Unicode™ 2 Series Aluminum Control Stations and Switches
Catalog Page
16 pgs2.62 Mb0

Appleton Unicode™ 2 Series Aluminum Control Stations and Switches Catalog Page

Download
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Applications
• Local control stations and motor control stations for use
in hazardous areas covering the broadest possible range of applications.
— Power plants — Chemical and petrochemical plants
— Petroleum reneries
— Reverse osmosis plants — Pulp and paper processing plants — Various industrial applications
• Push buttons and selector switches are used in conjunction
with contactors or magnetic starters for remote control of motors in hazardous locations. They provide circuit control and/or selection.
• Pilot lights provide visual assurance that an electrical function is
being performed at a remote or hazardous location.
• For use in washdown areas.
Features
• Employs Ex de method of protection which eliminates the need
for external seals.
• Operators include push buttons, illuminated push buttons,
selector switches, control and load break switches and LED pilot lights.
• Pilot light employs high intensity single LED with lifetime of
100,000 hours that can be used at: — 12 Vac to 254 Vac 50/60 Hz — 12 Vdc to 60 Vdc
• Up to 3 contact blocks per actuator can be used.
• Contact block technical data:
— IEC rated operating voltage (Ue): 500 Vac – 110 Vdc
— IEC switching capacity:
– AC12: 16 Amp/400 Vac
– AC14: 10 Amp/400 Vac
– AC15: 6 Amp/500 Vac
– DC13: 2 Amp/24 Vdc and 1 Amp/110 Vdc
— NEMA switching capacity: A600: 10 Amp/600 Vac
• Selector switch technical data:
— IEC rated operating voltage: 690 Vac
— IEC rated operating current: maximum 16 Amp
— IEC switching capacity:
– AC1: 16 Amp/690 Vac
– AC15: 16 Amp/415 Vac
– AC3: 8 Amp/500 Vac
– AC3: 4 Amp/690 Vac
– AC3: 16 Amp/690 Vac
– DC1: 10 Amp/24 Vdc
– DC1: 6 Amp/60 Vdc
– DC1: 6 Amp/110 Vdc (2 contacts wired in series)
– DC1: 6 Amp/220 Vdc (3 contacts in series)
— NEMA switching capacity: A600: 10 Amp/600 Vac
• Enclosures are rated for IP66 with rmly secured gasket.
• Operators and contact blocks are spaced for easy wiring.
• Wide selection of termination methods available.
• Choice of DIN rail mounted high performance contact block
suitable for low intensity (less than 5 mA).
• TS35 rail mounted components are held securely in place
during operation and easily removed for service.
• Brass Inserts are provided for TS35 DIN rails or mounting plates to be installed inside the enclosure.
• Captive, corrosion resistant stainless steel cover screws.
Standard Materials
• Body and cover: aluminum with gray epoxy powder coating
• Cover screws: 304 stainless steel
Accessories
• Key for changing actuator blocks.
• Guard for mushroom head actuator.
• Padlockable guard.
• M5 and M6 earth stud.
• Combination drain and breather available in brass, polyamide and stainless steel.
Options
• Nameplates: Stainless Steel or Lamacoid with different color combinations.
• Padlocking facility at left, center, right or any position on selector switches.
• Padlocking facility for momentary and maintained push buttons.
• Special contact arrangements available, see Unicode™ 2 Series Customized Control Stations.
U83W2 PRA5A9
157
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
ATEX/IECEx Certification and Compliances
• Fiberglass Reinforced Polyester (FRP)
— Certication Type CSPe
— Gas: Zone 1 and 2
– Conforming to ATEX 94/9/CE: II 2 G
• Certification Type PCe
— Gas: Zone 1 and 2
– Conforming to ATEX 94/9/CE: II 2 G – Type of Protection: Ex de IIC/Ex demb IIC – Temperature Class: T6
— Dust: Zone 21 and 22
– Conforming to ATEX 94/9/CE: II2 D – Type of Protection: Ex tD A21
— Surface Temperature: T75 °C (T167 °F)
— Ambient Temperature: -55 °C to +60 °C (-67 °F to +140 °F)
(empty enclosure, temperature to be determine according
actuator) — CE Declaration of Conformity: 50221 — ATEX Certificate: LCIE 02 ATEX 6047 — Index of Protection according EN/IEC 60529: IP66 — Impact Resistance (shock): IK10
EURASEC Certification
• Certification Type PCe — EURASEC RU C-FR ГБ05.B.00911
158
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 1 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Momentary Push Buttons
Green insert ‘I’ + red insert ‘O’ with 1NO + 1NC momentary contact
1x green push button ‘I’ with 1NO momentary contact
1x red push button ‘O’ with 1NC momentary contact
Twin Momentary Push Buttons
1x green push button ‘I’ with 1NO contact 1x red push button ‘O’ with 1NC contact momentary contacts
1x green push button ‘I’ with 1NO + 1NC contact 1x red push button ‘O’ with 1NO + 1NC contact momentary contacts
Green
Green
Green
Entry
Location
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Green
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
Catalog
Number
U81W2A3
U81W4A3
U81Z3A3
U81X3A3
U81W2A5
U81W4A5
U81Z3A5
U81X3A5
U81W2A9
U81W4A9
U81Z3A9
U81X3A9
U81W2A5A9
U81W4A5A9
U81Z3A5A9
U81X3A5A9
U81W2A3A3
U81W4A3A3
U81Z3A3A3
U81X3A3A3
Additional configurations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for or aluminum. Not included if NPT hubs are selected.
159
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 1 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Emergency Stop
Red mushroom head push-pull 1NC maintained contact
Red mushroom head push-pull 1NO + 1NC maintained contact
Red mushroom head key release 1NC maintained contact
Red mushroom head key release 1NO + 1NC maintained contact
Push Pull Emergency Stop + Push Button
1x red mushroom head push-pull with 1NC maintained contact
1x green push button ‘I’ with 1NO momentary contact
Entry
Location
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Red
Green
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
Volume
dm
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
(164.80)
3
(in3)
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
Catalog Number
U81W2D9
U81W4D9
U81Z3D9
U81X3D9
U81W2D3
U81W4D3
U81Z3D3
U81X3D3
U81W2C9
U81W4C9
U81Z3C9
U81X3C9
U81W2C3
U81W4C3
U81Z3C3
U81X3C3
U81W2D9A5
U81W4D9A5
U81Z3D9A5
U81X3D9A5
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected.
160
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 1 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Mushroom Head Push Button
Black mushroom head push button 1NO + 1NC momentary contact
Red mushroom head push button 1NC momentary contact
Key Push Button
With key removable in both positions 1NO + 1NC maintained contact
With key removable in both positions 1NO maintained contact
With key removable in both positions 1NC maintained contact
Entry
Location
Bottom
Black
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
U81W2B3
U81W4B3
U81Z3B3
U81X3B3
U81W2R9
U81W4R9
U81Z3R9
U81X3R9
U81W2E3
U81W4E3
U81Z3E3
U81X3E3
U81W2E5
U81W4E5
U81Z3E5
U81X3E5
U81W2E9
U81W4E9
U81Z3E9
U81X3E9
Catalog
Number
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected.
161
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 1 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Pilot Light
Description/Function Diagram
1x red pilot light
1x green pilot light
1x blue pilot light
1x yellow pilot light
1x white pilot light
Entry
Location
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
Catalog Number
U81W2PR
U81W4PR
U81Z3PR
U81X3PR
U81W2PG
U81W4PG
U81Z3PG
U81X3PG
U81W2PB
U81W4PB
U81Z3PB
U81X3PB
U81W2PY
U81W4PY
U81Z3PY
U81X3PY
U81W2PW
U81W4PW
U81Z3PW
U81X3PW
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected. 12 Vac to 254 Vac 50/60 Hz - 12 Vdc to 60 Vdc.
162
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 1 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Twin Pilot Light
1x green pilot light
1x red pilot light
Illuminated Push Button
1x green illuminated push button with 1NO contact momentary contacts
1x red illuminated push button with 1NC contact momentary contacts
Twin Illuminated Push Button
1x green illuminated push button with 1NO contact 1x red illuminated push button with 1NC contact momentary contacts
Green
Green
Green
Red
Entry
Location
Bottom
Red
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Red
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
1.1
(2.43)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
U81W2PGPR
U81W4PGPR
U81Z3PGPR
U81X3PGPR
U81W2LG5
U81W4LG5
U81Z3LG5
U81X3LG5
U81W2LR9
U81W4LR9
U81Z3LR9
U81X3LR9
U81W2LG5LR9
U81W4LG5LR9
U81Z3LG5LR9
U81X3LG5LR9
Catalog
Number
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected. 12 Vac to 254 Vac 50/60 Hz - 12 Vdc to 60 Vdc.
163
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 1 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
2-Position Selector Switch
3-Position Selector Switch
Description/Function Diagram
2 fixed positions ‘0 - I’ 1NO + 1NC contact
3 fixed positions ‘I - 0 - II’ 2NO contact
3 positions ‘I - 0 - II’ with spring return from I to 0 1NO + 1NC contact
3 positions ‘I - 0 - II’ with spring return from II to 0 1NO + 1NC contact
Entry
Location
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
1.0
(2.20)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
Catalog Number
U81W2H3
U81W4H3
U81Z3H3
U81X3H3
U81W2J1
U81W4J1
U81Z3J1
U81X3J1
U81W2N3
U81W4N3
U81Z3N3
U81X3N3
U81W2M3
U81W4M3
U81Z3M3
U81X3M3
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected.
164
Unicode™ 2 Series Aluminum Control Stations and Switches
GreenRed
GreenRed
Green
Red
Green
Red
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 2 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Twin Push Button
1x green push button ‘I’ with 1NO contact 1x red push button ‘O’ with 1NC contact momentary contacts
1x green push button ‘I’ with 1NO + 1NC contact 1x red push button ‘O’ with 1NO + 1NC contact momentary contacts
Push Button + Push-Pull Emergency Stop
1x green push button ‘I’ with 1NO momentary contact 1x red mushroom head push-pull with 1NC maintained contact
1x green push button ‘I’ with 1NO + 1NC momentary contact 1x red mushroom head push-pull with 1NO + 1NC maintained contact
Entry
Location
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
U82W2A5A9
U82W4A5A9
U82Z3A5A9
U82X3A5A9
U82W2A3A3
U82W4A3A3
U82Z3A3A3
U82X3A3A3
U82W2A5D9
U82W4A5D9
U82Z3A5D9
U82X3A5D9
U82W2A3D3
U82W4A3D3
U82Z3A3D3
U82X3A3D3
Catalog Number
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected.
165
Unicode™ 2 Series Aluminum Control Stations and Switches
Red
Red
Red
Red
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 2 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Twin Push Buttons + Push-Pull Emergency Stop
1x green push button ‘I’ with 1NO contacts 1x red push button ‘O’ with 1NC contacts momentary contacts 1x red mushroom head push-pull with 1x NC maintained contact
Pilot Light + Push Button
1x green light 1x green push button ‘I’ with 1NO momentary contact
1x green light 1x green push button ‘I’ with 1NO + 1NC momentary contacts
1x red light 1x red push button ‘O’ with 1NC momentary contact
1x red light 1x red push button ‘O’ with 1NO + 1NC momentary contact
Entry
Location
Bottom
Green
Red
Red
Feed-Thru 2 x 3/4”
Green
Green
Bottom
Feed-Thru 2 x 3/4”
Green
Green
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
Catalog Number
U82W2A5A9D9
U82W4A5A9D9
U82Z3A5A9D9
U82X3A5A9D9
U82W2PGA5
U82W4PGA5
U82Z3PGA5
U82X3PGA5
U82W2PGA3
U82W4PGA3
U82Z3PGA3
U82X3PGA3
U82W2PRA9
U82W4PRA9
U82Z3PRA9
U82X3PRA9
U82W2PRA3
U82W4PRA3
U82Z3PRA3
U82X3PRA3
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected. 12 Vac to 254 Vac 50/60 Hz - 12 Vdc to 60 Vdc.
166
Unicode™ 2 Series Aluminum Control Stations and Switches
Red
Green
Green
Green
Green
Red
Red
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 2 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Pilot Light + Twin Push Buttons
1x green light 1x green push button ‘I’ with 1NO 1x red push button ‘O’ with 1NC momentary contacts
Twin Pilot Lights + Twin Push Buttons
1x green light + 1x red light 1x green push button ‘I’ with 1NO 1x red push button ‘O’ with 1NC momentary contacts
Ammeter + 3-Position Selector Switch
1x ammeter 48 x 48 mm, 1A C.T., 3 F.L.C., with 0 - 1 - 3 scale 1x switch 3 positions ‘I - 0 - II’ with spring return from II to 0 1NO + 1NC contact
Entry
Location
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.3
(2.87)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
1.2
(2.65)
Volume
3
dm
(in3)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
2.7
(164.80)
U82W2PGA5A9
U82W4PGA5A9
U82Z3PGA5A9
U82X3PGA5A9
U82W2PGPRA5A9
U82W4PGPRA5A9
U82Z3PGPRA5A9
U82X3PGPRA5A9
U82W2VA13M3
U82W4VA13M3
U82Z3VA13M3
U82X3VA13M3
Catalog
Number
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected. 12 Vac to 254 Vac 50/60 Hz - 12 Vdc to 60 Vdc.
167
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 3 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Twin Push Buttons + Push-Pull Emergency Stop
1x green push button ‘I’ with 1NO contact 1x red push button ‘O’ with 1NC contact momentary contacts 1x red mushroom head push-pull emergency button with 1NO + 1NC maintained contacts
Pilot Light + Twin Push Buttons
1x green light 1x green push button ‘I’ with 1NO contact 1x red push button ‘O’ with 1NC contact momentary contacts
1x red light 1x green push button ‘I’ with 1NO contact 1x red push button ‘O’ with 1NC contact momentary contacts
1x green light 1x green push button ‘I’ with 1NO + 1NC contact 1x red push button ‘O’ with 1NO + 1NC contact momentary contacts
1x red light 1x green push button ‘I’ with 1NO + 1NC contact 1x red push button ‘O’ with 1NO + 1NC contact momentary contacts
Entry
Location
Green
Bottom
Red
Red
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
GreenRed
Bottom
Feed-Thru 2 x 3/4”
Bottom
Feed-Thru 2 x 3/4”
GreenRed
Bottom
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
Volume
3
(in3)
dm
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
Catalog Number
U83W2A5A9D3
U83W4A5A9D3
U83Z3A5A9D3
U83X3A5A9D3
U83W2PGA5A9
U83W4PGA5A9
U83Z3PGA5A9
U83X3PGA5A9
U83W2PRA5A9
U83W4PRA5A9
U83Z3PRA5A9
U83X3PRA5A9
U83W2PGA3A3
U83W4PGA3A3
U83Z3PGA3A3
U83X3PGA3A3
U83W2PRA3A3
U83W4PRA3A3
U83Z3PRA3A3
U83X3PRA3A3
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected. 12 Vac to 254 Vac 50/60 Hz - 12 Vdc to 60 Vdc.
168
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Size 3 Aluminum Control Station
Included: 1 white self-adhesive laminated plastic nameplate, 1 brass earth continuity plate , 1 blanking plug , 1 cable gland .
Description/Function Diagram
Location
Triple Illuminated Push Buttons
1x green illuminated push
Entry
button with 1NO contact 1x blue illuminated push button with 1NO + 1NC
GreenBlueRed
Bottom
contact 1x red illuminated push button with NC contact momentary contacts
Feed-Thru 2 x 3/4”
Pilot Light + Twin Push Buttons + Push-Pull Emergency Stop
1x green light 1x green push button ‘I’ with 1NO contact 1x red push button ‘O’ with 1NC contact momentary contacts 1x red mushroom head push-pull with 1x NC maintained contact
Green
Bottom
Green
Red
Red
Feed-Thru 2 x 3/4”
Twin Pilot Lights + Push-Pull Emergency Stop + Push Button
1x green light + 1x red light 1x red mushroom head push-pull with 1x NC maintained contact 1x green push button ‘I’
RedGreen
Red
Bottom
with 1NO momentary contact
Green
Feed-Thru 2 x 3/4”
Ammeter + Twin Push Buttons
1x ammeter 48 x 48 mm, 1A C.T., 3 F.L.C., with 0 - 1 - 3 scale 1x green push button ‘I’ with 1NO contact
GreenRed
Bottom
1x red push button ‘O’ with 1NC contact momentary contacts
Feed-Thru 2 x 3/4”
Entry
Size
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
2 x M20
2 x M25
1 x 3/4”
Weight
kg (lb)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
1.6
(3.53)
Volume
3
(in3)
dm
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
4.2
(256.30)
Catalog
Number
U83W2LG5LB3LR9
U83W4LG5LB3LR9
U83Z3LG5LB3LR9
U83X3LG5LB3LR9
U83W2PGA5A9D9
U83W4PGA5A9D9
U83Z3PGA5A9D9
U83X3PGA5A9D9
U83W2PGPRD9A5
U83W4PGPRD9A5
U83Z3PGPRD9A5
U83X3PGPRD9A5
U83W2VA13A5A9
U83W4VA13A5A9
U83Z3VA13A5A9
U83X3VA13A5A9
Additional combinations available, please refer to Unicode 2 Series - Customized Control Stations section.
Not required for aluminum. Not included if NPT hubs are selected. 12 Vac to 254 Vac 50/60 Hz - 12 Vdc to 60 Vdc.
169
Unicode™ 2 Series Aluminum Control Stations and Switches
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Nameplates — Set of 10
Blank self-adhesive, laminated plastic 58 mm x 18 mm (2.29” x 0.71”).
Color Catalog Number
White (black letters) UNPW Yellow (black letters) UNPY
Red (white letters) UNPR
Blue (white letters) UNPB
Black (white letters) UNPN Green (white letters) UNPG
Inserts for Push Button — Set of 5
Marking Color Catalog Number Small Large
(unmarked) Green UIAG Blank (set of 10) ULPS ULPL (unmarked) Red UIAR ON ULPSA01 ULPLA01 (unmarked) Yellow UIAY OFF ULPSA02 ULPLA02 (unmarked) White UIAW FORWARD ULPSA03 ULPLA03 (unmarked) Blue UIAB REVERSE ULPSA04 ULPLA04 (unmarked) Black UIAN JOG ULPSA05 ULPLA05 ON Green UIA01 RUN ULPSA06 ULPLA06 OFF Red UIA02 START ULPSA07 ULPLA07 START Green UIA03 STOP ULPSA08 ULPLA08 STOP Red UIA04 UP ULPSA09 ULPLA09 MARCHE Green UIA05 DOWN ULPSA10 ULPLA10 ARRET Red UIA06 FAST ULPSA11 ULPLA11 I Green UIA07 SLOW ULPSA12 ULPLA12 O Red UIA08
Inserts for Illuminated Push Button — Set of 5
Marking Color Catalog Number
(unmarked) Green UILG (unmarked) Red UILR HIGH ULPSA18 ULPLA18
Spare Key
For all key-operated buttons.
Spare key type 4 A 185 SK4A185 REMOTE—LOCAL ULPSH08 ULPLH08
(unmarked) Yellow UILY TEST ULPSA19 ULPLA19 (unmarked) White UILW RESET ULPSA20 ULPLA20 (unmarked) Blue UILB EMERGENCY STOP ULPSA21 ULPLA21 ON Green UIL01 MARCHE ULPSA22 ULPLA22 OFF Red UIL02 ARRET ULPSA23 ULPLA23 START Green UIL03 ARRET D’URGENCE ULPSA24 ULPLA24 STOP Red UIL04 HAUT ULPSA25 ULPLA25 MARCHE Green UIL05 ARRET Red UIL06 I Green UIL07 ON—OFF ULPSH02 ULPLH02 O Red UIL08
Description Catalog Number
Standard Legend Plates
Two sizes available. Self-adhesive yellow laminated plastic (black lettering).
Small Size
ULPS ULPL
Tex t
RAISE ULPSA13 ULPLA13 LOWER ULPSA14 ULPLA14 OPEN ULPSA15 ULPLA15 CLOSE ULPSA16 ULPLA16 LOW ULPSA17 ULPLA17
BAS ULPSA26 ULPLA26 O—I ULPSH01 ULPLH01
START—STOP ULPSH03 ULPLH03 STOP—START ULPSH04 ULPLH04 HAND—AUTO ULPSH05 ULPLH05 MANU—AUTO ULPSH06 ULPLH06 FORWARD—REVERSE ULPSH07 ULPLH07
MARCHE—ARRET ULPSH09 ULPLH09 I—O—II ULPSJ01 ULPLJ01 OFF—O—ON ULPSJ02 ULPLJ02 START—NORMAL—STOP ULPSJ03 ULPLJ03 HAND—OFF—AUTO ULPSJ04 ULPLJ04 MANU—O—AUTO ULPSJ05 ULPLJ05 FORWARD—OFF—REVERSE ULPSJ06 ULPLJ06 LOCAL—REMOTE—AUTO ULPSJ07 ULPLJ07 LOCAL—O—REMOTE ULPSJ08 ULPLJ08 MARCHE—NORMAL—ARRET ULPSJ09 ULPLJ09
Large Size
Catalog Number
170
Unicode™ 2 Series Aluminum Control Stations and Switches
49.5 mm (1.95”)
67.6 mm (2.66”
26 mm (1.02”) UPLD1S
33 mm (1.30”) UPLD2S
CONTROLSCONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Description Catalog Number
Additional Contacts
Each actuator is capable of activating 3 contacts. Exception: Illuminated push button and all actuators with key: 2 contacts maximum
1NO contact UCB5R
1NC contact UCB9R
Yellow Guard
Mushroom head protection for emergency stop 098657
Padlockable Guard
Stainless steel and plastic cover, capacity: 3 padlocks diameter 6 mm (0.24”) maximum (not supplied)
)
For push button and rotary actuator UPLD1S
For mushroom head actuator
UPLD2S
Cable Gland Exe
For unarmored cable Exe - IP66 - in polyamide entry thread seal
M20 (capacity 6.5-14.5 mm) 095605
For armored cable Exe/Exd - IP66 - in nickel plated brass (without entry thread seal)
Braid and Tape type:
M20 (inner: 6.4-14.0/outer: 12.5-20.9 mm) 20E1FX5
Single Wired Armor (SWA):
M20 (inner: 6.4-14.0/outer: 12.5-20.9 mm) 20E1FW5
Adaptors
Exd/Exe - IP66 in nickel plated brass (without entry thread seal)
Male M20 - Female 1/2” NPT 737DM2T15
Male M20 - Female 3/4” NPT 737DM2T25
Entry Thread Seal
M20 (in white nylon) 20ETS2
Combination Drain and Breather
Exe - IP66 - supplied with entry thread seal and locknut
M20 male thread in Polyamide DBE20P
M20 male thread in Brass DBE20B
M20 male thread in Stainless Steel DBE20S
Feed-Thru Earth Stud Terminal
Exe - IP66 – supplied with weatherproof seal and green/yellow earth conductor — 300 mm (11.81”) length
M20 with M5 earth and 2.5 mm2 (0.004 in2) conductor PREESTM20
171
Unicode™ 2 Series Aluminum Control Stations and Switches
110 mm (4.33”)
110 mm (4.33”) 95 mm (3.74”)
95 mm (3.74”)
170 mm (6.69”)
134 mm (5.28”)
230 mm (9.06”)
194 mm (7.64”)
94 mm (3.70”) 94 mm (3.70”)
110 mm (4.33”) 95 mm (3.74”)
230 mm (9.06”)
194 mm (7.64”)
94 mm (3.70”)
CONTROLS CONTROLS: NEC/CEC, ATEX/IECEX INCREASED SAFETY CONTROL STATIONS
© June 2017
Increased Safety
ATEX/IECEx:
Zone 1 and 2 – 21 and 22
II 2 GD Ex de IIC/Ex demb IIC/ Ex tD A21 IP66 – IK10
Dimensions in Millimeters (Inches)
95 mm (3.74”)
230 mm (9.06”)
194 mm (7.64”)
110 mm (4.33”)
84 mm (3.31”)
120 mm (4.72”)
94 mm (3.70”)
110 mm (4.33”)
95 mm (3.74”)
170 mm (6.69”)
134 mm (5.28”)
94 mm (3.70”)
Size 1 Box Size 2 Box Size 3 Box
Mounting/Fixing Details for above Boxes: Two Holes Ø 5 mm (0.20”)
110 mm (4.33”) 95 mm (3.74”)
94 mm (3.70”)
172
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
