Dalton 4ft6 Frame
Assembly Instructions - Please keep for future reference 656/9631
758/4866
Dimensions
Width - 139.4cm
Depth - 202cm
Height - 90.6cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
Issue 1 - 25/06/10
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do not use
bleach or abrasive cleaners.
• As you unpack and prepare
for assembly, clear an area for
assembly. The parts should be
placed on a carpeted or padded
area to protect them from
damage.
• Parts of the assembly will be
easier with 2 or 3 people.
• Do not discard any of the
packaging until you have
checked that you have all the
parts and pack of fittings.
• From time to time check that
there are no loose screws on
this unit.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• To ensure an easier assembly,
we strongly advise that all
fittings are only finger tightened
druing initial assembly. Only
upon completion of the
assembly should all fixing points
be fully tightened.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
1
If you have damaged or missing components,
Components - Panels
call the Customer Helpline:
Please check you have all the panels listed below
0845 6400800
Left headboard post
1
(90.6 x 5cm)
Right footboard post
4
(53.1 x 5cm)
Side rail x 2
7
(192 x 9cm)
Right headboard post
2
(90.6 x 5cm)
Top horizontal bar x 2
5
(134.4 x 5cm)
Left footboard post
3
(53.1 x 5cm)
Middle horizontal bar x 4
6
(134.4 x 4cm)
Slat x 12
8
(137.2 x 3.2cm)
Slat x 4
9
(137.2 x 3.2cm)
Center support slat x 2
10
(86.7 x 1.8cm)
Leg x 4
11
(dia1.8 x 35 cm)
2
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
36mm Bolt x 24
D
Small plain washer x 4
G
Small hex key x 1
B
49mm Bolt x 4
E
Large plain washer x 8
H
Large hex key x 1
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
105
C
30mm Bolt x 8
F
Spring washer x 8
110 115 120 125 130 135 140 145 150 155 160 165 170
3
Assembly Instructions
Step 1
Assemble headboard
Assemble top horizontal
5
bar
horizontal bars
headboard post
right headboard post
using bolts
in the figure.
Note: Do not fully
tighten bolts.
and middle
6
1
A
as shown
to left
and
2
A
A
A
1
A
A
A
5
6
2
Step 2
Assemble footboard
Assemble top horizontal
5
bar
horizontal bars
footboard post
right footboard post
using bolts
in the figure.
Note: Do not fully
tighten bolts.
and middle
6
3
A
as shown
to left
and
4
A
A
A
4
5
6
A
A
A
3
4
Assembly Instructions
Step 3
Assemble side rails
Three people are needed
here.
Assemble side rails
7
to headboard frame and
footboard frame using
C
bolts
F
washers
, spring washers
and large plain
E
.
Note:Do not fully
tighten bolts.
7
7
E
F
C
E
F
C
Step 4
Assemble slats
Insert slats and to
8
the side rails.
9
9
8
8
8
8
8
8
9
9
8
8
8
8
8
8
9
5
Assembly Instructions
Step 5
Assemble center
support slats and legs.
Use bolts , small
plain washers
the support slats
and legs
slats
Note:
Re-tighten all the
bolts.
B
D
to fix
10
11
onto the
9
B
D
Assembly is complete.
11
9
9
9
10
11
10
11
11
9
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
