SUBMIT TA L
SHEET
101S LF
Class 125, Rising Stem, Solder, Gate Valve
LEAD FREE
Job Name:
Job Location:
Engineer:
Contractor:
Tag :
PO#:
Rep:
Wholesale Dist.:
DESCRIPTION
The lead free* Apollo Model 101S-LF (30LF Series Gate Valve) provides a reliable, long lasting “Made in the USA” alternative to globally sourced multi-turn
valves for potable water service. These valves are cast, machined, assembled, and tested in South Carolina using proven ASTM quality materials.
FE ATURE S
• Threaded Bonnet
• Solid Bronze Disc
• 200 CWP
APPROVALS
• ARRA Compliant
• MSS SP-80 Design & Testing - Type 2
• MSS SP-139 - Copper Alloy Gate, Globe,
• Max. Temp: 406°F
• Lead Free Option (NSF 61/NSF 372)
STANDARDS
• MSS SP-80 Standard
• MSS SP-139 Lead Free Option (CWP only)
• ASME B16.18, - Cast Copper Alloy Solder
• NSF/ANSI 372 Lead Free
• NSF/ANSI 61 Water Quality
• CRN 0C14667.5
• ASTM B62 Bronze(ASTM B584-C89836 Lead Free)
PERFORMANCE RATING
• Cold Working Pressure:
200 psi (13.8 Bar) At 100°F
• Temperature Range: -20°F To 406°F
DIMENSIONS
PART
NUMBER
30LF-083-01 1/2 1.88 4.85 1.00
30LF-084-01 3/4 2.43 5.7 1 1.30
30LF-085-01 1 2.96 6.71 2.20
30LF-086-01 1 1/4 3.14 8.10 3.20
30LF-087-01 1 1/2 3.44 9.08 4.40
30LF-088-01 2 4.11 11.28 7. 00
30LF-089-01 2 1/2 4.79 14.58 13.80
30LF-080-01 3 5.43 19.07 17.70
Length is measured from end to end.
Height is measured from centerline to top of wheel in full open position.
NPS
LENGTH
(IN.)
HEIGHT
(IN.)
& Check Valves
Joint Pressure Fittings
WEIGHT
(LB.)
STANDARD MATERIALS LIST
BODY
BONNET
STEM
DISC WEDGE
PACKING
HAND WHEEL
NAMEPLATE
Bronze, ASTM B58 4-C898 36
Bronze, ASTM B58 4-C898 36
ASTM B21 UNS C46400
ASTM B584-C89836
®
Grafoil
(Asbestos Free)
Malleable Iron
Aluminum
*LEAD FREE: The wetted surfaces of this product shall contain no more than 0. 25% lead by weighted average. Complies with Federal Public Law 111-380. ANSI 3rd party approved and listed.
(704) 841-6000
apollovalves.com
SS1315 © 07/18 Page 1 of 1
This specification is provided for reference only. Apollo reserves the right to change any portion of this specification without
notice and without incurring obligation to make such changes to Apollo products previously or subsequently sold.
Most current information available at apollovalves.com.
