Argos 4182553, 4271062 ASSEMBLY INSTRUCTIONS

3FT Josie Bunk Bed

Assembly Instructions

- Please keep for future reference

436/9730 434/7972

Dimensions

Width - 195,0cm Depth - 103,3cm Height -154,6cm

Important – Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800

Issue 1 - 27/03/15

Safety and Care Advice

Important  Please read these instructions fully before starting assembly

Check you have all the components and tools listed on pages 2 and 3.

Remove all ﬁttings from the plastic bags and separate them into their groups.

Keep children and animals away from the work area, small parts could choke if swallowed.

Make sure you have enough space to layout the parts before starting.

Assemble on a soft level surface to avoid damaging the unit or your ﬂoor.

Care and maintenance

Use an appropriate furniture polish for natural wood furniture and a dry cloth to clean the product.

Avoid placing the furniture in

direct sunlight as this will cause the timber to prematurely age.

This product contain

natural timber; you may

notice some variation in the grain and colour of different component parts which is normal for furniture produced using natural wood and is not the result of any manufacturing fault.

Do not stand or put weight on the product, this could cause damage.

Assemble the item as close to its ﬁnal position (in the same room) as possible.

From time to time check

that there are no loose screws on this unit.

We do not recommend the use of power drill/drivers for inserting screws, as this could damage the unit. Only use hand screwdrivers.

Parts of the assembly will be

easier with 2 people.

Dispose of all packaging

carefully and responsibly.

This product should not be discarded with household waste. Take to your local authority waste disposal centre.

IMPORTANT, READ CAREFULLY -RETAIN FOR FUTURE REFERENCE.

ASSEMBLY:

Current legislation requires that the bunk bed must be ﬁtted with 4 safety-rails and a ladder or platform for the upper bunk bed. The bunk bed meets the European EN 747-2012 standards for security and durability.

MATTRESS:

This bed is designed to use a mattress size 190 cm. long and 91,0 cm. wide. The total thickness must not exceed 16,0 cm. The mattress top must not pass the marking on the ladder.

WARNING:

High beds and the upper bed of bunk beds are not suitable for children under six years due to the risk of injury from falls. Do not use the bed if any structural part is broken or missing. Be aware that children can strangle in items such as ropes, strings, cords, harnesses and belts attached to or hung on a bunk bed/high bed.

WARNING:

Children can become trapped between the bed and the wall. To avoid risk of serious injury the distance between the top safety barrier and the wall shall not exceed 75 mm. or shall be more than 230 mm.

MAINTENANCE INSTRUCTIONS:

All assembly fastenings should always be tightened properly and that care should be taken that no loose.

CLEANING: LACQUERED: Wooden, lacquered and painted as well as laminated surfaces should be wiped over with a

cloth and a mild soap. OIL: Oiled surfaces can be cleaned with soapy water, e.g. brown soap. Wipe with a clean cloth. To maintain the natural life in the furniture which is provided by the oil treatment, we recommend an oil aftercare of the furniture 1-2 times a year. The colourless natural oil for maintenance of oil-treated furniture is available at your local furniture store.

ttings are

ﬁ

Components - Panels

Please check you have all the panels listed below

Left front foot/ right back foot x 2

(152,5 x 6,3 x 2,5 cm)

Left back foot

(152,5 x 6,3 x 2,5 cm)

Right front foot

(152,5 x 6,3 x 2,5 cm)

Wide bar x 3

(83,5 x 11,0 x 1,9 cm)

Wide bar with label

(83,5 x 11,0 x 1,9 cm)

Narrow bar x6

(83,5 x 6,5 x 1,9 cm)

Curved bar with label

(83,5 x 9,0 x 1,9 cm)

Front side rail x2

(175,0 x 11,0 x 3,8 cm)

Back side rail x2

(175,0 x 11,0 x 3,8 cm)

Long guard rail x2

(175,0 x 6,3 x 1,9 cm)

Short guard rail x2

(141,2 x 6,3 x 1,9 cm)

Ladder side rail

(130,2 x 6,5 x 1,9 cm)

Step x 2

(35,7 x 6,5 x 1,9 cm)

Guard rail support x 2

141514

(34,0 x 6,5 x 1,9 cm)

Slats x 28 (91,0 x 7,0 x 1,7 cm)

Curved bar

(83,5 x 9,0 x 1,9 cm)

If you have damaged or missing components,

Components - Fittings

call the Customer Helpline: 03456 400 800

Please check you have all the ttings listed below

Note: The quantities below are the correct amount to complete the assembly. In some cases more ﬁttings may be supplied than are required.

1/4 x 70mm x 17 Bolt X 8

Allen Key X1

10 x 40mm Wooden dowel

Tools required

Phillips screwdriver (medium & large)

X 56

Barrel nut X16

4 x 35mm Screw X 62

1/4 x 110mm x 17 Bolt X 8

7 x 100 x 17mm Bolt X 16

7 x 60 x 17mm Bolt X 14

Spacer 71mm X 02

Ruler/tape measure

Small hammer

Ruler - Use this ruler to help correctly identify the screws

10 15 20 25 30 35 40

60 65 70

80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170

Eye protection (when using a hammer)
