ARCTIC P604BT Users Manual
Music Stutters
ButtonsButtons
Function Diagram
Switch On / Off
multifunction button
LED indicator
Micro-USB charging
4
Microphone
5
Previous track
6
Next track
Switch the Headset On or Off
Switch on
Press the multifunction
button for 3 seconds until
the blue LED lights up
Switch off
Press the multifunction
button for 3 seconds until
the red LED lights up
Getting Connected
The P604 Wireless allows you to pair with your mobile
device in 2 different ways:
A. Bluetooth Pairing
1. Switch on the P604 Wireless by Press the
Multifunction Button for 3 seconds.
2. The P604 Wireless automatically enters pairing mode
shown by the red and blue LED flash alternately.
3. Turn on Bluetooth on your phone and pair it with the
headphone.
Example: iOS
Press Settings > Bluetooth and switch Bluetooth on
> P604 Wireless > Pair
Select
Bluetooth
Click Settings
ON
P604 Wireless
Select
P604 Wireless
OFF
Switch On
Bluetooth
P604 Wi reles s
Select
P604 Wireless
Bluetooth
is On
Example: Android 4.0
Press Menu > Settings > Switch on Bluetooth >
Bluetooth > Search for devices > P604 Wireless > Pair
Click
Settings
Click Search
for Devices
Switch On
Bluetooth
P604 Wireless
Now
Connected
ON
Bluetooth
is On
P604 Wi reles s
Now
Connected
ON
ON
Notes:
- Pairing mode will last up to ten minutes or until a device is
found, two tones will sound to let you know when pairing has
stopped.
- If you exceed the effective range of approx. 10M (33ft) the
headphone will disconnect and will automatically reconnect if
the speaker re-enters the effective range within ten minutes.
How to wear the headset
B. NFC One Touch Pairing
(only for NFC enabled phones)
1. Switch on the P604 Wireless by Press the
Multifunction Button for 3 seconds.
2. Enable NFC on your mobile device.
3. Slide your phone very slowly from top to bottom
across the shown area of the right side of the
headphone until you hear a beep and a confirmation
message comes up on your mobile device.
4. Play music!
NFC antenna
Phone Operations
If the mobile device that is paired (via Bluetooth) with the
P604 Wireless headphone is a cellular phone you can:
Answer Call
End Call
Refuse Call
Switch Call Press and hold for 2 seconds
Press the once.
Press the once.
Press and hold for 2 seconds.
while in a call.
LED Indicators
Status
Charging
Battery Full
On and Paired
Paring Mode
Low Battery
Indication
Red LED on
Blue LED on
Blue LED flashes
Red and Blue LED will flash alternately
Red LED flashes
Reconnection
1. Turn on Bluetooth on phone.
2. Switch on the P604 Wireless by pressing the
multifunction button for 3 seconds.
3. If your device was the latest one to be paired with
the P604 Wireless it will connect automatically
otherwise please repeat pairing section.
Charging the headset
The P604 Wireless can be charged while switched on
or off.
1. Insert the micro USB cable into the P604 Wireless
and the USB side into a power source.
2. When the Blue light on constantly the P604
Wireless is fully charged.
Smart
Charger
4800
It is recommended to fully charge before initial use for
better battery life.
USB Chargers are available at
chargers.arctic.ac
