data sheet
SUPER DOPE™
Anaerobic Thread Sealant
VIRTUALLY
IMPOSSSIBLE
TO LEAK
•Chemically hardens in the
absence of air into a tough,
structural solid.
•Instant low pressure seal
•Cures to pipe burst pressure
•Allows for adjustment & alignment
of fittings after application
•Permits disassembly
•Pipe joints and fittings are locked
against vibration loosening
•Withstands temperature up to 400° F
•Seals regardless of a multitude of mistakes
•Comparable to Loctite* 565
•Will not loosen, set or shrink
•Only put on 1st, 2nd & 3rd
threads ...uses less material
Specifications: 0-10,000 psi; -65-400° F; 150,000 cPs, white color; 4 hour cure for pressure
testing. Typical applications are in sealing of all types of metal threaded connections against
water, potable water, gas, oil, grease, and most common materials conveyed by pipes.
It is extensively used on pressure vessels, air compressors, hydraulic systems, tanks, etc. for
positive vibration proof sealing.
DO NOT USE WITH PTFE TAPE OR PIPE JOINING COMPOUNDS WITH SUPERDOPE.
1010085: Superdope 14 liter can
1010086: Superdope 750 ml can
1010087WBRUSH: Superdope 350 ml brush top
1010087: Superdope 350 ml can
1010088: Superdope 250 ml can tube
1010089: Superdope 50 ml tube
*LOCTITE IS A REGISTERED TRADEMARK OF LOCTITE
CORP. NEWINGTON, CT
Volatile Organic Compounds:
5.4% based on weight (mg/liter)
59.4 grams per liter
The information contained herein is produced in good faith and is believed to be reliable but is for guidance only. ARGCO and its agents cannot
assume liability or responsibility for results obtained in the use of its product by persons whose methods are outside or beyond our control. It is the
user's responsibility to determine the suitability of any of the products, methods of use, or preparation prior to use, mentioned in our literature. It is
the user's responsibility to observe and adapt such precautions as may be advisable for the protection of personnel and property in the handling and
use of any of our products.
FOR MORE INFORMATION CALL ARGCO AT 1-800-854-1015
OR LOG ONTO WWW.ARGCO.COM
data sheet
Super-Dope® Anaerobic Thread Sealant
DESCRIPTION
Super Dope Pipe Sealant is an easy to use pipeline sealant which sets fast to give an instant low pressure seal of 100 psi and a high pressure
seal when fully cured. Unlike solvent based pipe dopes, Instant Pipe Sealants cures anaerobically, therefore, has no solvents leaking out of the
sealant, leaving behind leak paths. Finally, it provides 100% sealing capability and does not shrink when curing to allow failure at a later date.
APPLICATIONS
Typical applications are in sealing of all types of metal threaded connections (up to 2 inches) against water, oil, grease, and most common materials
conveyed by pipes. Compatible with pipe containing liquid propane.
It is extensively used on pressure vessels, air compressors, hydraulic systems, tanks, etc. for positive vibration proof sealing.
Superdope is compatible with Sprinkler Systems that include AntiFreeze Solutions such as Propylene Glycol and Glycerin when installed per NFPA
Standards.
NOT SUITABLE FOR USE WITH OXYGEN OR CHLORINE
USEFUL HINTS/NOTES
Where cure speed is extended due to low temperatures or inactive surfaces, activator can be used. Best results are found if Instant Pipe Sealant is
applied to 2nd or 3rd threadforms. Excess can be wiped away, any migration into lines will not solidify and can be flushed away during commissioning.
PROPERTIES
Resists most solvents.
Temperature range: -65°F to +400°F.
Volatile Organic Compounds: 5.4% based on weight (mg/liter) 59.4 grams per liter
INSTRUCTIONS FOR USE
Ensure parts are clean, dry and free from oil and grease.
PROCEDURE FOR APPLICATION
Product is normally hand applied from the tube or brushed onto threads.
COMPATIBLE ACCELERATORS/PRIMER
Primers such as (Primer T) can be used. However, up to 30%
strength loss can occur when using primers.
SUPERDOPE INSTANT PIPE SEALANT
With Polytetrafluoroethylene
TECHNICAL FEATURES
Resin: . . . . . . . . . . . . . . . . . . . . . . Dimethacrylate
Color: . . . . . . . . . . . . . . . . . . . . . . White
Cure Speed with Activator: . . . . . . <10 minutes
Cure Speed without Activator: . . . < 45 minutes
Viscosity (Thixotropic): . . .. . . 150,000-400,000cps
Gap Fill: . . . . . . . . . . . . . . . . . . . . . N/A
Flash Point: . . . . . . . . . . . . . . . . . . >200°F
Shelf Life: . . . . . . . . . . . . . . . . . 12 months @ 68°F
Specific Gravity: . . . . . . . . . . . . . . 1.11 @ 75°F
Max. Operating Temperature: . . . . . . . . . 400°F
STORAGE
Store in a cool area out of direct sunlight. Shelf Life: 12 months @ 68°F.
PRESENTATION
Bottles: . . . . . . . . .. . . 10ml, 50ml , 250ml & 1ltr
GENERAL INFORMATION
This Product is not recommended for use in: pure oxygen, oxygen rich
systems or for chlorine or other strong oxidizing material environments.
Normally not recommended for plastic. (particularly thermoplastic materials)
where stress cracking of the plastic could result.
HEALTH & SAFETY IN USE
IRRITANT: Contains Methacrylate Esters which can irritate the eyes,
the respiratory organs and the skin. In case of contact with the skin, wash immediately with plenty of water.
Country of Origin:
SuperDope Anaerobic Thread Sealant is a manufactured and packaged in the United States.
The information contained herein is produced in good faith and is believed to be reliable but is for guidance only. ARGCO and its agents cannot
assume liability or responsibility for results obtained in the use of its product by persons whose methods are outside or beyond our control. It is the
user's responsibility to determine the suitability of any of the products, methods of use, or preparation prior to use, mentioned in our literature. It is
the user's responsibility to observe and adapt such precautions as may be advisable for the protection of personnel and property in the handling and
use of any of our products.
FOR MORE INFORMATION CALL ARGCO AT 800-854-1015
OR LOG ONTO WWW.ARGCO.COM
