Rattan 4 Seater Set - Chair
Assembly Instructions - Please keep for future reference
3566651
Dimensions
Width - 67cm
Depth - 67cm
Height - 83cm
Important –
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
Please read these instructions fully before starting assembly
Issue 1 - 26/09/13
Page 2
•
1
Safety and Care Advi ce
Important – Please read these instruc tions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2.
plastic bags and separate them
into their groups.
• Keep child ren and animals
away from the work area, small
parts could choke if swallowed.
• Make su re you have enough
space to layout the parts before
starting.
• Do not stand or put weight on the
product during assembly, this could
cause damage.
• Assemble the item as close
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
chair or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws ,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
Care and mainte nanc e
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
r
the e are no loose screws on
• F om time to time check that
r
this chair.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Do not fully tighten all screws
until assembly is complete.
• Make sure each screw
matches the corresponding
gure to ensure correct
assembly.
• Maximum safe seated
weight: 110kgs.
Page 3
If you have damaged or missing components,
Components - Parts
call the Customer Helpline: 03456 400 800
Please check you have all the parts listed below
Left Armrest x 1
1
Right armrest x 1
2
3
Back rest x 1
5
4
Front board x 1
Seat board x 1
Components - Fittings
Please check you have all the fittings listed below
Note:
fittings may be supplied than are required.
The quantities
A
25mm Screw x 8
Tools required
below are the correct amount to complete the assembly. In some cases more
B
Metal washer x 16
C
Nut x 8
6
Cushion x 1
D
Plastic Washer x 8
Wrench x 1
Allen key x 1
2
Page 4
Assembly Instructions
Step 1
Assembly frame
and two
Use screw
washers
and plastic washer
to fix
the armrest 1
& 2 to
A
D
B
C
with nut
B
the backrest 3 .
3
1
3
2
2
1
3
Important:
Do not fully
tighten all screws
until assembly is
complete.
Step 2
Use screw
washers
and plastic washer
to fix
the armrest 1
& 2 to
4
.
A
with nut
B
the front board
and two
D
B
C
A
B
C
B
D
1
4
1
2
C
A
B
D
B
4
3
Page 5
Assembly Instructions
Step 3
Fit the seat board 5
onto the chair.
Tighten all the
screws.
5
Step 4
Put on the cushion
to fit for the seat board.
6
6
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Argos Limited
489-499 Avebury Boulevard Saxon Gate West Central Milton Keynes Bucks,MK9 2NW
4
