Appion LR2188 User Manual

Appion Inc. Phone: [phone] Fax: 1599

Page 1 of 6

www.Ap p io nT o o l s . c o m

2800 South Tejon St. Englewood, CO 80110 USA

Bluetooth Low Energy

BLE 4.2 Module

Model Number: LR2188/LR2188-uFL

Manual

Revised: June 26, 2019

Appion Inc. Phone: [phone] Fax: 1599

Page 2 of 6

www.Ap p io nT o o l s . c o m

2800 South Tejon St. Englewood, CO 80110 USA

Description

LR2188/LR2188-uFL BLE module houses the Nordic nRF52832 SoC with an on-board chip or external antenna
tuning for great performance and low power consumption.

LR2188/LR2188-uFL offers all Bluetooth low energy features: radio, stack, profiles and application space for
customer applications, so no external processor is needed.

For the nRF52832 SoC, refers to the nRF52832 Product Specification and the SDK is available from the Nordic
Semiconductor website.

Main Features

- Complete Bluetooth® low energy SoC (4.2 specification)

- 32-bit ARM Cortex-M4F processor @ 64MHz

- Size : 15 X 12 X 2 mm

- Operating Frequency : 2,402MHz ~ 2,480MHz

- FPU, DSP

- Up to 64 KB SRAM and 512 KB Flash

- Certified for CE, FCC and Bluetooth

- Rx sensitivity : Typical -93dBm

- Storage Temperature range : -20℃ ~55℃

Applications

- Sports and leisure equipment

- Heart rate collector

- Pedometer

- Watches

- Cycling and cadence sensor

- Consumer electronics

- Human Interface Devices (Keyboard, Mouse)

- Consumer medical

- Smart energy

- Security finder

- Proximity and presence

- Home and building automation

Revised: June 26, 2019

Appion Inc. Phone: [phone] Fax: 1599

Page 3 of 6

www.Ap p io nT o o l s . c o m

2800 South Tejon St. Englewood, CO 80110 USA

Model

Item Description

Placement

Type/

Model

Manufacturer

Name

Manufacturers.

Part Number

Remark

LR2188

Bluetooth module with SMT Chip Antenna

A1

SMT Chip

Antenna

Johanson

Technology

2450AT43B100E

N/A

LR2188­uFL

Bluetooth module with u.FL connector for

use with external antenna

J1

u.FL connector

Hirose

U.FL-R-SMT-1

N/A

Part Number

Gain (dBi)

Supplier

Notes

Chip

1.3

JOHANSON TECHNOLOGY

2450AT43B100-1

Dipole

4.9

Laird TECHNOLOGIES

ANT-DS-IN24-5RD 0711

Whip

3.0

Anaren, Inc.

66089-2406

The (Family model LR2188/LR2188-uFL) two models of Main Board share the same PCB layout.
The only difference is the LR2188 uses a SMT Chip Antenna whereas the LR2188-uFL has a u.FL connector to

attached to an external antenna.

 LR2188 uses a SMT Chip Antenna
 LR2188-uFL has a u.FL connector for external antenna use.

Antenna Approved for use with LR2188/LR2188-uFL

Since this module is not sold to general end users directly, there is no user manual of module.
For the details about this module, please refer to the specification sheet of module.
This module should be installed in the host device according to the interface specification

(installation procedure).

Revised: June 26, 2019

Appion Inc. Phone: [phone] Fax: 1599

Page 4 of 6

www.Ap p io nT o o l s . c o m

2800 South Tejon St. Englewood, CO 80110 USA

Federal Communication Commission Interference Statement

This equipment was tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.

FCC Caution

Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to

operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

Important Note
Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Country Code selection feature to be disabled for products marketed to the US/CANADA.

This device is intended only for OEM integrators under the following conditions:

1.The antenna must be installed such that 20 centimeters is maintained between the antenna and users, and

2.The transmitter module may not be co-located with any other transmitter or antenna,

3.For all products market in US, OEM must limit the operation channels in CH0 to CH39 for 2.4G band by supplied firmware
programming tool. OEM shall not supply any tool or info to the end user regarding to Regulatory Domain change.

If the conditions above are met, further transmitter test are not required. However, the OEM integrator is still responsible for testing
their end-product for any additional compliance requirements required with this module installed.

Important Note

In the event that these conditions cannot be met (for example, certain laptop configurations or co-location with another transmitter),
then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these
circumstances, the OEM integrator is responsible for re-evaluating the end product (including the transmitter) and obtaining a
separate FCC authorization

End Product Labeling

This transmitter module is authorized only for use in a device where the antenna may be installed such that 20 cm may be
maintained between the antenna and users. The final end product must be labeled in a visible area with the following: Contains
FCC ID: 2ABH9-LR2188

Manual Information to the End User

The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module
in the user’s manual of the end product which integrates this module.

The end user manual shall include all required regulatory information/warning as show in this manual.

Revised: June 26, 2019

Appion Inc. Phone: [phone] Fax: 1599

Page 5 of 6

www.Ap p io nT o o l s . c o m

2800 South Tejon St. Englewood, CO 80110 USA

Part Number

Gain (dBi)

Supplier

Notes

Chip

1.3

JOHANSON TECHNOLOGY

2450AT43B100-1

Dipole

4.9

Laird TECHNOLOGIES

ANT-DS-IN24-5RD 0711

Whip

3.0

Anaren, Inc.

66089-2406

Industry Canada Statement

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

 This device may not cause interference; and
 This device must accept any interference, including interference that may cause undesired operation of the device.

Cet appareil contient des émetteurs / récepteurs exempts de licence qui sont conformes au (x) RSS (s) exemptés de licence
d'Innovation, Sciences et Développement économique Canada. L'opération est soumise aux deux conditions suivantes:

 Cet appareil ne doit pas causer d'interférences

 Cet appareil doit accepter toute interférence, y compris les interférences pouvant provoquer un fonctionnement indésirable

de l'appareil

This radio transmitter (IC: 11615A-LR2188) has been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than
the maximum gain indicated for that type, are strictly prohibited for use with this device.

Le présent émetteur radio (IC: 11615A-LR2188) a été approuvé par Industrie Canada pour fonctionner avec les types
d'antenne énumérés ci dessous et ayant un gain admissible maximal. Les types d'antenne non inclus dans cette liste, et dont
le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur..

Radiation Exposure Statement

This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20 cm between the radiator and your body.

Déclaration d'exposition aux radiations

Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement non contrôlé. Cet équipement
doit être installé et utilisé à distance minimum de 20cm entre le radiateur et votre corps.

This device is intended only for OEM integrators under the following condition:
 The transmitter module may not be co-located with any other transmitter or antenna.
As long as the condition above is met, further transmitter test will not be required. However, the OEM integrator is still
responsible for testing their end-product for any additional compliance requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes:
 Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
Tant que les 1 condition ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas nécessaires.
Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité
supplémentaires requis pour ce module installé.

Important Note:

In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another
transmitter), then the Canada authorization is no longer considered valid and the IC ID cannot be used on the final product. In
these circumstances, the OEM integrator is responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate Canada authorization.

Note Importante:

Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations d'ordinateur portable ou
de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC ne
peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera chargé de réévaluer le produit final (y
compris l'émetteur) et l'obtention d'une autorisation distincte au Canada.

End Product Labeling

The final end product must be labeled in a visible area with the following: Contains IC: 11615A-LR2188

Plaque signalétique du produit final

Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: Contient des IC: 11615A-LR2188

Revised: June 26, 2019

Appion Inc. Phone: [phone] Fax: 1599

Page 6 of 6

www.Ap p io nT o o l s . c o m

2800 South Tejon St. Englewood, CO 80110 USA

Manual Information to the End User

The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF
module in the user’s manual of the end product which integrates this module.

The end user manual shall include all required regulatory information/warning as show in this manual.

Manuel d'information à l'utilisateur final

L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer ou de
supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module.

Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme indiqué
dans ce manuel.

EU Declarations of Conformity

Manufacturer: Appion Incorporated
Products: LR2188
EU Directives:2014/35/EU, 2014/30/EU and 2014/53/EU
Conformity Assessment: Annex IV

Declaration:
We, Appion Incorporated, declare under our sole responsibility that the essential radio test suites have been carried out and that
the above product to which this declaration relates is in conformity with all the applicable essential requirements of Article 3 of the
EU Directive 2014/53/EU, when used for its intended purpose.

Place of Issue: 2800 South Tejon Street Englewood, CO 80110
Name of Authorized Person: Frank Roberts II

Title: Chief Technical Officer

Signature of Authorized Person:

Revised: June 26, 2019
