Amalfi Armchair
Assembly Instructions - Please keep for future reference
1425361
Dimensions
Width - 72.0cm
Depth - 58.0cm
Height - 104.0cm
Important - Read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456400800
Issue 1 -19/11/13
Page 2
!
Safety and Care Advice
Important - Read these instructions fully before starting assembly
• Check you have all the components and
tools listed on page 2.
• Remove all fittings from the plastic bags
and separate them into their groups.
• Keep children and animals away from
the work area, small parts could choke if
swallowed.
Care and maintenance
• Wash frame parts with mild
soap and water, rinse thoroughly,
and dry completely. Do not use
bleach, acid, or other solvents
on the frame parts.
• Make sure you have enough space to
layout the parts before starting.
• Do not stand or put weight on the
components during assembly, this
could cause damage.
• Assembly on a soft level surface to
avoid damaging the unit or your floor.
• Parts of the assembly will be easier
with 2 people.
• Inspect and tighten all bolts
and fasteners on a regular basis
to ensure the proper performance
and safety of your chair.
• Dispose of all packaging carefully and
responsibly.
• Do not stand on this chair.
Warning: The unit weighs approximately
•
64.6 kgs. Please lift with care.
• In order to prolong the life and
beauty of your chair, we
recommend that it be stored in a
dry and protected area when not
in use .
• We recommend the use of
furniture covers when not in use.
1
Page 3
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly.
A
M6 x 14mm Bolt x 4 M6 x 16mm Bolt x 4 M6 x 35mm Bolt x 4
D
d6.5 x D13 x 1.0 Washer x 8
G
Bolt Cap x 4
B C
E
E
d6.5 x D10 x 1.6 Washer x 8
F
M6
H
M6
Bolt Cap x6
Bolt Cap x 4
Components - Parts
Please check you have all the parts listed below
1 2
Seat Assembly x 1
4
Support x 1
Left Arm x 1
Tools required
4mm Hex Key
6mm Hex Key
Ruler - Use this ruler to help correctly identify the screws
3
Right Arm x 1
35
2
Page 4
Assembly Instructions
Step 1
Place the support to the
left arm and the right arm
3
by using bolts ( and ),
washers ( and ) . Keep
the bolts loose.
Note:
The labels marked “L” and “R”
on arms ( and ) should
coincide with Step 2 to ensure
proper assembly.
2
2
4
A
DE
3
B
Step 2
L
B
E
D
3
4
A
2
4
R
3
Note:
Make sure that the bolts on
the seat assembly are
loose prior to assembling
this chair.
1
1
1
3
Page 5
Assembly Instructions
Step 3
Place the seat assembly to
the left arm and the right
arm by using bolts ( and
3
) , washers ( and ) .
B
Keep the bolts loose.
2
1
A
DE
L
2
1
R
B
E
D
3
1
A
3
Step 4
Turn the chair to its upright
. At the back of the
chair, fasten the seat assembly
1
to the arms ( and )
by using bolts and washers
( and ) .
D
E
2 3
C
1
D
E
2
1
D
E
C
C
2
3
4
Page 6
Assembly Instructions
Step 5
Tighten the bolts on the seat
assembly . Make sure that
all of the bolts have been
tightened completely and cover
them with bolt caps ( ,
and ).
1
FHG
G
1
3
1
H
F
Assembly is completed.
If you need help or have damaged or missing parts, call the Customer Helpline: 08456400800
Retailer: Argos
Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9, 2NW
5
