Use and operation after assembly

Adjustable handle bar

1.Keep both release button pressed.

2.Turn the handle bar to the desired
position.

Adjust backrest

To lower the backrest position, lift
the backrest adjusting lever up
firmly and put the backrest into the
correct position.

To fold the stroller

1.Close both canopies and place
the two seats in sitting position.
The front canopy must be pushed
into the front of the pram.

2.Press the button below the left
latch and lift up simultaneously the
two black latches on each side of
the handlebar.

Switch forwards and the handlebars
will block the folded position with
the hook.

6

Care and Maintenance

● This pushchair was designed and manufactured with qualified materials

and craftsmanship. Always use the safety harness.

● Always check your pushchair for bullet points. Lubricate moving parts

regularly, especially the wheels, and lower parts of the chassis that tend
to collect dirt.

● Regularly inspect the locking devices, breaks, wheels, harness assembly,

catches, seat adjusters, joints and fixings to ensure they are secure and in
full working order. If there is something wrong, please change it.

● Should any of the above be evident do not use and contact the Helpline:

03456 400 800

To avoid risk of injury to your baby, please check and maintain the stroller

●

periodically. Fabric cover may be cleaned in accordance with the fabric
cover. Allow to dry naturally, ideally on a washing line. Do not iron any part
of the fabric cover.

Regularly inspect the locking devices, breaks, wheel, harness assembly,

●

catches, seat adjusters, joints and fixing to ensure they are secure and in
full working order. If there is something wrong, please change it. Please
assemble and detach it according to the instructions.

If you have any question,
call the Customer Helpline:03456 400 800
This pushchair has been designed to comply with the EN1888:2012.
Country of origin: China
Argos LTD, 489-499 Avebury Boulevard, Central Milton Keynes,MK9 2NW
