Malvern 6 Drawer Unit
Assembly Instructions - please keep for future reference
346/8618
Dimensions
Width - 63cm
Depth - 26.5cm
Height - 76cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
LP. 260.96.078A
Customer Helpline:
0845 6400800
Issue 1 - 23/03/2015
Page 2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Check you have all the
components and tools listed on
pages 3 and 4.
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp
cloth and mild detergent, do
no use bleach or abrasive
cleaners.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
• Parts of the assembly will be
easier with 2 people.
• From time to time check that
there are no loose screws on
this unit.
• We do not
recommend the
use of power
drill/drivers for
inserting screws ,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
WARNING
In order to help prevent overturning –
To help prevent product toppling over please follow the below steps:-
Do not allow children to climb or hang on the furniture
Do not place heavy items in the top drawers
Do not place heavy items on top of the furniture, unless the furniture has been
designed for this purpose
You will need to provide wall plugs and screws applicable for your wall type
2
Page 3
Components - Fittings
Note:
may be supplied than are required.
If you have damaged or missing components,
call the Customer Helpline:
0845 6400800
A B D
Wall Strap Screw x 1
E
Washer x 2
Wall Plug x 1
C
Wall Screw x 1
D
Tools required
Phillips screwdriver
(medium & large)
Drill
(for wall drilling only)
Ruler – Use this ruler to help correctly identify the screws and parts
105
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
Wall Strap x 1
3
Page 4
Assembly Instructions
Step 3
The Malvern Unit is
floor standing, but it is
recommended that the
unit is secured to the
wall.
1. Connect 1 x wall strap
D
to the reverse of the
unit with 1 x washer E
and screw A.
2.Move the units into
desired position.
3. Mark the wall with a
suitable scribe the
position of the fixing
hole.
A
E
B
E
C
E
D
A
Warning:
Before driling,check
wall for hidden pipes
and cables.
4. Drill hole and insert
wall plug D
5. Secure the strap to the
wall using 1 x washer E
and wall screw E.
Note: To hide the strap
behind the unit, drill the
hole lower than the top of
the unit.
B
E
C
Assembly Complete
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
4
Page 5
A Guide to Wall Mounting & Fixings
lmportant note:
lf plastic wall plugs(rawl plugs)
are supplied with your product,
e.g.:
- these are only suitable for use in
masonry walls.
lf you are in any doubt about the
correct wall plugs for your wall,
seek professional advice.
Failure of the product due to
using the incorrect fixings is the
responsibility of the installer.
Types of walls
lmportant: when drilling into walls always check
that there are no hidden wires or pipes etc.
Make sure that the screws and wall plugs being used are suitable for
supporting your unit.Consult a qualified tradesperson if you
are unsure.
Hints:
General rule: always use a larger screw and wall plug if you are
not sure.
Ensure you use the recommended drill bit to match the wall plug and
hole size.
Ensure you drill the hole horizontally; do not force the drill or enlarge
the hole.
Take extra care when drilling high walls,ceilings and ceramic tiles.
Ensure wall plugs are inserted beyond the thickness of the ceramic
tiles to avoid the tiles splitting or cracking.
Ensure wall plugs are well fitted and are a tight fit in the
5:
drilled hole.
You can use one of the folllowing types of wall plug if your walls are made
of brick, breeze block, concrete,stone or wood.
No.1"General Purpose" wall plug No.3"Cavity Fixing" wall plug
Generally aerated blocks should not
be used to support heavy loads,use
For use with plasterboard partitions
or hollow wooden doors.
a specialist fitting in this case. For
light loads, general purpose
wall plugs can be used.
No.2" Plasterboard"
wall plug
No.4" Cavity Fixing - Heavy Duty"
wall plug
No.5"Hammer Fixing" wall plug
For use with walls stuck with
plasterboard. The hammer fixing
allows it to be fixed to the wall
rather than the plasterboard.
Always check the fixing is secure
to the retaining wall.
No.4" Shield Anchor" wall plug -
heavy loads
For use when attaching light loads
onto plasterboard partitions.
or use when fitting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with heavier loads such as
TV and HiFi speakers and satelite
dishes etc.
lf you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
