Code•Master™ Incandescent Factory Sealed Luminaires
Explosionproof, Dust-Ignitionproof
For use with threaded metal conduit.
NEC:
Class I, Division 1, Groups C, D
Class II, Division 1 and 2, Groups E, F, G
Class III
NEMA 3R, 4X
Applications
• For use in hazardous locations such as plants where plastics,
paints, thinners and petrochemicals are manufactured.
• For use in chemical and petrochemical plants, such as
manufacturers of plastics, paints and thinners, in reneries,
and in other areas where ignitable vapors, dust, moisture and
corrosive elements may be present.
• Suitable for outdoor saltwater locations and for other
wet locations.
Features
• Fixtures operate safely in high ambient temperatures.
• Patented “wireless” design. Threading of xture unit
onto mounting hood makes electrical connection. The
only wiring required is attaching two wires to connection
block in mounting hood.
• Connection block is easily wired: (a) loosen two screws; (b)
make wire connections; and (c) re-position connection block.
• Safe, easy servicing without disconnecting any wiring.
“Wireless” xture unit threads off mounting hood for convenient
servicing or for immediate replacement with a “stand-by” unit.
• Acme double-lead threads speed installation and xture removal
from mounting hood – only half as many turns are required
as for single-lead threads. The threads do not stick or gall,
eliminating problems often encountered with single-lead threads
during xture unit removal.
• Strategic location of lamp socket, in combination with interior
prism design of the glass globe, provides optimum light
distribution and control.
• Heat- and impact-resistant globes have smooth
dust-resistant exterior.
• Superior corrosion resistance, with epoxy powder coat nish.
• Porcelain socket with nickel-plated phosphor bronze screw
shell. Assures long trouble-free operation in high ambient areas.
• Choice of mountings: pendant, ceiling, bracket and stanchion.
• Fiberglass-reinforced polyester reectors, in standard dome
or 30° angle styles, are ideal in installations where luminaire is
subject to exceptionally severe corrosive atmospheres.
• All threaded joints are ame-tight.
• Heat- and impact-resistant globes have smooth
dust-resistant exterior.
• Superior corrosion resistance, with epoxy powder coat nish.
• Optional guards protect globes from damage. Secured to xture
with three stainless steel screws.
• Medium base lamp socket.
• Maximum voltage 250 Vac 50/60 Hz.
Standard Materials
• Fixture housing, mounting hoods and guards: copperfree
(4/10 of 1% max.) aluminum
• Globes: prismatic glass
• Reectors: berglass reinforced polyester
Standard Finishes
• Fixture housing, guards and mounting hoods: epoxy power
coat nish, electrostatically applied for complete, uniform
corrosion protection
Options
• Add sufx -Z for Exd IIB + H2, Zone 1.
NEC Certifications and Compliances
• UL Standard: UL 1598, UL 1598A, UL 844
• UL Listed: E10444
INCANDESCENT/AREA: NEC/CEC EXPLOSIONPROOF
Visit our website at www.emerson.com or contact us at (800) 621-1506.
© May 2016
615
Code•Master™ Incandescent Factory Sealed Luminaires
Explosionproof, Dust-Ignitionproof
For use with threaded metal conduit.
NEC:
Class I, Division 1, Groups C, D
Class II, Division 1 and 2, Groups E, F, G
Class III
NEMA 3R, 4X
Order using catalog numbering guide below or select catalog number from tables on following pages.
Catalog Numbering Guide
CI P 30 75 G
CI – Code•Master Incandescent
Technical Data Thermal Suitability of Code•Master Incandescent Fixture.
Incandescent (A21) 100 75 (167) 40 (140)
Incandescent (A23) 200 75 (167) 40 (140)
Incandescent (PS25) 300 75 (167) 40 (140)
Series:
Lamp Type
Mounting Hood:
P – Pendant
B – Wall Bracket
C – Ceiling
S – Stanchion
Lamp Watts
(Max.)
Use Wire Supply
Wattage:
30 – 100 W A21
200 W A23
300 W PS25
Ambient
Temperature
°C (°F)
Hub Size:
75 – 3/4”
100 – 1”
150 – 1-1/4” or 1-1/2”
°C (°F)
Options:
G – Guard
Blank – No Guard
Z - Exd IIB + H2, Zone 1
Class I, Division 1,
Groups C and D
T5 T3C
T4 T3C
T3C T3C
Class II, Division 1,
Groups E, F and G
“T” Numbers Represent the Maximum External Temperature for Class I, Division 1 Locations and
Maximum Surface Temperature Under Dust Blanket for Class II, Division 1 Locations.
“T”
Number
INCANDESCENT/AREA: NEC/CEC EXPLOSIONPROOF
Temp
Range
(°C)
Temp
Range
(°F)
NOTE: The maximum operating temperature of the fixture must not exceed the ignition temperature of the gas, vapor or dust to be encountered per the National
Certified to meet the Canadian Electrical Code (CEC) only.
616
T1 350 325 T2 T2A T2B T2C T2D T3 T3A T3B T3 T4 T4A T5 T6
351-
326-
301-
281-
261-
231-
216-
201-
181-
166-
161-
136-
121-
450
350
325
300
280
664-
619-
574-
538-
842
662
617
Electrical Code and the Canadian Electrical Code.
572
502-
536
260
448-
500
230
421-
446
215
394-
419
200
180
165
160
358-
331-
322-
392
356
Visit our website at www.emerson.com or contact us at (800) 621-1506.
329
277-
320
135
250-
275
101-
120
214-
248
86-
100
187-
212
85
185
© May 2016
Code•Master™ Incandescent Factory Sealed Luminaires
Explosionproof, Dust-Ignitionproof
For use with threaded metal conduit.
NEC:
Class I, Division 1, Groups C, D
Class II, Division 1 and 2, Groups E, F, G
Class III
NEMA 3R, 4X
Type Mounting Hub Size (Inches) Catalog Number
Pendant
Ceiling
Wall Bracket
25° Stanchion
Mounting Hoods
Pendant
Ceiling
Bracket
One Hub
Rigid Conduit.
Four Hubs
Three Close-Up Plugs
Rigid Conduit
Four Hubs
Three Close-Up Plugs
Rigid Conduit
One Hub 1-1/2 CIS30150
Type Mounting Hub Size (Inches) Hood Weight kg (lb) Catalog Number
One Hub
Rigid Conduit
Four Hubs
Three Close-Up Plugs
Rigid Conduit
Four Hubs
Three Close-Up Plugs
Rigid Conduit
3/4 CIP3075
1 CIP30100
3/4 CIC3075
1 CIC30100
3/4 CIB3075
1
3/4 0.9 (1.98) CAP-75
1 0.9 (1.98) CAP-100
3/4 1.8 (3.97) CAC-75
1 1.8 (3.97) CAC-100
3/4 2.7 (5.95) CALB-75
1 2.7 (5.95) CALB-100
CIB30100
INCANDESCENT/AREA: NEC/CEC EXPLOSIONPROOF
25° Stanchion
One Hub
1-1/2” Tapped hub furnished with 1-1/2” to 1-1/4” reducer.
1” Hubs are listed for Group D only.
Catalog numbers shown are supplied with clear lens. Add suffix G for optional Guard.
Visit our website at www.emerson.com or contact us at (800) 621-1506.
© May 2016
1-1/4 or 1-1/2
0.9 (1.98)
CAS-150
617
Code•Master™ Incandescent Factory Sealed Luminaires
Explosionproof, Dust-Ignitionproof
For use with threaded metal conduit.
NEC:
Class I, Division 1, Groups C, D
Class II, Division 1 and 2, Groups E, F, G
Class III
NEMA 3R, 4X
Description Weight kg (lb) Catalog Number
Fixture Unit Only
Optional White Polyester Reector
Optional White Polyester Reector
Optional Aluminum Guard
Optional Three Way Exit Sign
Replacement Connection Block
Not including mounting
hood
Standard Dome 1.1 (2.43) KR2-ST
Angled Reector 1.1 (2.43) KR2-AN
5.0 (11.02)
0.2 (0.44) CJGU-15
3.4 (7.50) CJEXRN
CJNC30I
INCANDESCENT/AREA: NEC/CEC EXPLOSIONPROOF
618
0.2 (0.44) VPT-7
Visit our website at www.emerson.com or contact us at (800) 621-1506.
© May 2016
Code•Master™ Incandescent Factory Sealed Luminaires
Explosionproof, Dust-Ignitionproof
For use with threaded metal conduit.
NEC:
Class I, Division 1, Groups C, D
Class II, Division 1 and 2, Groups E, F, G
Class III
NEMA 3R, 4X
Pendant
One Hub
3/4” NPT
CAP75
Standard Dome
KR2-ST
Dimensions in Millimeters (Inches)
101.6
(4.00)
Pendant
114.3
(4.50)
198.1
(7.80)
101.6
(4.00)
150.4
(5.92)
114.3
(4.50)
343.7
(13.53)
Hub for .75"
NPT Conduit
334.0
(13.15)
95.3
(3.75)
Four Hubs
Three Close-Up Plugs
3/4” NPT
Ceiling
101.6
(4.00)
339.9
(13.38)
330.2
(13.00)
Ceiling
CAC75
Optional Aluminum
Guard
CJGU-15
125.0
(4.92)
99.6
(3.92)
151.3
(5.95)
198.1
(7.80)
Bracket
Four Hubs
Three Close-Up Plugs
3/4” NPT
CALB75
Code•Master
Incandescent
Fixture Unit
CJNC30I
Wall Bracket
10.4
(0.41)
62.5
57.9
(2.46)
(2.28)
31.2
(1.23)
87.9
(3.46)
Hub for .75" NPT
Conduit Four Sides
Hub For
3/4” NPT
2” Wiring access
cover both sides.
292.1
(11.50)
349.3
(13.75)
1-1/4 or 1-1/2” NPT
Optional Three Way
Exit Sign
CJEXRN
125.0
(4.92)
108.0
(4.25)
45.5
(1.79)
25˚
25° Stanchion
One Hub
CAS150
352.6
(13.88)
25° Stanchion
290.3
(11.43)
317.0
(12.48)
198.1
(7.80)
Angle Reflector
KR2-AN
314.5
(12.38)
349.3
(13.75)
303.0
(11.93)
326.9
(12.87)
INCANDESCENT/AREA: NEC/CEC EXPLOSIONPROOF
Visit our website at www.emerson.com or contact us at (800) 621-1506.
© May 2016
619
