Arçelik OCD608YI User manual

Built

Built----In Hob

BuiltBuilt

OCD 608 YI

OCD 608 YI

OCD 608 YI OCD 608 YI

In Hob

In HobIn Hob

185261329

Important information or useful hints

Warning of hazardous situations with

Warning of electric shock.

Warning of

risk of fire.

Warning of hot surfaces.

Please read this user manual first!

Please read this user manual first!

Please read this user manual first!Please read this user manual first!

Dear Customer,
Thank you for purchasing this product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully before using the product and keep it
as a reference for future use. If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences between models
will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

about usage.

regard to life and property.

TABLE OF CONTENTS

1 Important instructions and warnings

for safety and environment 4

General safety ................................................ 4

Electrical safety .............................................. 4

Safety when working with gas ......................... 5

Product safety ................................................ 6

Intended use .................................................. 7

Safety for children .......................................... 7

Compliance with AEEE regulation and disposal of

waste products ........................................ 7

Package information ....................................... 8

2 General information 9

Overview ....................................................... 9

Package contents ........................................... 9

Technical specifications ................................ 10

3 Installation 11

Before installation ........................................ 11

Installation and connection ........................... 12

Future Transportation .................................. 14

4 Preparation 15

Tips for saving energy ................................. 15

Initial use .................................................... 15

First cleaning of the appliance ...................... 15

5 How to use the hob 16

General information about cooking ............... 16

Using the hobs ............................................ 16

6 Maintenance and care 18

General information ..................................... 18

Cleaning the hob ......................................... 18

7 Troubleshooting 19

3/EN

1 Important instructions and warnings for safety and environment

This section contains safety
instructions that will help protect from
risk of personal injury or property
damage. Failure to follow these
instructions shall void any warranty.

General safety

• This appliance can be used by

children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.

• Installation and repair procedures

must always be performed by
Authorized Service Agents. The
manufacturer shall not be held
responsible for damages arising
from procedures carried out by
unauthorized persons which may
also void the warranty. Before
installation, read the instructions
carefully.

• Do not operate the product if it is

defective or has any visible
damage.

4/EN

• Control that the product function

knobs are switched off after every
use.

Electrical safety

• If the product has a failure, it

should not be operated unless it
is repaired by the Authorized
Service Agent. There is the risk of
electric shock!

• Only connect the product to a

grounded outlet/line with the
voltage and protection as
specified in the “Technical
specifications”. Have the
grounding installation made by a
qualified electrician while using
the product with or without a
transformer. Our company shall
not be liable for any problems
arising due to the product not
being earthed in accordance with
the local regulations.

• Never wash the product by

spreading or pouring water onto it!
There is the risk of electric shock!

• ever touch the plug with wet

hands! Never unplug by pulling on
the cable, always pull out by
grabbing the plug.

• The product must be unplugged

during installation, maintenance,
cleaning and repairing procedures.

• If the power connection cable for

the product is damaged, it must
be replaced by the manufacturer,

its service agent or similary
qualified persons in order to avoid
a hazard.

• The appliance must be installed

so that it can be completely
disconnected from the network.
The separation must be provided
either by a mains plug, or a
switch built into the fixed
electrical installation, according to
construction regulations.

• Any work on electrical equipment

and systems should only be
carried out by authorized and
qualified persons.

• In case of any damage, switch off

the product and disconnect it
from the mains. To do this, turn
off the fuse at home.

• Make sure that fuse rating is

compatible with the product.

Safety when working with gas

• Any works on gas equipment and

systems may only be carried out
by authorised qualified persons
who are Gas Safe registered.

• Prior to the installation, ensure

that the local distribution
conditions (nature of the gas and
gas pressure) and the adjustment
of the appliance are compatible.

• This appliance is not connected to

a combustion products or
evacuation device. It shall be
installed and connected in
accordance with current

installation regulations. Particular
attention shall be given to the
relevant requirements regarding
ventilation; See Before installation,
page 11

• The use of gas cooking appliance

results in the production of heat
and moisture in the room in which
it is installed. Ensure that the
kitchen is well ventilated: keep
natural ventilation holes open or
install a mechanical ventilation
device (mechanical extractor
hood). Prolonged intensive use of
the appliance may call for
additional ventilation, for example
increasing the level of the
mechanical ventilation where
present.

• Gas appliances and systems must

be regularly checked for proper
functioning. Regulator, hose and
its clamp must be checked
regularly and replaced within the
periods recommended by its
manufacturer or when necessary.

• Clean the gas burners regularly.

The flames should be blue and
burn evenly.

• Good combustion is required in

gas appliances. In case of
incomplete combustion, carbon
monoxide (CO) might develop.
Carbon monoxide is a colourless,
odourless and very toxic gas,

5/EN

which has a lethal effect even in
very small doses.

• Request information about gas

emergency telephone numbers
and safety measures in case of
gas smell from you local gas
provider.

What to do when you smell gas

• Do not use open flame or do not

smoke. Do not operate any
electrical buttons (e.g. lamp
button, door bell and etc.) Do not
use fixed or mobile phones. Risk
of explosion and toxication!

• Open doors and windows.

• Turn off all valves on gas

appliances and gas meter at the
main control valve, unless it's in a
confined space or cellar.

• Check all tubes and connections

for tightness. If you still smell gas
leave the property.

• Warn the neighbours.

• Call the fire-brigade. Use a

telephone outside the house.

• Do not re-enter the property until

you are told it is safe to do so.

Product safety

• The appliance and its accessible

parts become hot during use.
Care should be taken to avoid
touching heating elements.
Children less than 8 years of age
shall be kept away unless
continuously supervised.

• Never use the product when your

judgment or coordination is
impaired by the use of alcohol
and/or drugs.

• Be careful when using alcoholic

drinks in your dishes. Alcohol
evaporates at high temperatures
and may cause fire since it can
ignite when it comes into contact
with hot surfaces.

• Do not place any flammable

materials close to the product as
the sides may become hot during
use.

• Keep all ventilation slots clear of

obstructions.

• Do not use steam cleaners to

clean the appliance as this may
cause an electric shock.

• Unattended cooking on a hob with

fat or oil can be dangerous and
may result in fire. NEVER try to
extinguish a fire with water, but
switch off the appliance and then
cover flame e.g. with a lid or a
fire blanket.

• Danger of fire: Do not store items

on the cooking surfaces.

• If the surface is cracked, switch

off the appliance to avoid the

possibility of electric shock.
For the reliability of the fire of the
product;

• Make sure the plug is fitting to

socket as well for not cause to

spark.

6/EN

• Do not use damaged or cutted or

extension cable except the
original cable.

• Make sure that not whether liquid

or moisture on the socket is
pluged to product .

• Make sure your gas connection is

installed as well for not cause the
gas leakage.

• Electrical and/or gas products are

dangerous to children. Keep

children away from the product

when it is operating and do not

allow them to play with the

product.

• Do not place any items above the

appliance that children may reach

for.

Intended use

• This product is designed for

domestic use. Commercial use
will void the guarantee.

• This appliance is for cooking

purposes only. It must not be
used for other purposes, for
example room heating.

• The manufacturer shall not be

liable for any damage caused by
improper use or handling errors.

• Service life of your product is 10

years. Manufacturer shall provide
the required spare parts for the
product to perform as defined
during this period.

Safety for children

• Accessible parts may become hot

during use. Young children should
be kept away.

• The packaging materials will be

dangerous for children. Keep the
packaging materials away from
children. Please dispose of all
parts of the packaging according
to environmental standards.

Compliance with AEEE regulation
and disposal of waste products

• This product does not contain

harmful and forbidden materials

described in the "Directive on the

Restriction of the Use of Certain

Hazardous Substances in Waste

Electrical and Electronic

Equipment" (AEEE) issued by the

T.R. Ministry of Environment and

Urbanization.

Complies with the AEEE Directive.

• This product has been

manufactured with high quality

parts and materials which can be

reused and are suitable for

recycling. Therefore, do not

dispose the product with normal

domestic waste at the end of its

service life. Take it to a collection

point for the recycling of electrical

and electronic equipment. Please

consult your local authorities to

learn the nearest collection point.

Help protect the environment and

natural resources by recycling

7/EN

used products. Before disposing
of the product, cut off the power
cable plug and make the door
lock (if any) unusable to avoid
dangerous conditions to children.

Package information

• Packaging materials of the

product are manufactured from
recyclable materials in

accordance with our National

Environment Regulations. Do not

dispose of the packaging

materials together with the

domestic or other wastes. Take

them to the packaging material

collection points designated by

the local authorities.

8/EN

1 Tempered glass

2 Pan support

3 Base cover

4 Assembly clamp

5 Control panel

1 Auxiliary burner Front right

2 Rapid burner Front left

3 Normal burner Rear left

4 Normal burner Rear right

Accessories supplied can vary depending on

2 General information

Overview

Package contents

the product model. Not every accessory
described in the user manual may exist on
your product.

1. User manual

User manual

User manualUser manual

2. Coffee pot adaptor

Coffee pot adaptor

Coffee pot adaptorCoffee pot adaptor

Used for coffe pots.

9/EN

Voltage / frequency

220-230 V ~ 50

Hz

Cable type / section

H05RR

-FG

Cable length

max. 2 m

Category of gas product

2H3B/P

Gas type / pressure

NG G 20/20 mbar

Total gas consumption

7.4 kW

LPG G 30/30 mbar

– optional

/ - / - / - / - / - / - / - /

External dimensions (height / width / depth)

98

mm/590

mm/510

mm

Installation dimensions (width / depth)

560 mm/480

-

490 mm

Burners

BurnersBurners

Burners

Front right

Auxiliary burner

Auxiliary burnerAuxiliary burner

Auxiliary burner

Power 1000 W

Front left

Rapid burner

Rapid burnerRapid burner

Rapid burner

Power 2900 W

Rear left

Normal burner

Normal burnerNormal burner

Normal burner

Power 1750 W

Rear right

Normal burner

Normal burnerNormal burner

Normal burner

Power 1750 W

Technical specifications may be changed

without prior notice to improve the quality of

Figures in this manual are schematic and

Values stated on the product labels or in the

Technical specifications

Converting the gas type / pressure§

the product.

may not exactly match your product.

3 x 0,75 mm2

II

/ / – / – / – /

documentation accompanying it are
obtained in laboratory conditions in
accordance with relevant standards.
Depending on operational and
environmental conditions of the product,
these values may vary.

10/EN

Preparation of location and electrical and

Prior to installation, visually check if the

3 Installation

Refer to the nearest Authorised Service Agent for
installation of the product. Make sure that the
electric and gas installations are in place before
calling the Authorised Service Agent to have the
product ready for operation. If not, call a qualified
electrician and fitter to have the required
arrangements made. The manufacturer shall not
be held responsible for damages arising from
procedures carried out by unauthorized persons
which may also void the warranty.

gas installation for the product is under
customer’s responsibility.

DANGER:

The product must be installed in
accordance with all local gas and/or
electrical regulations.

DANGER:

product has any defects on it. If so, do
not have it installed.

Damaged products cause risks for your
safety.

Before installation

The hob is designed for installation in a
commercial worktop. A safety distance must be
left between the appliance and the kitchen walls
and furniture. See figure (values in mm).

• It can also be used in a free standing

position. Allow a minimum distance of 750

mm above the hob surface.

• (*) If a cooker hood is to be installed above

the cooker, refer to cooker hood

manufacturer' instructions regarding

installation height (min 650 mm)

• Remove packaging materials and transport

locks.

• Surfaces, synthetic laminates and adhesives

used must be heat resistant (100 °C

minimum).

• The worktop must be aligned and fixed

horizontally.

• Cut aperture for the hob in worktop as per

installation dimensions.

11/EN

Room size

Room sizeRoom size

Room size

Ventilation opening

Ventilation openingVentilation opening

Ventilation opening

not required

In the cellar or

Room ventilation

All rooms require an openable window, or
equvalent, and some rooms will require a
permanent vent as well.
The air for combustion is taken from the room air
and the exhaust gases are emitted directly into
the room.
Good room ventilation is essential for safe
operation of your appliance. If there is no window
or door available for room ventilation, an extra
ventilation must be installed.
The appliance may be located in a kitchen,
kitchen/diner or a bed-sitting room, but not in a
room containing a bath or shower. The appliance
must not be installed in a bed-sitting room of
less than 20m3.
Do not install this appliance in a room below
ground level unless it is open to ground level on
at least one side.

smaller than 5 m3 min. 100 cm2
5 m3 to 10 m3 min. 50 cm2
greater than 10 m3'den

min. 65 cm2

basement

Installation and connection

• Product can only be installed and connected

in accordance with the statutory installation

rules.

Electrical connection

Connect the product to a grounded outlet/line
protected by a fuse of suitable capacity as stated
in the "Technical specifications" table. Have the
grounding installation made by a qualified
electrician while using the product with or
without a transformer. Our company shall not be
liable for any damages that will arise due to
using the product without a grounding installation
in accordance with the local regulations.

12/EN

mains supply only by an authorised and

warranty period starts only after correct

Power cable plug must be within easy reach

Your product is equipped for natural gas

DANGER:

The product must be connected to the

qualified person. The product's

installation.

Manufacturer shall not be held responsible
for damages arising from procedures
carried out by unauthorised persons.

DANGER:

The power cable must not be clamped,
bent or trapped or come into contact
with hot parts of the product.

A damaged power cable must be replaced
by an Authorised Service Agent. Otherwise,
there is risk of electric shock, short circuit
or fire!

• Connection must comply with national

regulations.

• The mains supply data must correspond to

the data specified on the type label of the
product. Type label is at the rear housing of
the product.

• Power cable of your product must comply

with the values in "Technical specifications"
table.

DANGER:

Before starting any work on the
electrical installation, disconnect the
product from the mains supply.

There is the risk of electric shock!

after installation (do not route it above the
hob).

Plug the power cable into the socket.

Gas connection

DANGER:

Product can be connected to gas
supply system only by an authorised
and qualified person.

Risk of explosion or toxication due to
unprofessional repairs!
Manufacturer shall not be held responsible
for damages arising from procedures
carried out by unauthorised persons.

DANGER:

Before starting any work on the gas
installation, disconnect the gas supply.

There is the risk of explosion!

• Gas adjustment conditions and values are

stated on labels (or ion type label).

(NG).

• Natural gas installation must be prepared

before installing the product.

• There must be a flex pipe at the outlet of

the installation for the natural gas

connection of your product and the tip of

this pipe must be closed with a blind plug.

Service Representative will remove the blind

plug during connection and connect your

product by means of a straight connection

device (coupling).

• Make sure that the natural gas valve is

readily accessible.

• If you need to use your product later with a

different type of gas, you must consult the

Authorised Service Agent for the related

conversion procedure.

If there is a built

If there is a built----in oven installed under the

If there is a builtIf there is a built
hob;

hob;

hob;hob;

in oven installed under the

in oven installed under the in oven installed under the

• Gas hose must be routed in a way not to

touch the sharp edges and corners beneath

the hob and not to be kinked or twisted.

If you will make the gas connection from left

hand side when viewed from your position,

fix the hose with clamps.

13/EN

1 Hob (appearance from below)

2 Hose tip

3 Hose

4 Clamp

5 Oven

* min. 20 & max. 40 mm

1 Hob

2 Screw

3 Installation clamp

4 Counter

5 Sealing gasket

Making connection

s to different holes is not

Flame must be blue and have a regular

Check the general appearance of your

Installing the product

1. The sealing gasket provided in the package
must be applied on the lower casing bend
around the hob as shown in the figure,
during installation of the hob.

2. Place the hob on the counter and align it.

3. Using the installation clamps secure the hob
by fitting through the holes on the lower
casing.

Place the burner plates, burner plate caps and
grills back to their seating after installation.

a good practice in terms of safety since it
can damage the gas and electrical system.

Final check

1. Open gas supply.

2. Check gas installations for secure fitting and
tightness.

3. Ignite burners and check appearance of the
flame.

shape. If the flame is yellowish, check if the
burner cap is seated securely or clean the
burner.

Future Transportation

• Keep the product's original carton and

transport the product in it. Follow the
instructions on the carton. If you do not
have the original carton, pack the product in
bubble wrap or thick cardboard and tape it
securely.

• Secure the caps and pan supports with

adhesive tape.

Rear view (connection holes)

Rear view (connection holes)

Rear view (connection holes)Rear view (connection holes)

14/EN

product for any damages that might have
occurred during transportation.

The surface might get damaged by some

Do not use harsh abrasive cleaners or sharp

4 Preparation

Tips for saving energy

The following information will help you to use
your appliance in an ecological way, and to save
energy:

• Defrost frozen dishes before cooking them.

• Use pots/pans with cover for cooking. If

there is no cover, energy consumption may
increase 4 times.

• Select the burner which is suitable for the

bottom size of the pot to be used. Always
select the correct pot size for your dishes.
Larger pots require more energy.

Initial use

First cleaning of the appliance

detergents or cleaning materials.
Do not use aggressive detergents, cleaning
powders/creams or any sharp objects
during cleaning.

metal scrapers to clean the oven door glass
since they can scratch the surface, which
may result in shattering of the glass.

1. Remove all packaging materials.

2. Wipe the surfaces of the appliance with a
damp cloth or sponge and dry with a cloth.

15/EN

Never fill the pan with oil more than

5 How to use the hob

General information about cooking

one third of it. Do not leave the hob
unattended when heating oil.
Overheated oils bring risk of fire. Never
attempt to extinguish a possible fire

attempt to extinguish a possible fire

attempt to extinguish a possible fire attempt to extinguish a possible fire
with water!

with water! When oil catches fire,

with water!with water!
cover it with a fire blanket or damp
cloth. Turn off the hob if it is safe to do
so and call the fire department.

• Before frying foods, always dry them well

and gently place into the hot oil. Ensure
complete thawing of frozen foods before
frying.

• Do not cover the vessel you use when

heating oil.

• Place the pans and saucepans in a manner

so that their handles are not over the hob to
prevent heating of the handles. Do not place
unbalanced and easily tilting vessels on the
hob.

• Do not place empty vessels and saucepans

on cooking zones that are switched on.
They might get damaged.

• Operating a cooking zone without a vessel

or saucepan on it will cause damage to the
product. Turn off the cooking zones after
the cooking is complete.

• As the surface of the product can be hot, do

not put plastic and aluminum vessels on it.
Such vessels should not be used to keep
foods either.

• Use flat bottomed saucepans or vessels only.

• Put appropriate amount of food in

saucepans and pans. Thus, you will not
have to make any unnecessary cleaning by
preventing the dishes from overflowing.
Do not put covers of saucepans or pans on
cooking zones.
Place the saucepans in a manner so that
they are centered on the cooking zone.
When you want to move the saucepan onto
another cooking zone, lift and place it onto

Never

Never Never

the cooking zone you want instead of sliding
it.

Gas cooking

• Size of the vessel and the flame must match

each other. Adjust the gas flames so that
they will not extend the bottom of the vessel
and center the vessel on saucepan carrier.

16/EN
