CF SERIES
Cylindrical EMI Suppression Ferrites
Suppressors
API's Cylindrical EMI Suppression ferrites provide a cost effective means of reducing common and differential mode EMI. Used to suppress common mode EMI on the internal and external cable assemblies of electronic equipment. Select a ferrite with an inner diameter most closely matching the outer diameter of the wires to be filtered.
Features
• Wide range of sizes with inner diameters from 1.5 mm (0.059 inches) to 23 mm (0.905 inches)
• Precision formed smooth surfaces prevent damage to wire insulation
• Available in API-1 and API-2 material.
• Custom designs available
Applications
• Internal and external computer data and power cables.
**Note – Impedance Testing Impedance is typical, measurement using HP4191A. For CF1-4*1.5*10 through CF2-4.6*1.85*6, based on 1⁄2 turn (4.0") 32 AWG wire. For CF1-7.35*5.1*10 and above, based on 1⁄2 turn (4.0") 19 AWG wire.
PART NUMBER
CF1-4*1.5*10 CF2-4*1.5*10 CF1-4*2*10 CF2-4*2*10 CF1-4.6*1.85*6 CF2-4.6*1.85*6 CF1-7.35*5.1*10 CF2-7.35*5.1*10 CF1-9.5*4.8*20 CF2-9.5*4.8*20 CF1-10.5*5.5*20 CF2-10.5*5.5*20 CF1-12*7.3*15 CF2-12*7.3*15 CF1-14.2*6.35*28.5 CF2-14.2*6.35*28.5 CF1-16*9*17 CF2-16*9*17 CF1-17.5*9.5*28.5 CF2-17.5*9.5*28.5 CF1-21*13.2*21 CF2-21*13.2*21 CF1-26*13*28.5 CF2-26*13*28.5 CF1-28*15.6*7.5 CF2-28*15.6*7.5 CF1-31*19*10 CF2-31*19*10 CF1-36*23*15 CF2-36*23*15
IMPEDANCE**
@ 25
MHz
(Min.)
50 55 40 40 35 35 23 23 70 80 65 70 40
40 115 125
50
55
95
95
55
55 100 110
28
28
30
30
40
40
@ 100
MHz
(Typ.)
135 116 102
86 89 77 68
63 171 142 161 134 107
89 280 230 130 109 217 172 136 115 235 198
85
76
91
83 113 101
MHz
(Typ.)
300 269 282 255 261 237 217 214 263 251 273 261 273 242 302 210 281 257 310 296 309 305 325 316 313 286 232 320 384 369
DIMENSION A
INCHES mm
0.157±.007
0.157±.007
0.157±.007
0.157±.007
0.181±.007
0.181±.007
0.289±.011
0.289±.011
0.374±.011
0.374±.011
0.413±.015
0.413±.015
0.472±.019
0.472±.019
0.559±.019
0.559±.019
0.629±.019
0.629±.019
0.688±.023
0.688±.023
0.826±.023
0.826±.023
1.023±.027
1.023±.027
1.102±.031
1.102±.031
1.220±.031
1.220±.031
1.417±.031
1.417±.031
4.0±0.2
4.0±0.2
4.0±0.2
4.0±0.2
4.6±0.2
4.6±0.2
7.35±0.3
7.35±0.3
9.5±0.3
9.5±0.3
10.5±0.4
10.5±0.4
12.0±0.5
12.0±0.5
14.2±0.5
14.2±0.5
16.0±0.5
16.0±0.5
17.5±0.6
17.5±0.6
21.0±0.6
21.0±0.6
26.0±0.7
26.0±0.7
28.0±0.8
28.0±0.8
31.0±0.8
31.0±0.8
36.0±0.8
36.0±0.8
DIMENSION B
INCHES mm
0.059±.005
0.059±.005
0.078±.007
0.078±.007
0.072±.007
0.072±.007
0.200±.007
0.200±.007
0.188±.007
0.188±.007
0.216±.007
0.216±.007
0.287±.011
0.287±.011
0.250±.011
0.250±.011
0.354±.011
0.354±.011
0.374±.011
0.374±.011
0.519±.019
0.519±.019
0.511±.019
0.511±.019
0.614±.019
0.614±.019
0.748±.023
0.748±.023
0.905±.023
0.905±.023
1.5±0.15
1.5±0.15
2.0±0.2
2.0±0.2
1.85±0.2
1.85±0.2
5.1±0.2
5.1±0.2
4.8±0.2
4.8±0.2
5.5±0.2
5.5±0.2
7.3±0.3
7.3±0.3
6.35±0.3
6.35±0.3
9.0±0.3
9.0±0.3
9.5±0.3
9.5±0.3
13.2±0.5
13.2±0.5
13.0±0.5
13.0±0.5
15.6±0.5
15.6±0.5
19.0±0.6
19.0±0.6
23.0±0.6
23.0±0.6
DIMENSION C
INCHES mm@ 300
0.393±.015
0.393±.015
0.393±.015
0.393±.015
0.236±.011
0.236±.011
0.393±.015
0.393±.015
0.787±.023
0.787±.023
0.787±.023
0.787±.023
0.590±.019
0.590±.019
1.122±.031
1.122±.031
0.669±.023
0.669±.023
1.122±.031
1.122±.031
0.826±.023
0.826±.023
1.122±.031
1.122±.031
0.295±.011
0.295±.011
0.393±.015
0.393±.015
0.590±.019
0.590±.019
10.0±0.4
10.0±0.4
10.0±0.4
10.0±0.4
6.0±0.3
6.0±0.3
10.0±0.4
10.0±0.4
20.0±0.6
20.0±0.6
20.0±0.6
20.0±0.6
15.0±0.5
15.0±0.5
28.5±0.8
28.5±0.8
17.0±0.6
17.0±0.6
28.5±0.8
28.5±0.8
21.0±0.6
21.0±0.6
28.5±0.8
28.5±0.8
7.50±0.3
7.50±0.3
10.0±0.4
10.0±0.4
15.0±0.5
15.0±0.5
