Argos 6342755, 6342762, 6342786, 6342793 ASSEMBLY INSTRUCTIONS

Page 1
634/2724
Assembly Instructions – Please keep for future reference
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 24/10/12
Avalon 4'6 and 5' Bed
Dimensions (4'6)
Width - 149cm
Height - 104cm
Dimensions (5')
Length - 210cm
Width - 164cm
Height - 104cm
634/2755
634/2786
634/2731
634/2762
634/2793
Page 2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
1
Care and maintenance
• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.
• From time to time check that there are no loose screws on this unit.
• This product should not be discarded with household waste. Take to your local authority waste disposal centre.
• Check you have all the components and tools listed on pages 2 and 3.
• Remove all fittings from the plastic bags and separate them into their groups.
• Keep children and animals away from the work area, small parts could choke if swallowed.
• Parts of the assembly will be easier with 2 people.
• Make sure you have enough
space to layout the parts before starting.
• Assemble the item as close to its final position (in the same
room) as possible.
• Dispose of all packaging
carefully and responsibly.
• Place the product on flat and
steady surface during use.
• Assemble on a soft level surface to avoid damaging the unit or your floor.
• Keep these instructions for further use.
• To ensure an easier assembly, we strongly advise that all fittings are only finger tightened during initial assembly. Only upon completion of the assembly should all fixing points be fully tightened.
Page 3
Please check you have all the parts listed below
Components - Parts
Slat (Thread each end) x 4 (4'6- 142.1 X Ø1.9cm) (5'- 157.1 x Ø1.9cm)
9
10
Side rail x 2 (4'6- 98.4 x 10cm) (5'- 103.4 x 10cm)
7
Slat x 8 (4'6- 142.1 X Ø1.9cm) (5'- 157.1 x Ø1.9cm)
Side rail x 2 (4'6- 98.4 x 10cm) (5'- 103.4 x 10cm)
8
Support leg x 2
(29.8 x 7cm)
12
2
Central support x 2
(87.6 x Ø1.9cm)
11
Support leg x 4
(29.2 x Ø1.9cm)
13
Headboard corner post (right) (101 x Ø3.2cm)
1
Headboard corner post (left) (101 x Ø3.2cm)
2
Horizontal rail x 6 (4’6- 143ר1.9cm) (5'- 157 x Ø1.9cm)
3
Top rail (4'6- 148 x 8.2cm) (5'- 164 x 8.2cm )
6
Footboard corner post (right) (40 x Ø3.2cm)
4
Footboard corner post (left) (40 x Ø3.2cm)
5
Page 4
Components - Fittings
B
Rubber washer x 8
Please check you have all the fittings listed below
Note:
The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
Plain washer x 8
If you have damaged or missing components, call the Customer Helpline: 08456 400800
C
D E F
G
30mm Allen screw x 4
Nut x 4
25mm Allen screw x 12
H
13mm Allen screw x 8
3
55mm Allen screw x 4
J
Ruler - Use this ruler to help correctly identify the screws
0
5
10 15 20 25 30 35 40
45
50
55
60 65 70
75
80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Tools required
0
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150
1 2 3 4 5 6
Ruler/tape measure
A
15mm Allen screw x 4
K
Allen key x 2
25mm Allen screw x 12
Page 5
Step 1
4
Step 2
B
B
2
1
B
B
5
4
3
6
A
A
Assembly Instructions
Holes to face up
HEADBOARD
3
3
3
3
1
2
Assembling top rail
Assemble top rail to the headboard assembly
using screws .
6
A
Assembling corner
posts
Lay headboard posts and flat onto the floor with the holes facing up.
Assemble horizontal rails
in between corner posts and using screws .
Note: Horizontal rails fit inside the large holes in posts and .
Repeat using footboard corner posts and .
1
2
3
1 2
B
3
1 2
4
5
3
FOOTBOARD
Page 6
Step 3
Assembly Instructions
5
C
8
7
7
8
C
Step 4
Assembling slats
Assemble slats to one side rail only, using screws .
Note:
Slats have a
thread in each end.
9
9
E
E
9
7
E
8
7
9
9
9
9
Assembling side rails
Assemble side rails and together using screws .
Repeat for the other side rail.
7
8
C
Page 7
Step 5
Step 6
Assembling bed base
With help, locate the remaining side rail onto
the ends of the slats.
Secure using screws into slats as shown.
E
Assembling slats
Locate slats into
the remaining holes in
the side rail.
Note:
Slats have no
threads in the end and do not require fixing.
10
10
E
7
8
10
10
10
10
10
10
10
10
7
8
6
Assembly Instructions
9
9
9
9
9
Page 8
Step 7
AssemblingAssembling main frame
a: With help, assemble
side rails to the headboard using fixings
, , and .
b: Assemble the
footboard to the side rails using fixings ,
and .
c: Assemble support leg
to the underside of
the side rail using screws
.
Repeat on both sides.
F D G
H
E
D G
12
C
D
5
7
G
E
b:
b:
C
12
c:
12
C
c:
E
D
G
8
7
a:
H
D
F
G
D
F
H
G
8
2
a:
7
Assembly Instructions
Page 9
Assembly Instructions
Step 8
Assembling slat supports
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW
J
11
9
10
13
Assemble central supports and support legs through slats using screws .
Note:
Central supports
fit underneath the slats.
11
11
13
J
9
J
9
9
9
J
J
J
9
13
11
13
13
13
8
