Arctic Air AF49, AR49 Specifications

Stainless design.

Stellar performance.

Superior value.

AR49

Refrigerator

AF49

Freezer

• Tested to NSF

Standard 7
requirements
for open food
storage.

• Arctic Air

products must
pass numerous
quality control
inspections
throughout the
manufacturing
process. All
products are
operated and
monitored for
a minimum
of thirteen
hours prior to
packaging and
shipping.

Two Door Reach-in
Refrigerators and Freezers

• All Arctic Air

products come
with full one
year parts and
labor warranties
and a five year
compressor
warranty.

Two Door Reach-in

ANSI/NSF 7

Refrigerators and Freezers

Stainless design. Stellar performance. Superior value.

• Exterior cabinet construction

consists of full stainless
steel front and sides.

• Electronic thermostat with
external digital LED display

for accurate control and
easy reading.

• Interior cabinet is bright

white aluminum liner with
full stainless steel floor
with coved corners.

• Six adjustable, heavy-duty

epoxy coated wire shelves.

• Self contained capillary

tube system using
environmentally friendly
CFC free refrigerant
(R404A in freezers and
R134A in refrigerators).

• Condensate heating element

built into condensate pan
for efficient evaporation of

excess water.

• Bottom mounted

compressor for more
efficient operation in coolest
area of the kitchen.

• Front accessible, bottom

mounted condensing unit
is mounted on slide out
rack for easy maintenance.

• Self closing doors that

remain open at 90 degrees.

• Magnetic door gaskets
are removable and
replaceable without tools.

• Freezer doors have integral

factory installed heating
element to eliminate
condensation.

• Lockable doors with foamed­in-place recessed handles.

• Larger fan motors and

blades for more efficient air
flow ensuring faster recovery
times.

• Easy to mount casters
(two lockable) are standard
with all units.

Tested to NSF Standard 7

•

requirements for open food
storage.

•

All Arctic Air products come

with full one year parts and
labor warranties and a five year
compressor warranty.

Model External Dimensions Doors Shelves Cubic Temperature Cord HP Amps NEMA Crated
Number Width Depth* Height** Feet Range Length Plug Weight (lbs.)

AR49 549 32.759 82.759 2 6 49 337F to 417F 9 1/2 7 5-15P 455

AF49 549 32.759 82.759 2 6 49 –107F to +107F 9 1 12 5-15P 485

*Depth with door open 907 — AR49/AF49 = 57.759 **Height includes 69 for casters

Optional Shelf Kit (#65056K)

Each kit contains one shelf and
four mounting clips.
