Page 1
Small Extra Deep Bookcase
Assembly Instructions - Please keep for future reference 610/9493
609/1006
609/2067
610/9565
Dimensions
Width - 78cm
Depth - 29cm
Height - 91.5cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
08456 400 800
Date : 01/11/10
Page 2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
•
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• From time to time check that
there are no loose screws on
this unit.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
Page 3
If you have damaged or missing components,
Components - Panels
call the Customer Helpline: 08456 400 800
Please check you have all the panels listed below
Top (749x289mm)
3
Shelf x 2 (749x289mm)
6
Left side (915x290mm)
2
Bottom (749x289mm)
4
Front (749x59mm)
5
Right side (915x290mm)
1
Back (852x777mm)
7
2
Page 4
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
50mm Screw x 8 Shelf Support x 8
G
Wall Strap x 1 Nail x 30
B
13mm Screw x 9
E
Allen Key x 1
H
8 Covering Stickers x 1 ( 16mm)
C
Nail Guide x 1Plastic Support x 4
FD
I
Tools required
Phillips screwdriver
Eye protection
(when using a
hammer or glue)
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
3
Small
hammer
0 1 0 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
110 115 120 125 130 135 140 145 150 155 160 165 170105
Ruler/tape
measure
Page 5
Assembly Instructions
Step 1
Attaching bottom panel
B
A
to fix
onto
4
.
B
A
a: Use Screws
Plastic Support
the Bottom Panel
B
a:
4
B
B
A
A
A
B
A
b:
Use Screws
B
to
connect the Front Panel
onto the Bottom Panel .
4
4
5
5
b:
5
B
4
B
B
B
B
4
4
Page 6
Assembly Instructions
Step 2
Attaching side panel
a:
Use Screws
Left Side Panel onto the
Bottom Panel
Panel .
Note:
3
Use Allen Key
to fix Screws .
D
2
4
and Top
D
to fix the
E
a:
D
E
3
D
2
D
D
4
D
D
to fix the
1
4
and
E
Use Screws
b:
Right Side Panel onto
the Bottom Panel
Note:
Use Allen Key
to fix Screws .
b:
D
3
1
D
E
D
2
4
Page 7
Assembly Instructions
Step 3
Fixing back panel
Use Nails
Back Panel
unit.
Note:
keep a constant distance
from the edge.
I
to fix the
7
onto the
Use Nail Guide to
I
C
C
7
6
Page 8
Assembly Instructions
Step 4
Fixing to wall
It is recommended that the
bookcase is fixed to a
wall.
See Wall Fixing Guidelines
at the end of these
Assembly Instructions
Use Screw
Wall Strap
B
to fix the
onto the Top
G
of the panel.
Step 5
Attaching shelf panel
Insert Shelf Supports
into the unit.
Ensure they are well fitted
before inserting the
Shelves.
F
G
Wall screw and wall
plug not included
B
G
Set the shelf
Note:
supports to the desired
height.
Slide the Shelves
6
into the unit.
Step 6
Covering Sticker
Use the Covering Sticker
H
to cover the Screw
Heads.
6
F
F
6
F
F
F
F
H
Page 9
A Guide to - Wall Mounting & Fixings
Important note:
If plastic wall plugs
are supplied with your
product:
- there are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect fixings is the
responsibility of the installer.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles spltting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
Types of walls
No.1 "General Purpose" wall plug No.3 "Cavity Fixing" wall plug No.5 "Hammer Fixing" wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case. For light
loads, general purpose wall plugs can
be used.
No.2 "Plasterboard" wall plug
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
For use with plasterboard partitions or
hollow wooden doors.
No.4 "Cavity Fixing-Heavy Duty"
wall plug
For use with walls stuck with
plasterboard. The hammer fixing allows
it to be fixed to the wall rather than the
plasterboard. Always check the fixing
is secure to the retaining wall.
No.6 "Shield Anchor" wall plug
Heavy loads
For use when attaching light loads on
to plasterboard partitions.
Care &
Maintenance
For use when fitting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
8
