Page 1
Skandi Oak
Veener Bar Table
Spare Parts
www.argos-support.co.uk
0370 112 1928
Customer Support
0345 640 2020
Issue 1 - 05/11/19
Page 2
Safety and Care Advice
Product Details
Skandi Oak Veneer Bar Table 4463447
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough space
to layout the parts before
starting.
This product has been
constructed to be used in the
domestic environment only and
not for commercial purposes.
Care and maintenance
Only clean using a damp cloth
and mild detergent. Do not use
abrasive cleaners.
Use a dry cloth to clean the
product, furniture polish is
not recommended.
Assemble the item as close
room) as possible.
Assemble on a soft level
surface to avoid damaging the
From time to time check that there
are no loose screws, nuts or bolts.
If there are please re-tighten.
We do not
recommend the
use of power
drill/drivers for
inserting screws
as this could damage the unit.
Only use hand screwdrivers.
Parts of the assembly will be
easier with 2 people.
Dispose of all packaging
carefully and responsibly.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
Additional Guidance
Assemble all parts and bolts loosely during assembly, only once the product is complete should you
fully tighten the bolts.
Regularly check and ensure that all bolts and fittings are tightend properly.
Maximum user weight 100kg(refer to EN12521)
This product is compliant EN12521
Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United
Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered
office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales). Both companies are subsidiaries of J
Sainsbury's plc.
1
Page 3
Fittings (Shown to scale)
Bag 1
A
100mm Bolt x8
B
B
60mm Nut x4
C
M8 Nut x8
F
Wrench x1
H
30mm Dowel x8
D
M8 Spring Washer x8
I
50mm Screw x4
E
M8 Flat Washer x8
G
Felt Pad x4
2
Page 4
Panels
1
Top Panel x 1
(1200 x 500mm)
Leg x 2
2
( 890x 70mm)
Rail x 2
4
( 365x 70mm)
Leg x 2
3
( 890x 70mm)
Page 5
Tools required
Phillips screwdriver
(small & medium)
Phillips screwdriver
(small & medium)
4
Page 6
A
1
100mm Bolt x8
B
B
60mm Nut x4
x4
B
2
3
A
100mm Bolt x8
B
B
60mm Nut x4
C
M8 Nut x8
D
M8 Spring Washer x8
A
A
E
M8 Flat Washer x8
F
Wrench x1
H
30mm Dowel x8
I
5
0mm Screw x4
G
Felt Pad x4
5
Page 7
2
Rotate
Product
C
M8 Nut x4
F
Wrench x1
D
M8 Spring Washer x4
70%
E
M8 Flat Washer x4
F
E
D
C
2
3
1
6
Page 8
3
H
H
H
30mm Dowel x8
I
4
I
0mm Screw x2
5
4
4
3
C
M8 Nut x4
2
D
M8 Spring Washer x4
70%
E
M8 Flat Washer x4
F
E
D
C
7
Page 9
G
I
5
100%
Felt Pad x4
0mm Screw x2
5
G
I
6
Rotate
Product
8
