TC Facet Towel Rail
Assembly Instructions
– Please keep for future reference
634 / 4557 D
Warning: To prevent breakage - Do Not press on to the glass back plate too hard when
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
assembling.
Issue 1–06/10/16
Page 2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2.
• Remove all fittings from the
plastic bags and separate them
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• D
and responsibly.
•
Warning: To prevent breakage -
Do Not press on to the glass back
plate too hard when assembling.
into their groups.
Glass safety – Take care when handling glass, please follow the advice below
•
• If a glass component is
chipped or broken replace with
glass of the type described on
this instructions. Consult the
manufacturer, retailer or agent
with regard to obtaining a
manufacturing specification and
shape for replacement glass
quoting the model number, and
batch or date of manufacture.
• Do not place very hot or
• •
cold items against or in close
proximity to the glass
surfaces unless adequately
thick insulating material is
used to prevent such items
coming into contact with the
glass.
• Do not strike the glass with
•
hard or pointed items.
• When cleaning glass panels
or mirrors use a damp cloth or
leather with washing up liquid or
soft soap if necessary.
• Do not use washing powders
•
or any other substances
containing abrasives since these
substances scratch glass.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Page 3
Allen Key
Components - Parts
Wall Plug
x4Screw
x
4
A
Washer
x
2
Please check you have all the parts listed below
1
Towel rail
If you have damaged or missing components,
Components - Fittings
call the Customer Helpline: 08456 400800
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
B
C
Tools required
(Provided)
2
Page 4
Assembly Instructions
Step
Step
Step
A
A
1
Decide upon position of
items.
Vertically position the flat
side of the metal wall
plate on the wall. Mark
screw fixing hole
positions as required.
Note: Ensure
gap in pin is
on underside.
2
Before drilling check for any
hidden pipes and cables.
WALL
Ensure gap in pin is on underside.
WALL
Drill holes (6mm diameter
x 40mm deep) at the
positions marked and
push in the wall plugs
provided. Secure the
back plate to the wall
using the 2 screws .
Ensure it is level before
fully tightening.
Ensure screw heads are
flush with wall plate.
B
3
Peel off the pad cover
and stick the Glass back
plate over the back plate
ensuring it is straight and
central.
B
WALL
3
Page 5
Assembly Instructions
Step
4
Loosen the grub screw
as shown.
Place the washer &
metal part over the back
plate. Secure by
tightening the grub screw
as shown.
Note: To
prevent
breakage - Do
Not press on to the glass
back plate too hard when
assembling.
Note: The
wall fixing
step is for
securing the product to a
wall and should only be
attempted by
experienced persons.
C
WALL
C
Note: The
fixings
described are
for use with solid
masonry walls only.
Alternative fixings should
be purchased if you have
a different wall
construction.
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Help Line: 08456 400800
Home Retail Group plc. Avebury, 489-499 Avebury Boulevard. Milton Keynes. MK9 2NW
4
Page 6
