ARC Audio MPAK-2 Brochure

MPAK

MPAK 1

Includes­(1) KS125.2 Mini

(1) KS5026 5.25” Coaxial Speakers
(1) Motorcycle Wire and Installation Kit
(1) Step by Step Installation Manual

MPAK 2

Includes­(1) KS125.2 Mini

(1) KS5026 5.25” Component Speakers
w/ Separate Tweeters and X-Overs
(1) Motorcycle Wire and Installation Kit
(1) Step by Step Installation Manual

MPAK 3

Includes­(1) KS125.2 Mini

(1) KS6026 6.5” Coaxial Speakers
(1) KS6026 6.5” Component Speakers
w/ Separate Tweeters and X-Overs
(1) Motorcycle Wire and Installation Kit
(1) Step by Step Installation Manual

MPAK

-Designed and tested by factory trained
technicians at Mitchells Modesto Harley
Davidson

-MPAK kits are designed to bolt into your HD
motorcycle's factory locations in the front
fairing

-No Loss of space in your side bags or touring
pack

-High efficiency non-digital amplifier design
works within the parameters of the factory
motorcycle charging system

-Speakers bolt directly to the factory
locations with no modifications or changes
needed to the mounting area

removal required for separate component tweeter installation)

-Includes full step by step color instruction
manual for an easy do it yourself installation

-Allows you to upgrade your HD Audio system
and still retain all factory handlebar stereo
controls

-Wire hanress and installation kit contents
selected by Mitchells Modesto Harley Davidson
technicians so that the stereo will not void the
motorcycles factory electrical warranty. (At no
point in this installation does the motorcycle’s
main harness need to be cut!) - (No Warranty
voiding “T” or “Y” harnesses to plug into the
radio)

4719 Green Leaf Circle #4
Modesto CA, 95356

(Holes or selected gauge

Toll Free -

866.258.0288

Motorcycle Audio

- MPAK Kits

- Mini Amplifiers

- OEM Fit
Speakers

- Wiring
Harness

Performance Audio
Products For -

-HD Road -HD Electra -HD & Non-HD
Glide Models Glide Models Baggers

WWW.ARCAUDIO.COM/MOTORCYCLE.ASP

Component Speakers

Mini Amplifiers

Coaxial Speakers

KS 5006

Diameter 5 1/4"
Max Power 100 watts
Nor. Power 50 watts
Sensitivity 87dB
Frequency response 70Hz-20KHz
IMP. 4 Ohm
Protection PTC

- The KS125.2 Mini is capable of
being installed inside your HD
motorcycle fairing allowing you
have that high performance sound
without the loss of valuable
storage space in your side bags.

- Designed to work with your
factory HD electrical system the
KS125.2 Mini allows you to
upgrade your audio system
without exceeding the electrical
capacity of your motorcycle.

KS 6006

Diameter 6 1/2"
Max Power 100 watts
Nor. Power 50 watts
Sensitivity 87dB
Frequency response 60Hz-20KHz
IMP. 4 ohm
Protection PTC

KS125.2 MINI (Fairing Install Compatable)

Power output RMS @ 4 ohms 2 X 70 watts
Power output RMS @ 2 ohms 2 X 125 watts
Power output RMS @ 4 ohms Bridged 1 X 250 watts
Transient Distortion (100W) <.05% @ 4ohms
Frequency Response 20Hz-20KHz
Signal to Noise Ratio >92dB
Bass Boost 0 - 15dB @ 45Hz
Crossover (Butterworth) 55Hz-550Hz
Fuse 30A x 1
Size 8.25”(L) X 4.85”(W) X 1.75”(H)

KS125.4 MINI (Bag Install Only)

Power output RMS @ 4 ohms 4 X 70 watts
Power output RMS @ 2 ohms 4 X 125 watts
Power output RMS @ 4 ohms Bridged 2 X 250 watts
Transient Distortion (100W) <.05% @ 4ohms
Frequency Response 10Hz-50KHz -3dB
Signal to Noise Ratio >92dB
Bass Boost 0 - 15dB @45Hz
Crossover (Butterworth) 55Hz-550Hz
Fuse 25A X 2
Size 11.5”(L) X 5.15”(W) X 1.7”(H)

KS500.1 MINI (Bag Install Only)

Power output RMS @ 4 ohms 1 x 300 watts
Power output RMS @ 2 ohms 1 X 500 watts
Transient Distortion (100W) <.05% @ 4ohms
Frequency Response 10Hz-50KHz -3dB
Signal to Noise Ratio >92dB
Bass Boost 0 - 15dB @45Hz
Crossover (Butterworth) 55Hz-550Hz
Fuse 25A X 2
Size 11.5”(L) X 5.15”(W) X 1.7”(H)

With conditions ranging from extremely hot and dry to
cold, wet and raining, the open enviorment will test the
design and reliability of all electronic equipement on your
HD Motorcycle.
For this reason all ARC Audio products are tested by
third party facilities with state of the art enviormental
testing equipment to ensure that our products will hold up
to these adverse conditions and allow you trouble free
operation of your new audio system.

KS 5026

Diameter 5 1/4"
Max Power 75 watts
Nor. Power 35 watts
Sensitivity 86dB
Frequency response 80Hz-20KHz
IMP. 4 Ohm

- A built in hi Level interface
on all ARC Mini amplifiers
allow you to keep your
factory radio with all of the
features and functions that
were designed for your HD
Motorcycle.

KS 6026

Diameter 6 1/2"
Max Power 100 watts
Nor. Power 50 watts
Sensitivity 86dB
Frequency response 60 Hz-20KHz
IMP. 4 Ohm

- All ARC Audio amplifiers
allow a smooth integration
into your factory audio
system, giving you the
ability to keep your factory
handle bar controls.

Adjustable cossovers and independent
gain controls allow for fine tuning of your
system to your specific application and
listening style, optimizing your overall
experience.

A high efficiency power supply helps
produce clean reliable power while
increasing the amplifier’s reliability and
stability. This feature allows the amplifier
to operate within the parameters of your
motorcycles electrical system

Low ESR self branded power caps
increase reserves for the power supply on
all MINI amplifiers. This increases
reliability, stability & effeciency of the
power supply during high demand listening

Wheels Courtesy of Sinister Wheels Wheels Courtesy of Sinister Wheels

periods.
