AquaBrew EX3 User Manual

elliptical

Owners Manual
Version 1.1

table of contents

Page

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Limited Home Use Warranty . . . . . . . . . . . . . . . . . . . . . . 3

Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . 4

Find a Certified Health Fitness Instructor . . . . . . . . . . . . 5

Getting Fit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Electronics Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Exercise Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Elliptical Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Congratulations on the purchase of your LifeSpan Home series exercise equipment.

To ensure safe and trouble free operation, we suggest that you read this Owners Manual and
follow its recommendations.

LifeSpan

™

and Intelli-Key™ are trademarks of PCE Health and Fitness. Any use of these trademarks,

without express written consent of PCE Health and Fitness is forbidden.

1

welcome to LifeSpan

™

We all know that exercise is a key component to achieving the level of Health and Wellness that all of us

desire. Regular activity prevents the development of numerous diseases, helps to reduce stress, leads to an

improved self image, weight loss and increased energy levels.

The LifeSpan Home series offer the discriminating consumer products that meet their exacting needs and

with many of the models we include commercial warranties that cover institutional use up to 6 hours per

day. The requirement for performance and durability is at the heart of each PRO series model. We start

with a robotically welded steel frame and add top of the line components to our patented EX-Link drive

system. The result is a smooth and consistent workout for every user that will last for years to come.

To make the Home series easy to use we include our Intelli-Key™ blue button system that simply and easily

steps each user through the program set-up process and for motivation we include resistance programs

and a heart rate control program to give our customers the programming variety they need to maintain

their workout routines.

Please read this manual thoroughly before assembly and operation of your LifeSpan elliptical. It includes

basic information on starting an exercise program, and safety tips that will assist you in reaching your goals

for a healthy lifestyle.

To keep your elliptical cross trainer in optimal condition, please pay attention to the maintenance and

cleaning section of this manual and remember that some kinds of service should only be performed by a

qualified service technician. If service is required, please contact your authorized PCE Health and Fitness

Retailer. If a question or problem arises that cannot be answered by your retailer, contact us:

PCE Health and Fitness

PO Box 981316

Park City, Utah 84098 –1316

Phone: [phone]

Fax: [phone]

www.pcefitness.com

Neither PCE Health and Fitness nor its representatives can accept responsibility for any damage or injury

incurred as a result of information presented in the manual except under the terms of the product warranty.

2

specifi cations

CONSOLE

PROGRAMMING

CONSOLE FEEDBACK

HEART RATE

CONSOLE OPERATIONS

POWER

20” STRIDE LENGTH

DRIVE SYSTEM

LEVELS OF RESISTANCE

RESISTANCE SYSTEM

ARM MOVEMENT

PEDALS

FLOOR SPACE

PRODUCT WEIGHT

FRAME

MAX. USER WEIGHT

FLOOR LEVELING

TRANSPORT

FRAME

PART S

LABOR

ELECTRONICS

AND PROGRAMMING

MECHANICS AND PERFORMANCE

RESIDENTIAL

WARRANTY

8 * 16 LED Program Matrix,

3 LED Display Panels, Storage Tray,

and Spring Loaded Magazine Rack

Manual, Random,

Mountain, Weight Loss,

Target Heart Rate,

Interval

Time, Distance, Speed, Calories,

Resistance Level, Heart Rate

Contact Hand Grips and

Optional Chest Strap

Intelli-Key™ blue light program setup

and operations

Plug-in (120 VAC to 6 VDC)

Patented EX-Link™ drive system

provides a bio-mechanically correct

symmetrical elliptical pattern that

models your natural walking gait and

places the pedals parallel to the ground

at the bottom of the pedal stroke.

Quiet-Stride drive system includes
commercial grade sealed bearings

and poly-V-belt with 10.5 to 1 flywheel

to pulley ratio providing smooth

resistance at all workout levels.

16 Levels

Motor Operated Eddy Current Brake.

Multi-position handlebars include

maximum movement up to 25” (64 cm).

Oversized slip resistant

16.8”L / 7.4”W (42 cm L / 18.4 cm W)

67”L / 29.2”W / 63”H

(167 cm L / 66.7 cm W / 157.5 cm H)

213 lbs / 97 kg

Extra heavy duty welded frame with

chrome plated running rails.

350 lbs / 159 kg

4 point adjustable foot pads

Front mounted transport wheels offer

easy moving.

LifeTime

3 Years

1 Year

3

limited home use warranty

The LifeSpan EX3 comes with the following limited warranty, which applies only to the use of the cross

trainer in the home, for residential, non-commercial purposes.

• Frame: Lifetime

• Parts: 3 year

• Labor: 1 year

PCE Health and Fitness warrants that the equipment it manufacturers is free from defects in material and

workmanship under normal use and service. The periods above are based on the date of purchase. During

these periods, PCE Health and Fitness will repair or replace any defective part. Free labor is included for

the first year.

If within the time frames specified above, any part of the LifeSpan EX3 fails to operate properly contact

your authorized PCE Health and Fitness retailer to report the problem. All labor shall be supplied by the

authorized retailer that sold your product and the product must be located within that retailer’s service

area. If you are unable to reach the dealer that you purchased the product from, contact PCE Health

and Fitness at our web site, www.pcefitness.com and click on Customer Support/Customer Service or

call 801-973-9993.

PCE Health and Fitness reserves the right to make changes and improvements to our products without

incurring any obligations to similarly alter any product purchased. In order to insure our product warranty

and to ensure the safe and efficient operation of your elliptical, only authorized parts can be used. The

warranty is void if any parts other than those provided by PCE Health and Fitness are used.

Exclusions and Limitations

• This warranty does not apply to any defects caused by negligence, misuse, improper assembly or

maintenance, accident, or an "act of god".

• This warranty does not apply to discoloration of paint or plastics.

• PCE Health and Fitness shall not be responsible for incidental or consequential damages.

• This warranty is nontransferable from the original owner.

Registration

You must register your LifeSpan product before a warranty claim can be processed. To complete your

registration card online, go to www.pcefitness.com and fill out the registration card online or fill out

the warranty card provided with your elliptical and mail it today. Registration Cards must be completed

and sent to PCE Fitness within 30 days of purchase to activate the Product Warranty on your LifeSpan

equipment. Product Warranties are not valid unless properly completed and sent to PCE Fitness within

this 30 day period.

Note: Read ALL instructions before using your LifeSpan elliptical.
