Alex Headboard
Step 7
Assembly Instructions
- Please keep for future reference
634/1880
634/1897
634/3541
634/3558
Dimensions
Width x Depth x Height
92cm x 5cm x 53.5/105cm (Single)
136cm x 5cm x 53.5/105cm (Double)
Important
If you need help or have damaged or missing parts, call the
- Please read these instructions fully before starting assembly
Customer Helpline:0345 6400800
Issue 2 - 25/10/14
Page 2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fi ttings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• Assemble the item as close
to its fi nal position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your fl oor.
• Assembly requires 2 people.
• Do not fully tighten bolts until
the whole bed is assembled.
Do not overtighten the nuts to
avoid causing damage to the
threads.
• From time to time check that
there are no loose bolts or
screws on this unit..
• To reduce
the lik elihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• Dispose of all packaging
carefully and responsibly.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
.
H andy
• Assemble all parts and bolts
loosely during assembly,only
once the product is complete
should you fully tighten the bolts.
H ints
• Regularly check and ensure
that all bolts and fittings are
tightend properly..
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
Page 3
If you have damaged or missing components,
Components
Please check you have all the parts listed below
(Single) (Double)
1 Headboard
call the
Customer Helpline:0345 6400800
2 Support arms x 2
2
Page 4
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
M8 Bolt x 4
Tools required
Phillips screwdriver
B
M8 Flat washer x 4
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
3
105
110 115 120 125 130 135 140 145 150 155 160 165 170
Page 5
Assembly Instructions
Attaching support arms
Attach the two support
arms to the rear of the
headboard using bolts
and washers as
shown.
Assembly is complete.
2
1
A
B
B
A
1
B
A
B
A
B
2
A
2
4
