Sasha Coffee Table
Assembly Instructions
-
Please keep for future reference
609/4883
609/5734
609/6290
404/2222
Dimensions
Width - 90cm
Depth - 45cm
Height - 44.5cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
Version 3 Date: 19/03/15
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
the following pages.
• Remove all fi ttings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• During assembly do not stand
or put weight on the product,
this could cause damage.
• Assemble the item as close
to its fi nal position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your fl oor.
• Parts of the assembly will be
easier with 2 people.
• From time to time check that
there are no loose screws on
this unit.
• To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Handy Hints
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
• Regularly check and ensure
that all bolts and fi ttings are
tightend properly.
1
Components - Panels
If you have damaged or missing components, call the
Customer Helpline:
Argos = 0345 6400800
1
Table top (90 x 45cm)
Leg x 4 (40 x 4.5cm)
2
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly. in some cases mor
may be supplied than are required.
A
72mm Screw x 4
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
105
110 115 120 125 130 135 140 145 150 155 160 165 170
2
Assembly Instructions
Step 1
Attaching legs
a:
Fasten Screw into
the Leg up to half
length(36mm).
Note: Please ensure
screws are tightly secured.
b:
the Table top .
2
Fix the Legs onto
A
2
1
a:
b:
A
2
A
72mm
36mm
X 4
2
2
36mm
2
36mm
Step 2
Finishing the unit
With help, place the unit in
the intended position.
2
1
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
3
