Arctic TV Basic L User Manual

Ultra-Slim TV Wall Mount
Main Features
• Secure hold thanks to the stable lock system even for the largest TV sets
• Ultra-slim design for an elegant TV suspension
• Space-saving attachment on the wall
• Simple and quick installation with enclosed spirit level
www.arctic.ac
Designed by ARCTIC
2
TV Basic L
Ultra-Slim TV Wall Mount
Let your flat TV screen hover on the wall! The ultra-slim TV Basic L wall mount is the ideal solution for an almost invisible installation even for the largest TV screens.
Specificati ons
Materi al Screen S ize Maximu m Load Distan ce between Wall an d TV Weight
Package Contents
Wall Mounting Bar x 1
TV Mount x 2
Metal
Washer x 8
M8 (12 mm) x 4
Level Gauge x 1
M5 (12 mm) x 4
M8 (30 mm) x 4
VESA Compatib ility (W x H in mm)
TV Basic S TV Basic L
TV Flex S TV Flex L
75 x 75
X X X X
X X X X X X X X X X X X X X X X X X
X X X X X
100 x 200 200 x 100 200 x 200
100 x 100
X X X X X X X X X X X X X X
Steel 42”–78” 45 kg/99 l bs 14 mm
1.03 kg
Spacer x 4
M5 (30 mm) x 4
TV Anchor x 1
Plastic Peg x 4
M6 (12 mm) x 4
200 x 300 280 x 150 300 x 200 300 x 300
TV Anchor with
Back Stand x 1
M6 (30 mm) x 4
Mounting Screw x 4
400 x 200
400 x 300
600 x 200 600 x 400 600 x 600 800 x 400 800 x 600 800 x 800
400 x 400
Designed by ARCTIC
Ultra-Slim TV Wall Mount
Ultra-Slim Design for an Elegant TV Suspension
The ultra -slim TV Basic L w all mount is an el egant soluti on for the attac hment of the tel evision and fi ts perfectly
Space-Saving Attachment on the Wall
14 mm
Only 14 mi limeters lie b etween your TV s creen and the wa ll. Thus, th e TV Basic L saves you s pace and simul taneously create s an optical hig hlight in your l iving room.
in every fu rnishing con cept.
Secure Hold Thanks to Lock System
Simple and Quick Installation
In almos t no time at all, th e lightweigh t holder is moun ted on the wall . All you need for i nstallatio n, is a power dril l. An enclos ed spirit level e nsures an opti mal adjustme nt.
Thanks t o the stable loc k-system wit h secured bracke ts, the TV Basic L h olds your TV, which can we ight up to 45 kg, sa fely
on the wal l. With this TV wa ll mount, scre ens with a size fr om 42" to 78" will f ind their well -deserved pl ace.
Designed by ARCTIC
170220_r1_EN
