BRONZE GLOBE VALVE
INSTALLATION
OPERATION
MAINTENANCE
GUIDE
33 & 33LF SERIES
MODELS:
120T/120TLF
120S/120SLF
121T/121TLF
122T
127T
128T
DOCUMENT NO.: ES-1497
REVISION LEVEL: A
ISSUED BY: Bill Hooks DATE: 08/7/13
APPROVED BY: _________________ DATE: _______
APOLLO® BRONZE GLOBE VALVE IOM GUIDE
Page 2 of
4
INTRODUCTION
The Apollo Bronze seat Class 125/150/300 Globe valves are designed to operate at the fully closed or fully open position to stop
or start the flow of fluid by means of rotating the hand wheel (counter-clockwise to open and clockwise to close) . Disc or disc
holders are fastened securely to the end of the stem in such a manner as to allow these parts to swivel freely. Valve sizes ½” and
smaller, have the disc or disc holder formed on the end of the stem. Discs, plugs or disc holders of the slip-on type are adequately
guided for self-centering in relation to the body and bonnet, that when the valve is fully opened, they will not slip off the stem.
123
3
2
1
3
2
1
4
5
6
7
8
9
11
10
4
5
6
7
8
9
15
12
11
10
13
14
Type 1 Globe Valve Type 2 Globe Valve Type 3 Globe Valve
Part Name
Item
1 Hand Wheel Nut Brass Brass Brass
2 Nameplate Alu minum Alumin um Alumin um
3 Hand Wheel Mal leable Iron Malle able Iron Malleable Iron
4 Stem ASTM B371 Bronze ASTM B371 Bronze AS TM B371 Bronze
5 Packin g N ut ASTM B16 Brass ASTM B16 Brass ASTM B16 Brass
6 Gland ASTM B16 Brass ASTM B16 Brass ASTM B16 Brass
7 Packing Grafoil ® Grafoil ® Grafoi l ®
8 Bonnet ASTM B62 Bronze ASTM B61 Bronze ASTM B61 Bronze
9 Lock Nut ASTM B16 Brass ASTM B 16 Brass ASTM B16 Brass
10 Body ASTM B62 Bronze AS TM B61 Bronze ASTM B61 Bronze
11 Disc (Type 1) ASTM B505 Bronze ASTM B61 Bronze N/A
11 Disc (Type 2) Virgin PTFE N/A N/A
11 Disc (Type 3) N/A N/A ASTM A276 Stainle ss Stl.
12 Di sc Holde r ASTM B505 Bronze N/A N/ A
13 Washer Stainless Steel N/A N/ A
14 N ut ASTM B16 Brass N/A N/ A
15 Union Nut ASTM B62 Bronze ASTM B61 Bronze ASTM B61 Bronze
16 Seat Ring N/A N/A ASTM A276 Stainle ss Stl.
Class 125/150 Class 300 ( BRZ Seat) Class 300 ( SS Seat)
Material
4
5
6
7
8
9
11
10
16
Table 1 Apollo Series & Model Numbers
SERIES MODEL DESCRIPTION
33-13x 120T Class 125 PTFE Disc, Threaded bonnet, NPT connection
33-14x 120S Class 125 PTFE Disc, Threaded bonnet, Solder connection
33-16x 121T Class 125 Bronze Disc, Threaded bonnet, NPT connection
33-22x 122T Class 150 PTFE Disc, Union bonnet, NPT connection
33LF-13x 120TLF Class 125 PTFE Disc, Threaded bonnet, NPT connection Lead Free
33LF-14x 120SLF Class 125 PTFE Disc, Threaded bonnet, Solder connection Lead Free
33LF-16x 121TLF Class 125 Bronze Disc, Threaded bonnet, NPT connection Lead Free
33-66x 127T Class 300 Bronze Disc, Union bonnet, NPT connection
33-74x 128T Class 300 Renewable Stainless Steel Disc and Seat, Union bonnet, NPT connection
x – indicates pipe size.
ES1497 IOM Bronze Globe Valve 1418 S. Pearl Street Pageland SC USA 29728
2
APOLLO® BRONZE GLOBE VALVE IOM GUIDE
Page 3 of
4
Table 2 Pressure Ratings
Class 125
Saturated Steam 125 psi (8.6 Bar) to 353°F (178°C)
Cold Water 200 psi (13.8 Bar) at 100°F
Class 150
Saturated Steam 150 psi (10.3 Bar) to 366°F (185°C)
Cold Water 300psi (20.7 Bar) at 100°F
Class 300
Saturated Steam 300 psi (20.7 Bar) to 423°F (217°C)
Cold Water 1000 psi (68.9 Bar) to 100°F
These ratings are the maximum allowable, non-shock pressures at the temperatures shown and allowable
pressures may be interpolated between temperatures shown. Use of a pressure rating at a material
temperature other than the temperature of the contained fluid is the responsibility of the user, and subject to
the requirements of applicable codes. The safe pressure-temperature rating of a solder joint valve is
dependent on the composition of the solder used. All valves are 100% pneumatically shell and seat tested at a
pressure of 80 psi in accordance with MSS-SP-80 Manufacturers Standardization Society requirements.
INSTALLATION
Inspection
Threads of mating pipe must be clean and machined to appropriate ANSI/ASME specifications.
Ends of mating copper tubing or pipe must be square and free of burrs. Use emery cloth to clean and remove
grease and/or oxidation before soldering. Inspect sealing surfaces of valve for cleanliness prior to installing.
Mounting
Globe valves can be mounted in either vertical or horizontal position. Flow is recommended by arrow in body.
NPT connection
It is recommended that the valve is mounted in the closed position. Gently thread valve to mating pipe by
hand until resistance is felt. Using a wrench tighten the valve using the hex flats at the joint being tightened.
Do not tighten through the valve body using hex flats on opposite end of joint being tightened.
Solder connection
It is recommended that the valve be in the open position. Care must be taken to apply the proper amount of
solder so that it does not flow into valve seat area. During soldering, the mid-portion of the valve body should
not exceed 300°F. This can be monitored using Tempilstik® or an infra-red temperature sensor. Depending on
the fuel selected and the orientation of the installation it may be necessary to wrap the valve body with wet
rags or employ other heat absorbing techniques. The flame must be directed away from the valve body,
concentrated on the solder cup. The cup should be heated evenly. Once one of the joints is complete, the valve
should be allowed to cool until "cool to the touch" before beginning the second joint.
Fuel Flame temp w/Oxygen
Propane 5122°F (2828°C)
Propylene 5245°F (2896°C)
MAPP Gas 5389°F (2976°C)
Acetylene 5720°F (3160°C)
WARNING: Excessive heat input will damage the body seal resulting in leaks at the valve
body joint. In extreme cases, seats and stem packing may also be damaged.
Press connection
Valve can be in either closed or open position. Piping must be properly supported so that valve fits squarely
before pressing. Do not solder any joint within 12” of press connection.
Compatible piping: Copper water tube per ASTM B88, Types K, L, & M.
(Not for use with steam service)
ES1497 IOM Bronze Globe Valve 1418 S. Pearl Street Pageland SC USA 29728
3
APOLLO® BRONZE GLOBE VALVE IOM GUIDE
Page 4 of
4
Push connection
Valve can be in either closed or open position.
Compatible piping: Copper water tube per ASTM B88, Types K, L, & M, both hard drawn
(Not for use with steam service)
OPERATION
Globe valves are intended to provide years of reliable service throttling applications.
Globe valves have high flow restriction and not recommended where pressure drop is critical.
Globe valves with metal seated disc have a permissible leakage rate per MSS SP-80 of 10ml of water per hour
per inch of pipe size. Soft-seated/resilient disc have bubble-tight shut off.
MAINTENANCE
Valves must be actuated frequently depending on fluid corrosiveness to assure contamination or deposits do
not collect causing seizure and seat leak.
Seat leakage can be resolved by:
□ Flushing seat area with high rate of flow through the valve.
□ Additional torque using hand wheel maybe needed.
□ Disassembly and cleaning of seat area. Minor scratches can be corrected by evenly polishing the disc face
using 400 grit sand paper. If body sealing surfaces are damaged it is recommended replacing valve due to
difficulty of correcting damaged area.
□ Replacement of disc.
Bonnet/Body joint leakage can be resolved by:
□ Union Bonnet Globe Valves
.1 Remove bonnet after valve has been depressurized.
.2 Inspect body and bonnet sealing area for minor scratches and defects.
.3 Minor scratches and defects on body sealing surface can be corrected by sanding on a flat plate using 400
grit sandpaper.
.4 Once imperfections have been corrected reassemble bonnet to body.
□ Threaded Bonnet Globe Valves
.1 Remove bonnet after valve has been depressurized.
.2 Add Loctite 246 to threaded portion of bonnet and reassemble.
Stem/Bonnet leakage can be resolved by:
□ Tighten packing gland nut. Hand wheel torque is affected by the tightness of this packing, so care must be
taking to not over-tighten.
If there is no travel left on the packing gland, packing should be replaced. Backseat feature can be used to
reduce leakage until system can be isolated and depressurized for packing replacement.
CAUTION: Packing should not be replaced while valve is under pressure. This could lead to serious injury.
ES1497 IOM Bronze Globe Valve 1418 S. Pearl Street Pageland SC USA 29728
4
