Advanced Power
Electronics Corp.

Micropower Ultra-Sensitive Hall Effect Switch

FEATURES

Battery Operation from 2.4V to 5.5V
Chopper Stabilized Technology
Micro Power Operation for Battery Applications
Operation with North or South Pole

High Sensitivity and High Stability of the

Magnetic Switching Points

Small RoHS-compliant, halogen-free

SOT-23 or TSOT-23 packages

APE9101/A-HF-3

DESCRIPTION

The APE9101/A-HF-3 is a three-terminal Hall Effect

sensor device with an output driver, mainly designed

for battery operated hand-held equipment (such as

cellular and cordless phones, PDAs). After power-on,

the APE9101/A-HF-3 will detect and setup the operating

pole (North or South) to avoid another side magnetic

noise. (Patent pending). For the APE9101-HF-3, the

output will be turned off in the absence of a magnetic field.

While the magnetic flux density B is larger than the

operating point, Bop, the output will be turned on. The

output remains latched on until the flux density B drops

below the release point, Brp.

Typical Application

OUTPUT

3

APE9101/A

Ordering information

50kΩ

2

1

+

2.4~5.5V

-

2

2

APE9101XX-HF-3TR

Output

Blank: Pull High

A: Pull Low

Sensor Location

1.45mm

0.8mm

(Top view)

Packing Type:

Package Type:

N : SOT-23 TN : TSOT-23

TR: Tape and reel

Example:

APE9101ATN-HF-3TR : output pull low, in RoHS-compliant, halogen-free TSOT-23, shipped on tape and reel (3000 pcs/reel).

©2012 Advanced Power Electronics Corp. USA

www.a-powerusa.com

201001145-3

1/6

Advanced Power

-

-

-

-

-

Electronics Corp.

Absolute Maximum Ratings (at T

Supply Voltage Pin (VDD) --------------------------------

Output Voltage Pin(V

Output Current Pin (I

Power Dissipation(P

Storage Temperature Range(T

Operating Temperature Range(T

Junction Temperature(T

Thermal Resistance from Junction to Ambient(RthJA)

Note. RthJA is measured with the PCB copper area of approximately 1 in2(Multi-layer).

) --------------------------------

OUT

) --------------------------------

OUT

) ------------------------------------

D

) --------------------- -65°C To 150°C

ST

) ------------------ -40°C To 85°C

OP

) -------------------------------

J

= 25°C)

A

-0.3 to 6V

-0.3 to 6V

2mA

230mW

125°C

550°C/W

APE9101/A-HF-3

Electrical Specifications

(VDD=2.75V, TA=25°C, unless otherwise specified)

Parameter SYM TEST CONDITION MIN TYP MAX

Supply Voltage V

DD

Awake State - 2 4 mA

Input Current

Sleep State - 7 12 uA

Average - 9 16 uA

Output Saturation Voltage V

Output Leakage Current I

Output Wake-Up Time T

Period T

OSAT

O-LEAK

wake-up

Period

IO=1mA - 0.1 0.3 V

VOUT=5.5V, B<Brp - 0.01 1 uA

Duty Cycle - 0.1 - %

North or South Pole Detection and
Setup Time

T

Set

Continuous >B

OPS

or <B

OPN

2.4 - 5.5 V

- 70 120 us

- 70 120 ms

- 210 400

UNITS

ms

THIS PRODUCT IS SENSITIVE TO ELECTROSTATIC DISCHARGE, PLEASE HANDLE WITH CAUTION.

USE OF THIS PRODUCT AS A CRITICAL COMPONENT IN LIFE SUPPORT OR OTHER SIMILAR SYSTEMS IS NOT AUTHORIZED.

APEC DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED

HEREIN; NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.

APEC RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN TO IMPROVE

RELIABILITY, FUNCTION OR DESIGN.

©2012 Advanced Power Electronics Corp. USA

www.a-powerusa.com

2/6

Advanced Power
Electronics Corp.

Pin Assignment

Pin Functional Descriptions

APE9101/A

1

V

DD

(SOT-23/TSOT-23)

(TOP VIEW )

PIN SYMBOL PIN DESCRIPTION

VDD

GND

OUTPUT

GND

2

2

3

V

OUT

Power Input Pin

Ground

APE9101

B>Bops or B<Bopn, Output is Low.

B<Brps or B> Brpn, Output is High.

APE9101A

B>Bops or B<Bopn, Output is High.

B<Brps or B> Brpn, Output is Low.

APE9101/A-HF-3

Magnetic Characteristics

(VDD = 2.75V, TA=25°C, unless otherwise specified)

Parameter SYM TEST CONDITION MIN TYP MAX

Operating Points

Release Points

Hysteresis B

Low State

Vout

0

Vout

0

Brps Bops

High State

Brps Bops

1.APE9101

High State

N

2.APE9101A

N

B

B

B

Low State

OPS

OPN

B

RPS

RPN

hys

Vout

High State

or

B

S

Low State

Bopn Brpn

N

0

Vout

High State

or

B

S

Bopn Brpn

N

Low State

0

-3555

-55 -35 -

10 25 -

- -25 -10

-10-

B

S

B

S

UNITS

Gauss

©2012 Advanced Power Electronics Corp. USA

www.a-powerusa.com

3/6
