Aplex APC-3593P User Manual
1
APC-3x93P_3X93R
(SBC-7106 – 15”)
User Manual
Release Date _ Revision
Oct. 2014 V2.1
® 2014 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw URL: www.aplex.com.tw
APC-3x93P_R (SBC-7106) User Manual
2
Warning!___________________________________
This equipment generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions manual, it may cause interference to radio
communications.
It has been tested and found to comply with the limits for a Class A computing device pursuant
to FCC Rules, which are designed to provide reasonable protection against such interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely to
cause interference in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Electric Shock Hazard – Do not operate the machine with its back cover removed. There are
dangerous high voltages inside.
APC-3x93P_R (SBC-7106) User Manual
3
Packing List
Accessories (as ticked) included in this package are:
□ Adaptor
□ Driver & manual CD disc
□ Other.___________________(please specify)
Safety Precautions
Follow the messages below to prevent your systems from damage:
◆ Avoid your system from static electricity on all occasions.
◆ Prevent electric shock. Don‘t touch any components of this card when the card is
power-on. Always disconnect power when the system is not in use.
◆ Disconnect power when you change any hardware devices. For instance, when you
connect a jumper or install any cards, a surge of power may damage the electronic
components or the whole system.
APC-3x93P_R (SBC-7106) User Manual
4
Table of Contents______________________
Warning!…………………………………………………………………………….……..….2
Packing List…………………………………………………………………………………..3
Safety Precautions…………………………………………………………………………..3
Chapter 1 Getting Started
1.1 Features…….……………………………………..….……………………..6
1.2 Specifications……………………………...……………………………......6
1.3 Dimensions……………………………………………………….……....…8
1.4 Brief Description………………………………………………….……....…9
Chapter 2 Hardware
2.1 Mainboard………………..…….……………………………………..…....10
2.2 Introduction…….………………….……………………………………….13
2.3 Jumpers Setting and Connectors........................................................15
Chapter 3 BIOS Setup
3.1 Operations after POST Screen...........................................................21
3.2 BIOS Setup Utility……........................................................................21
3.3 Main Settings…..................................................................................22
3.4 Advanced Settings..............................................................................23
3.5 Chipset Settings..................................................................................29
3.6 Boot Settings......................................................................................33
3.7 Security Settings.................................................................................36
3.8 Save and Exit Settings…....................................................................37
Chapter 4 Installation of Drivers
4.1 Intel Chipset Driver.…………………………...………………………..…40
4.2 Intel Graphics Media Accelerator Driver...……………………………....43
4.3 Intel (R) Network Adapter……..………………………………………….46
4.4 Realtek ALC662 HD Audio Driver Installation…….………….…………48
APC-3x93P_R (SBC-7106) User Manual
5
Chapter 5 Touch Screen Installation
5.1 Windows 2000/XP/2003/Vista/WIN7 Universal Driver Installation for
PenMount 6000 Series…..………………………………………………50
5.2 Software Functions……………………………………………………......60
Figures
Figure 1.1: Dimensions of APC-3593P(R).……………………………..…......8
Figure 1.2: Front view of APC-3X93P(R)………….....……………………...…9
Figure 1.3: Rear view of APC-3X93P(R)…………..………………………...…9
Figure 2.1: Mainboard Dimensions…………………………………..…….....12
Figure 2.2: Jumpers and Connectors Location_ Board Top………………...13
Figure 2.3: Jumpers and Connectors Location_ Board Bottom…………....14
APC-3x93P_R (SBC-7106) User Manual
6
Chapter 1 Getting Started
APC-3593P(R)
System
CPU
Intel® Atom Processor D2550(1M Cache, 1.8GHz)
Motherboard
SBC-7106-D2550
System Chipset
Intel NM10 Express
System Memory
Onboard DDR3 2GB (Default), optional 4G
IO Port
USB
1 x M12 8 pin for USB 1/2
1 x M12 8 pin for USB 3/4
Serial/Parallel
1 x M12 8pin for COM 1/RS-232/422/485 (Default RS-232)
1 x M12 8pin for COM 2/RS-232
Audio
N/A
Membrane control
N/A
LAN
1 x M12 8pin for LAN
Power
1 x M12 3 pin DC power connector
Storage Space
HDD
1 x 2.5” SATA HDD or SSD
Movable device
1 x Internal SD Card slot on board
Expansion
On board expansion bus
1 x Mini PCIe half size slot
Display
Display Type
15” TFT-LCD
1.1 Features
Fanless and Low Power Consumption Stainless Steel Panel PC
Intel® Atom™ Processor D2550 (1M Cache, 1.8GHz)
Onboard 2GB DDR3, optional 4G
11~32V DC wide-ranging power input
M12 I/O Connector
Full Flat bezel Design, Total 6 sides IP65/ IP69K
Projective capacitive touch/ Resistive Type
1.2 Specifications
APC-3x93P_R (SBC-7106) User Manual
7
Max. Resolution
1024x768
Max. Color
16M
Contrast Ratio
800 : 1
Luminance (cd/m²)
400
View angle(H°/V°)
160/145
Touch Screen (for APC-3X93P)
Type
Projective Capacitive
Interface
USB
Light Transmission(%)
90%
Touch Screen (for APC-3X93R)
Type
Resistive touch window
Interface
Default RS-232
Light Transmission(%)
80%
Power
Power Input
11~32V DC
Power Consumption
Max:19.5W
Mechanical
Construction
Stainless steel
IP Rating
Total IP65 6 sides / IP69 K
Mounting
VESA 75 x 75
Dimension (mm)
399 x 324 x 53
Net Weight (Kgs)
6.5KG
Environmental
Operating
temperature(°C)
0℃ to 50℃ (with HDD)
-20~60 (with Industrial SSD or CF)
Storage
temperature(°C)
-30~70℃
Storage humidity
10 to 90% @ 40°C, non- condensing
Certification
CE / FCC Class A
Operating System
Support
WES7 32bit, W7PES
APC-3x93P_R (SBC-7106) User Manual
8
1.3 Dimensions
Figure 1.1: Dimensions of APC-3593P(R)
APC-3x93P_R (SBC-7106) User Manual
9
1.4 Brief Description of APC-3X93P/3X93R
APC-3x93P/3X93R series comes with IP65 certificated and is powered by Intel Atom D2550 to
provide low power consumption. The stainless steel chassis design makes it exceptionally suitable for
strict hygiene regulations for food/chemical industry, medical, restaurant/kitchen applications, storage
management and outdoor /information segment and so on. APC-3x93P/3X93R series has touch
screen of projective capacitive type and resistive type window for option. The APC-3x93P/3X93R
series has advanced computing performance and lower power consumption thanks to well-equipped
Intel Atom D2550 solution with 2G DDR3 on board. Regarding the storage capability,
APC-3x93P/3X93R series provides 1 x 2.5” SATA HDD, 1 x internal SD Slot and 1x internal mini-PCIe
allowing customers to easily access/backup the data. APC-3x93P/3X93R series supports OS such as
Windows Embedded Standard 7, Windows 7 Pro for Embedded and so on.
Figure 1.4: Front View of APC-3x93P(R)
APC-3x93P_R (SBC-7106) User Manual
Figure 1.5: Rear View of APC-3x93P(R)
10
Chapter 2 Hardware
Specifications
Board Size
170mm x 113mm
CPU Support
Intel Atom Processor D2550 (1M Cache, 1.8 GHz)
Chipset
Intel NM10 Express
Memory
Support
Onboard 2GB DDRIII SDRAM
Graphics
Integrated Intel GMA 3600 (N2600)
Display Mode
1 x CRT Port
1 x LVDS1 (18/24-bit single LVDS)
Support
Resolution
Up to 1920 x1200 for CRT
Up to 1366 x768 for LVDS1 (N2600)
Dual Display
CRT+LVDS1
Super I/O
Winbond W83627UHG-E
BIOS
AMIBIOS
Storage
1 x SATA Connector (7P)
1 x SATA Connector (7P+15P)
1 x SD Socket (USB to SD)
Ethernet
2 x PCIe GbE LAN by Realtek RTL8111E
USB
2 x USB 2.0 (type A)stack ports (USB4/USB5)
2 x USB 2.0 Pin header via CN3 (USB2/USB3)
2 x USB 2.0 Pin header via CN1 (USB0/USB1)
1 x USB 2.0 for MPCIE1 (USB7)
Mini-PCIe(USB7)
Serial
1 x RS-232/RS-422/RS-485, DB9 connector for external (COM1)
pin 9 w/5V/12V/Ring select
1 x RS232 port, DB9 connector for external (COM2)
pin 9 w/5V/12V/Ring select
1 x RS422/485 header via CN2 (COM3)
2 x UART via CN3 (COM5,COM6)
2.1 Mainboard
APC-3x93P_R (SBC-7106) User Manual
11
Digital I/O
8-bit digital I/O Pin header via CN2
4-bit digital Input
4-bit digital Output
4-bit digital I/O Pin header via CN3
2-bit digital Input
2-bit digital Output
Battery
Support CR2477 Li battery by 2-pin header
Audio
Realtek ALC662 HD audio codec
Line-in, Line-out, MIC via 2x6-pin header
Audio Line out in phone jack
Keyboard
/Mouse
1 x PS2 keyboard/mouse 1x6 box pin header via CN3
Expansion Bus
1 x mini-PCI-express slot
1 x PCI-express via CN3
Touch Ctrl
1 x Touch control header for TCH1 (COM4)
Power
Management
Wide Range DC 9~36V input
1 x 3-pin power input connector
Switches and
LED Indicators
1 x Power on/off switch via CN1
1 x Reset switch via CN1
1 x Power LED status via CN1
1 x HDD LED status via CN1
1 x Buzzer
External I/O
port
2 x COM Ports (COM1/COM2)
2 x USB 2.0 Ports (USB4/USB5)
2 x GbE LAN Ports
1 x Line out Audio phone jack
Watchdog
Timer
Software programmable 1 – 255 second by Super I/O
Temperature
Operating: -20℃ to 70℃
Storage: -40℃ to 85℃
Humidity
5% - 95%, non-condensing, operating
Power
Consumption
12V /0.95A (Intel Atom N2600 processor with 2GB DDR3 DRAM)
EMI/EMS
Meet CE/FCC class A
APC-3x93P_R (SBC-7106) User Manual
12
(units :mm)
Figure 2.1: Mainboard Dimensions
APC-3x93P_R (SBC-7106) User Manual
13
2.2 Introduction
SBC-7106 is a 4" industrial motherboard developed on the basis of Intel Cedarview-M Processors
and NM10, which provides abundant peripheral interfaces to meet the needs of different customers.
Also, it features dual GbE ports, 3-COM ports and one Mini PCIE configuration, one VGA port, one
HDMI port, one LVDS interface. To satisfy the special needs of high-end customers, CN1 and CN2
and CN3 richer extension functions. The product is widely used in various sectors of industrial control.
2.2.1 Jumpers Setting and Connectors
Board Top
Figure 2.2: Jumpers and Connectors Location_ Board Top
APC-3x93P_R (SBC-7106) User Manual
14
Board Bottom
Figure 2.3: Jumpers and Connectors Location_ Board Bottom
APC-3x93P_R (SBC-7106) User Manual
15
2.3 Jumpers Setting and Connectors
JP5
Mode
Open
ATX Power
Close
Auto Power on (Default)
Pin#
Signal Name
Pin1
VBAT
PIN2
Ground
Pin#
Power Input
Pin1
DC+9V~32V
Pin2
Ground
Pin3
FG
Signal Name
Pin#
Pin#
Signal Name
CRT_RED
1
2
Ground
CRT_GREEN
3
4
Ground
CRT_BLUE
5
6
Ground
CRT_H_SYNC
7
8
CRT_DDCDATA
1. JP5:
(2.0mm Pitch 1X2 box Pin Header),ATX Power and Auto Power on jumper setting.
2. BAT1 :
(1.25mm Pitch 1X2 box Pin Header) 3.0V Li battery is embedded to provide power for
CMOS.
3. DC_IN1:
(5.08mm Pitch 1x3 Pin Connector),DC9V~36V System power input connector。
4. VGA1:
(CRT 2.0mm Pitch 2X6 Pin Header), Video Graphic Array Port, Provide 2x6Pin cable to
VGA Port.
APC-3x93P_R (SBC-7106) User Manual
16
CRT_V_SYNC
9
10
CRT_DDCCLK
Ground
11
12
Ground
Function
S_232 Pin#
RS232
(Default)
ON:
Pin1, Pin2, Pin3, Pin4, Pin5
RS422
(option)
OFF:
Pin1, Pin2, Pin3, Pin4, Pin5
RS485
(option)
OFF:
Pin1, Pin2, Pin3, Pin4, Pin5
Function
RS_422 Pin#
RS232
(Default)
OFF: Pin1, Pin2, Pin3, Pin4,
Pin5
RS422
(option)
ON: Pin1, Pin2, Pin3, Pin4,
Pin5
RS485
(option)
ON: Pin1, Pin2, Pin3, Pin4,
Pin5
6. RS-232:
(Switch),COM1 jumper setting, it provides selectable RS232 or RS422 or RS485 serial
signal output.
7. RS-422:
(Switch),COM1 setting, it provides selectable RS232 or RS422 or RS485 serial signal
output.
Note: Must keep the setting with BIOS setting.
8. COM1:
(Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a direct
connection to serial devices. COM1 port is controlled by pins No.1~6 of JP1,select
output Signal RI or 5V or 12V, For details, please refer to description of JP1 and S_232
and S_422 setting.
APC-3x93P_R (SBC-7106) User Manual
17
RS232 (Default):
Pin#
Signal Name
1
DCD# (Data Carrier Detect)
2
RXD (Received Data)
3
TXD (Transmit Data)
4
DTR (Data Terminal Ready)
5
Ground
6
DSR (Data Set Ready)
7
RTS (Request To Send)
8
CTS (Clear To Send)
9
JP1 select Setting (RI/5V/12V)
BIOS Setup：
Advanced/W83627UHG Super IO
Configuration/Serial Port 1 Configuration【RS-232】
RS422 (option):
Pin#
Signal Name
1
422_RX+
2
422_RX-
3
422_TX-
4
422_TX+
5
Ground
6
NC
7
NC
8
NC
9
NC
BIOS Setup：
Advanced/W83627UHG Super IO
Configuration/Serial Port 1 Configuration【RS-422】
RS485 (option):
Pin#
Signal Name
1
NC
2
NC
3
485-
4
485+
5
Ground
6
NC
7
NC
8
NC
APC-3x93P_R (SBC-7106) User Manual
18
9
NC
BIOS Setup：
Advanced/W83627UHG Super IO
Configuration/Serial Port 1 Configuration【RS-485】
Pin#
Signal Name
1
DCD# (Data Carrier Detect)
2
RXD (Received Data)
3
TXD (Transmit Data)
4
DTR (Data Terminal Ready)
5
Ground
6
DSR (Data Set Ready)
7
RTS (Request To Send)
8
CTS (Clear To Send)
9
NA
10. COM2:
(Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a
direct connection to serial devices.
11. LED3:
LED STATUS. Green LED for Touch Power status.
12. SATA1:
(SATA 7Pin+15Pin), SATA Connectors, one SATA connectors are provided, with transfer
speed up to 3.0Gb/s.
13. SD1:
(SD card socket),Secure Digital Memory Card socket.
14. LINE_OUT:
APC-3x93P_R (SBC-7106) User Manual
19
(Diameter 3.5mm Jack), HD Audio port, An onboard Realtek ALC662 codec is used to
provide high quality audio I/O ports. Line Out can be connected to a headphone or
amplifier.
15. USB45:
USB4/USB5：(Double stack USB type A), Rear USB connector, it provides up to 4
USB2.0 ports, High-speed USB 2.0 allows data transfers up to480 Mb/s ,support USB
full-speed and low-speed signaling.
Each USB Type A Receptacle (2 Ports) Current limited value is 1.5A.
If the external USB device current exceeds 1.5A, please separate connectors
into different Receptacle.
16. LAN1/LAN2:
LAN1/LAN2: (RJ45 Connector), Rear LAN port, Two standard 10/100/1000M RJ-45
Ethernet ports are provided. Used Realtek RTL8111E chipset, LINK LED (green) and
ACTIVE LED (yellow) respectively located at the left-hand and right-hand side of the
Ethernet port indicate the activity and transmission state of LAN.
17. BUZ1:
Onboard buzzer.
18. LED1:
LED STATUS. Green LED for Motherboard Power status.
19. LED2:
LED STATUS. Green LED for Motherboard Standby Power Good status.
APC-3x93P_R (SBC-7106) User Manual
20
20. CN3:
Function
Signal Name
Pin#
Pin#
Signal Name
Function
5V_S5_USB
1 2 5V_S5_USB
5V_S5_USB
3 4 5V_S5_USB
USB23_OC
5 6 CLKREQPSON_ATX-
USB2
USB2_N
7 8 USB2_P
USB2
USB3
USB3_N
9
10
USB3_P
USB3 Ground
11
12
Ground
PS/2 MS
PS2_MSCLK
13
14
PS2_MSDATA
PS/2 MS
PS/2 KB
PS2_KBCLK
15
16
PS2_KBDATA
PS/2 KB
COM6
(UART)
COM6_RI
17
18
COM6_DCD-
COM6
(UART)
COM6_TXD
19
20
COM6_RXD
COM6_DTR
21
22
RICOM6_RTS-
COM6_DSR
23
24
COM6_CTS-
Ground
25
26
Ground
COM5
(UART)
COM5_RI
27
28
COM5_DCD-
COM5
(UART)
COM5_TXD
29
30
COM5_RXD
COM5_DTR
31
32
DSRCOM5_RTS-
COM5_DSR
33
34
DTRCOM5_CTS-
GPIO24
ICH_GPIO24
35
36
ICH_GPIO13
GPIO13
GPIO26
ICH_GPIO26
37
38
ICH_GPIO27
GPIO27
Ground
39
40
Ground
PCIE
PE1_TX_N0
41
42
PE1_TX_P0
PCIE
PE1_RX_N0
43
44
PE1_RX_P0
Ground
45
46
Ground
CLK_100M_PE1_N
47
48
CLK_100M_PE1_P
PM_PCIE_WAKE
49
50
PLTRST_BUF-
SMBUS
SMB_CLK_S5
51
52
SMB_DATA_S5
SMBUS
PCIE
PE1_CLKREQ
53
54
Ground
PCIE
3P3V_S5
55
56
3P3V_S5
3P3V_S5
57
58
3P3V_S5
12V
12V_S0
59
60
12V_S0
12V
(1.27mm Pitch 2X30 Pin Header), For expand output connector, It provides four GPIO,
Two USB 2.0,one PS/2 mouse，one PS/2 keyboard,two uart,one PCIe x1,one SMbus.
APC-3x93P_R (SBC-7106) User Manual
21
Chapter 3 BIOS Setup
3.1 Operations after POST Screen
After CMOS discharge or BIOS flashing operation,.Press [Delete] key to enter CMOS Setup.
After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows
and includes basic information on BIOS, CPU, memory, and storage devices.
3.2 BIOS Setup Utility
Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system
summary information will appear.
APC-3x93P_R (SBC-7106) User Manual
22
3.3 Main Settings
APC-3x93P_R (SBC-7106) User Manual
23
System Time
Set the system time, the time format is :
Hour:
0 to 23
Minute:
0 to 59
Second
0 to 59
System Date
Set the system date, the date format is:
Day:
Note that the ‘Day’ automatically changes when you set the date.
Month:
01 to 12
Date:
01 to 31
Year:
1998 to 2099
3.4 Advanced Settings
3.4.1 PCI Subsystem Settings
PCI Bus Driver Versio V2.05.02
PCI Common Settings:
APC-3x93P_R (SBC-7106) User Manual
24
PCI Latency Timer:
[32 PCI Bus Clocks]
[64 PCI Bus Clocks]
[96 PCI Bus Clocks]
[128 PCI Bus Clocks]
[160 PCI Bus Clocks]
[192 PCI Bus Clocks]
[224 PCI Bus Clocks]
[248 PCI Bus Clocks]
VGA Palette Snoop:
[Disabled]
[Enabled]
PERR# Generation:
[Disabled]
[Enabled]
SERR# Generation:
[Disabled]
[Enabled]
3.4.2 ACPI Settings
Enable ACPI Auto Conf:
[Disabled]
[Enabled]
Enable Hibernation:
[Enabled]
[Disabled]
ACPI Sleep State:
[Both S1 and S3 available for OS to choose from ]
[Suspend Disabled]
[S1 only(CPU Stop Clock) ]
[S3 only (Suspend to RAM) ]
Lock Legacy Resources:
[Disabled]
[Enabled]
APC-3x93P_R (SBC-7106) User Manual
Loading...
