Carly Desk
Assembly Instructions - Please keep for future reference
617-2592
617-2578
Dimensions
Width - 90cm
Depth-50cm
Height-74cm
Important - Please read these instruction fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 28/04/12
Page 2
Safety and Care Advice
IMPORTANT – READ CAREFULLY–RETAIN FOR FUTURE REFERENCE
Care and maintenance
and mild detergent, do not use
bleach or abrasive cleaners.
there are no loose screws on
this unit.
Keep These Instructions For Future Reference
This product complies with
EN 12521:2009
Argos plc
489-499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
discarded with household
waste. Take to your local
authority waste disposal centre.
if required the next
Note:
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
Page 3
Components
Please check you have all the panels listed below
Desk Top
1
(90x 50cm)X 1
Metal leg X 4 (7x 71.9cm)
2
If you have damaged or missing components,
Components - Fittings
call the Customer Helpline: 08456 400800
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
A
12mm Allen screw 16
x
Tools required
Allen key
(included)
Ruler - Use this ruler to help correctly identify the screws
85
5
0
25
201510
403530
60555045
75
7065
90
80
10510095
110
115
140
130
135
125120
155
170
165
160150145
2
Page 4
Assembly Instructions
Step 1
Preparing desk top
Place desk top on a
flat surface.
Step 2
Preparing metal legs
1
Lay 4 pcs metal leg
2
on a flat surface.
Step 3
Attaching metal legs
Attach 1pc of metal leg
2
to desk top by
using 4 pcs of bolts .
1
A
2
2
2
2
2
A
A
A
A
1
3
Page 5
Assembly Instructions
Step 4
Attaching other metal
legs
Repeat step3.
Attach other 3pcs of
2
metal legs
top by using 12 pcs
1
of bolts .
A
to desk
2
A
A
A
A
2
2
A
A
A
A
A
A
A
A
Step5
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline:
08456 400800
4
