Page 1
Rattan
4 Piece Sofa Set
Spare Parts
www.argos-support.co.uk
0370 112 1928
Customer Support
0345 640 2020
Issue 3 - 09/09/20
Page 2
Safety and Care Advice
Product Details
Argos Rattan 4 Piece Sofa Set - Grey 502/2636
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts
before starting.
This product has been
constructed to be used in the
domestic environment only and
not for commercial purposes.
Warnings
Do not stand or jump on the
chair, bench, table.
Do not sit on the arms of the
chair and bench.
Do not use the chair, bench
as a step stool/ladder.
Care and maintenance
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Please note wood is a natural
material, some slighty colour
and grain variation and natural
marks will be present.
• Do not rock the chair, bench
whilst seated.
• Beware of the risk of falling
and tipping.
• Pregnant women should take
additional care when using
this product.
We do not
recommend the
use of power
drill/drivers for
inserting screws
as this could damage the unit.
Only use hand screwdrivers.
Parts of the assembly will be
easier with 2 people.
Dispose of all packaging
carefully and responsibly.
• Do not leave the child
unattended.
• Children should always be
under direct adult supervision
whilst using this product.
• If the product is broken or
damaged, discontinue use
immediately.
• Only clean using a damp cloth
and mild detergent. Do not use
abrasive cleaners.
• Do not use hard objects to rub
on the product to avoid scratches.
• From time to time check that
there are no loose screws, nuts or
bolts. If there are please re-tighten.
• Store indoors when the product
is not in use to prolong the lifetime.
• In order to prolong the life and
appearance of the product, we
recommend that it should be
stored in a dry area when not in use.
• Always protect from severe
weather conditions.
• During bad weather or winter
months the product should be
stored in a cool and dry place.
• Care instructions for cushion:
Do not wash. Do not bleach.
Do not tumble dry. Do not iron.
Do not dry clean. Wipe clean
with warm water and sponge only.
• Keep away from fire.
Additional Guidance
● Assemble all parts and bolts loosely during assembly, only once the product is complete should you
fully tighten the bolts.
● Regularly check and ensure that all bolts and fittings are tightend properly.
● Maximum weight capacity : Chair 110 kg, Bench 220 kg, Table 25 kg.
● This product is compliant EN 581-1:2017, EN 581-2:2015, EN 581-3:2017, EN 1022:2018,
Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United
Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited,
Registered office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales).
Both companies are subsidiaries of J Sainsbury's plc.
2
Page 3
Components - Parts
Table Top1
Bench Seat
4
Table Leg2
Back Leg5
x4
x6
Chair Seat3
6
Front Leg
x2
x6
Small Cushion7
x2
8
Large Cushion
x2
Components - Fittings
A
M6x20mm Screw x12
D E
Wrench x1 Allen key x2
B
M8/13x5 Nut x24
9
Small Pillow
x2
C
Washer x24
10
Large Pillow
x2
3
Page 4
A
B
C
A
1
M6x20mm Screw x12
D E
Wrench x1 Allen key x2
M8/13x5 Nut x24
A
1
A
Washer x24
2
M6x20mm Screw x12
E
A
A
2
2
2
1
2
Turn
Product
4
Page 5
B
C
2x
2
M8/13x5 Nut x8
5
Washer x8
C
5
6
6
B
C
B
B
D
3
9
7
Turn
Product
5
Page 6
B
C
3
M8/13x5 Nut x8
B
5
Washer x8
C
B
D
6
C
B
4
5
6
Turn
Product
10
10
8
8
6
Page 7
Care Instructions
for wood furniture
IMPORTANT
As your furniture has been boxed since manufacture there may be a slight oil residue on the pieces
which will dry when it is left in the air. Care should be taken when assembling and using the
furniture in the first couple of days particularly if light coloured clothes are worn. Hardwood
has a varied texture which absorbs oil at different rates. This may mean there are some paler
dry patches. If this is the case then apply a little oil as directed in the care instructions below.
Use of Wood Furniture
- This furniture has been made for the garden and is not suitable for indoor use or conservatories.
If positioned on grass the legs may absorb moisture which could cause deterioration. The sunlight
will make the colour of the wood mellow with time even if it is oiled.
- Never place hot dishes directly on to the wood as they will mark the surface.
- Wipe up spills immediately as the oiled surface is more susceptible to stains than a lacquered
finish and the wood will absorb moisture causing the grain to rise slightly.
- Take care when moving furniture and never drag pieces as this will cause damage to the joints.
- To ensure the longevity of your garden furniture it is advised that it is covered when not in use and
that it is stored in a garage or shed over the winter months. Ensure furniture is dry before storing.
Care Instructions.
- In the first three months the furniture should be oiled monthly with a hardwood garden furniture
oil using a lint free cloth, paying particular attention to the ends of the legs and slats as
they are more absorbent.
- After the first three months, the furniture should be oiled once a year as it is brought out at the
beginning of the spring summer season and whenever the surface is looking dry. The wood will
gradually change colour to a silvery grey and the surface will become rough. Regular oiling will help
to minimise cracking but won’t eliminate it. Cracking of the timber does not affect
the durability of the product.
- Do not use oils sold for cooking or eating as they will leave a sticky film.
- If the surface of the furniture becomes slightly stained or damage with use, then it can often
be removed by sanding gently with fine sandpaper then re-oiling. If the stain or damage is more
serious then we recommend that professional help is obtained.
- Please check the fixings are all tight when you put the furniture out each year, as the wood
may expand or contract slightly.
Please retain for future reference.
Produced in Vietnam for Argos Ltd
489-499 Avebury Boulevard, Milton Keynes, MK9 2NW
7
