Page 1
CHAD VALLEY BABY
Circus Friends
™
™
580/9866
Portable Swing
IMPORTANT! KEEP FOR FUTURE REFERENCE.
Argos
Avebury, 489-499 Avebury Boulevard, Milton Keynes, MK9 2NW
www.argos.co.uk
Customer Helpline: 03456 400 800
10956_BS_IS090116rev1
PRINTED IN CHINA
Page 2
EN
To Prevent Serious Injury Or Death From Children Falling Or Being
Strangled In Straps:
• Use the product only if the child meets ALL of the following conditions:
• Cannot sit up by himself or herself
• Is not an active child who may be able to climb out of the seat
• Weighs more than 6 lbs. (3kg) and less than 20 lbs. (9kg)
• NEVER leave child unattended.
• ALWAYS use restraint system.
• Not intended for carrying baby
• Never move or lift the product while child is in the seat.
• NEVER lift swing using a toy bar as a handle.
• NEVER attach any additional strings or straps to product or toy bar.
• FALL HAZARD: NEVER place the swing on countertops, tables, on or near
steps or on other elevated surfaces. • ALWAYS use on the oor.
To Prevent Serious Injury or Death
• Use only in reclined position until child is at least 4 months old AND can hold
head unassisted. Young infants have limited head and neck control. If the
swing is too upright, infant’s head can drop forward, compress the airway,
and result in DEATH.
• This product is not intended for prolonged periods of sleeping.
• NEVER use as an infant carrier for automobile or airline travel.
• To avoid injury, ensure that children are kept away when unfolding and
folding this product.
• Do not let children play with this product.
• SUFFOCATION HAZARD: NEVER use on soft surface (bed, sofa, cushion), as
seat may tip over and cause suocation.
WARNING
(approximately 9 months of age)
IMPORTANT
• Adult assembly required.
• Please read all instructions before assembly and use of the product.
• Care should be taken in unpacking and assembly.
• Examine product frequently for damaged, missing, or loose parts.
• DO NOT use if any parts are missing, damaged, or broken.
• This product has not been designed for sleeping. Should your child need to
sleep, they should be placed in a suitable cot or bed.
•
Do not use accessories or replacement parts other than those approved
by the manufacturer
– 2 –
Page 3
Battery Information
The swing control module requires (4) size C/LR14 (1.5V) alkaline batteries (not included).
EN
CAUTION: Follow the battery guidelines in this section. Otherwise, battery life may
be shortened or the batteries may leak or rupture.
• Always keep batteries away from children.
• Do not mix old and new batteries.
• Do not mix alkaline, standard, or rechargeable batteries.
• Only batteries of the same or equivalent type as recommended are to be used.
• Install the batteries so that the polarity of each one matches the markings in the battery
compartment.
• Do not short-circuit the batteries.
• Do not store batteries in areas that have extreme temperatures (such as attics,
garages, or automobiles).
• Remove exhausted batteries from the battery compartment.
• Never attempt to recharge a battery unless it is specically marked “rechargeable.”
• Rechargeable batteries are to be removed from the toy before being charged.
• Rechargeable batteries are only to be charged under adult supervision.
• Do not use rechargeable alkaline batteries in a Ni-Cad or Ni-MH battery charger.
• Please use the correct disposal method for batteries.
• Remove batteries before putting the swing into storage for a prolonged period of time.
• Weak batteries cause erratic product operation, including distorted sound, dimming or
failed lights, and slow or non-working motorized parts. Because each electrical component requires a dierent operating voltage, replace the batteries when any function fails
to operate.
• Do not dispose of product or batteries in re, batteries may explode or leak.
This symbol indicates that the product is not to be disposed of in household waste as
batteries contain substances that can be damaging to the environment and health.
Contact local authority for recycling & collection information.
– 3 –
Page 4
Parts List and Drawing
No. Qty. Description
1 (1) Left frame/pivot assembly
2 (1) Right frame/pivot assembly with swing control module
3 (2) Base frame tube
4 (2) Seat tube
5 (1) Seat pad
6 (1)
Toy bar with toys
– 4 –
Page 5
not included
+
1.5V
4x
6
8
5
7
-
C/LR14
A
4
5
2
3
1
2
3
4
4
6
– 5 –
Page 6
1
2
1
2
3
3
– 6 –
Page 7
4
5
5
– 7 –
Page 8
6
4
4
7
– 8 –
Page 9
8
9
4x
+
-
1.5V
C/LR14
– 9 –
Page 10
10
11
6
– 10 –
Page 11
1
Using the Seat Restraint
2
– 11 –
Page 12
3
x2
Using the Recline Function
x2
– 12 –
Page 13
Using the Swing Control Module
Swing Timer Select Button and Indicator
EN
The TrueSpeed Control™ provides steady motion to calm your baby. To use the swing func-
tion...
Turn the Speed Selector Ring clockwise to any of six positions to start the swing and select the
speed. Turn the selector ring counter-clockwise to the rst position (OFF) to stop the swing.
NOTE: It is not necessary to push the swing. The swing will automatically adjust motion
to the desired speed within 20 to 25 seconds after speed
selection.
– 13 –
Page 14
1
Storage and Travel
2
– 14 –
Page 15
3
x2
When putting swing away for storage, always store in a dry location, away from any heat
EN
sources, and out of the sun.
Care and Cleaning
S
Seat pad and headrest – Can be cleaned by sponging with warm water and a
EN
mild detergent. (Do not immerse in water.) Never clean with abrasive, ammoniabased, bleach-based, or spirittype cleaners. Seat pad must be dried thoroughly on
a at surface before using or storing. Do not spin or tumble dry.
Toy bar and toy – Wipe clean with a damp cloth and mild soap. Air dry. Do not
immerse in water.
Frame – Wipe the metal frame with soft, clean cloth and mild soap.
CAUTION: CARELESSNESS CAUSES FIRE. COVER(S) AND FILLING(S) HAVE
BEEN TESTED TO ENSURE COMPLIANCE WITH THE FURNITURE AND
FURNISHINGS (FIRE) (SAFETY) REGULATIONS 1988.
