NEW APC Smart-UPS
Advanced line interactiv e power protection for
servers and network equipment.
>
The world’s most popular
network and server UPS.
Award-winning Smart-UPS® protects critical
data by supplying reliable, network-grade
power in either traditional tower or rackoptimized convertible form factor.. Included
PowerChute® management software
provides IT administrators the comfort of
safe system shutdown and advanced UPS
management.
®
Reliable
Intelligent
Efficient
Manageable
APC Smart-UPS®
Applicat io n optimized standard mo d els id eal f or server s, storage,
point of sale and other network dev ices.
Tower and Rackmount 750-3000VA
1
1
6
5
6
5
5
8
7
6
Standard features:
Alpha/numeric LCD Display
1
Intuitive interface provides detailed and accurate information with
ability to configure locally.
Advanced battery management
4
Temperature compensated
charging extends life and
advanced algorithms recommend
replacement date.
Battery disconnect
7
Convenient way to disconnect
battery for transport
High Efficiency Green Mode
2
optimum efficiency which
saves utility and cooling costs
Communication Ports
5
Serial, USB and Smart-slot
for accessory cards
Emergency Power Off
8
(EPO)
Provides for remote UPS
shutoff in the event of a fire or
other emergency.
Network Grade Power
3
Conditioning
Extended range automatic
voltage regulation (AVR), noise
filtering and surge protection.
Switched Outlet Group
6
Reboot hung devices, shed
non-critical loads to conserv e
runtime, sequenced startup/turn off.
APC Smart-UPS® Display
Intuitive, easy to use LCD interface.
On all SMT and SMX models.
1
2
LCD Display Screen
Clear, consistent and detailed infor mation
in your choice of basic or advanced
menus.
Power Status:
•Operating mode and efficiency
•Load VA/Watt s/Amps
•Input/Output Volt age and frequency
•Battery capacity and runtime
•Energy meter and more
Control:
•UPS and outlet group settings
1
Configuration:
•Language
•Power quality setting
•Sensitivity
3
5
4
3
4
Escape
Exits to the previous menu or
screen.
Return
Used to enter or confirm
settings.
•Voltage transfer points
•Alarm, delay and threshold settings
Test and diagnostics:
•Initiate battery and runtime calibration tests
Logs:
•
See explanation of las t ten t ransfers and faults
About:
•UPS and replacement battery part numbers
•Serial numbers
•
Battery install and suggested replacement
dates
2
Quick Status Indicators
Online, on battery, fault and
replace battery Leds for quick
status identification.
Navigation arrows
5
Allows quick adjustment of
settings.
Standard T ower models
Product feature SMT750I SMT1000I SMT1500I SMT2200I SMT3000I
Output
Power Capacity 500W/750VA 670W/1000VA 980W/1500VA 1980W/2200VA 2700W/3000VA
Nominal Output Voltage 230V
Output Frequency 47-53 Hz for 50 Hz nominal; 57-63Hz for 60 Hz nominal
Wave Form Type Sine wave
Output Connections (6) IEC320 C13
Input
Nominal Input Voltage 230V
Input Voltage Range for main
operations (Max adjustable range)
Input Frequency 50/60 Hz +/-3 Hz (auto sensing)
Input Connection IEC320 C14
Batteries and Runtime
Battery Type Maintenance-free seal ed lead-acid batt ery with suspended elec trolyte, leak proof
Typical Backup Time at 1/2 Load (min) 16 min 21 min 24 min 24 min 14 min
(8) IEC320 C 13 (8) IEC320 C13 & (1) IEC320 C19
Outlets arranged in two groups of which one is controllable
160-285V (151-302V)
IEC-320 C 20, Sc huk o CE E 7 / EU1-
16P, British BS1363A
Typical Backup Time at full Load (min) 5 min 6 min 7 min 7 min 6 min
Replacement Battery RBC48 RBC6 RBC7 RBC55
Communication and Management
Interface Ports Serial (RJ45), USB and Smart-Slot
Control Panel and audible alarms
Emergency Power off (EPO) Optional Yes
Alpha-numeric LCD display with LED status indicators; alarm on battery, distincti ve low battery
alarm and configurable delays
Surge Protection and Filtering
Surge Energy Rating 540J 459J 459J 365J
Filtering
Full time multi-pole noise filtering: 0.3% IEEE surge let-through,
zero clamping response time, meets UL1449
Physical
Maximum Height cm (in) 16.1cm (6.3 in) 21.9 cm (8.6 in) 21.9 cm (8.6 in) 43.5 cm (17.1 in)
Maximum W idth cm (in) 13.8 cm(5.4 in) 17.1 cm (6.7 in) 17.1 cm (6.7 in) 19.7 cm (7.8 in)
Maximum Depth cm (in) 36.3 cm(14.3 in) 43.9 cm (17.3 in) 43.9 cm (17.3 in) 54.4 cm (21.4 in)
Net Weight kg (lbs) 13.2 kg (29 lbs) 18.86 kg (42 lbs) 24.1 kg (53 lbs) 48.8 kg (108 lbs) 52.5 kg (116 lbs)
Conformance
Regulatory C-tick, CE, EN 50091-1, EN 50091-2, VDE
Warranty 3 years electronics, 2 years battery
Standard Rackmount models
Product feature SMT750RMI2U SMT1000RMI2U SMT1500RMI2U SMT2200RMI2U SMT3000RMI2U
Output
Power Capacity 525W/750VA 700W/1000VA 1050W/1500VA 1980W/2200VA 2700W/3000VA
Nominal Output Voltage 230V
Output Frequency 47-53 Hz for 50 Hz nominal; 57-63Hz for 60 Hz nominal
Wave Form Type Sine wave
Output Connections
(Note: Outlets arranged in two groups of
which one is controllable)
(4) IEC320 C13
Input
Nominal Input Voltage 230V
Input Voltage Range for main
operations (Max adjustable range)
Input Frequency 50/60 Hz +/-3 Hz (auto sensing)
Input Connection IEC320 C14 IEC320 C20
160-286V (150-300V)
Batteries and Runtime
Battery Type Maintenance-free seal ed lead-acid batt ery with suspended elec trolyte, leak proof
Typical Backup Time at 1/2 Load
(min)
Typical Backup Time at full Load
(min)
Replacement Battery APCRBC123 APCRBC132 APCRBC133 RBC43
16.0 min 31.3 m i n 25.8 min 10.1 m in 11.7 min
5.5 min 8.7 min 7.2 min 5.2 min 3.4 min
Communication and Management
Interface Ports Serial (RJ45), USB and Smart-Slot
Control Panel and audible alarms
Emergency Power off (EPO) Optional Yes
Alpha-numeric LCD display with LED status indicators; alarm on battery, distincti ve low battery alarm and
configurable delays
(8) IEC320 C13
(1) IEC320 C19
Surge Protection and Filtering
Surge Energy Rating 459 J 480 J
Filtering Full time multi-pole noise filtering: 0.3% IEEE surge let-through, zero clamping response time, meets UL1449
Physical
Maximum Height (in) 8.9 cm (3.5 in) 8.9 c m (3.5 in) 8.9 cm (3.5 in) 8.6 cm (3.39 in) 8.6 cm (3.39 in)
Maximum Width (in) 43.2 cm (17 in) 43.2 cm (17 in) 43.2 cm (17 in) 48 cm (18.9 in) 48 cm (18.9 in)
Maximum Depth (in) 40.6 cm(16 in) 45.7 cm (18 in) 45.7 cm (18 in) 68.3 cm (26.9 in) 68.3 cm (26.9 in)
Net Weight 17.27 kg (38 lbs) 28.18 kg (62 lbs) 28.64 k g (63 lbs ) 42.31 kg (93 lbs) 44.28 kg (97.4 lbs)
Conformance
Regulatory C-tick, CE, EN 50091-1, EN 50091-2, GOST, TUV, VDE
Warranty 3 years electronics, 2 years battery
C-tick, CE, EN 60950, EN/IEC 62040-1-1,
EN/IEC 62040-2, GOST, GS Mark,
IRAM, VDE, WEEE
NEW APC Smart-UPS® Extended Run
Convertible extended run models ideal for critical
servers and voice/data switches.
Extended Run 750-3000VA
1
5
Additional feature s from
standard:
Slim 2U Rack/Tower
1
Convertible Form
Display rotates easily for use in
or out of a rack.
High Frequency Design
2
Reduces size of (or
eliminates) bulky
transformers making
installation even easier.
High Voltage Models
3
(2.2kVA and above)
Configurable output from
200-240 on high voltage
models.
6
Models available with Pre-
4
installed Network Cards
Models with “NC” suffix have
pre-installed AP9631 network
cards with temperature
monitoring.
Smart External Battery
7
4
4
5
7
6
5
Connector
Accept external batteries and
increases runtime
automatically to increase
availability
Switched Outlet Groups
6
Reboot hung devices, shed
non-critical loads to conserv e
runtime, sequenced startup/turn off.
Emergency Power Off
7
(EPO)
Provides for remote UPS
shutoff in the event of a fire or
other emergency.
Extended Run Rack/Tower Convertible models
Product feature SMX750I SMX1000I SMX1500RMI2U SMX2200RMHV2U SMX3000RMHV2U
Output
Power Capacity 500W/750VA 800W/1000VA 1200W/1500VA 1980W/2200VA 2700W/3000VA
Nominal Output Voltage 230V 200/208/220/230/240V
Output Frequency 47-53 Hz for 50 Hz nominal; 57-63Hz for 60 Hz nom inal
Wave Form Type Sine wave
Output Connections
(Switched groups)
(750 has 1 group, 1000 has 2 groups, 1500 has 3 groups)
Input
Nominal Input Voltage 230V 200-240V
Input Voltage Range for main
operations (Max adj. range)
Input Frequency 50/60 Hz +/-3 Hz (auto sensing)
Input Connection IEC320 C14 IEC320 C20
Batteries and Runtime
Battery Type Maintenance-free seal ed lead-acid batt ery with suspended elec trolyte, leak proof
Typical Backup Time at
½ Load (min)
Typical Backup Time at
Full Load (min)
Replacement Battery APCRBC116 APCRBC115 APCRBC117
External Battery Pack SMX48RMBP2U SMX120RMBP2U
Replacement Battery APCRBC115 APCRBC118
24 min 20 min 14 min 26 min 14 min
12 min 8 min 5 min 7 Min 5 min
Communication and Management
Interface Ports Serial (RJ45), USB and Smart-Slot
Control Panel and Alarms Alpha-numeric LCD display with LED status indicators; alarm on battery, distinctive l ow battery alarm and configurable delays
Emergency Power off (EPO) Yes
Surge Protection and Filtering
Surge Energy Rating 540J
Filtering Full time multi-pole noise filtering: 0.3% IEEE surge let-through, zero clamping response time, meets UL1449
Physical
Maximum Height (in) 8.9 cm (3.5 in) (2U)
Maximum Width (in) 43.2 cm (17 in)
Maximum Depth 49 cm (19 in) 66.7 cm (26.26 in)
Net Weight 20 Kg (48.5 lbs) 22. 9 k g (50.3 l bs) 24.8 kg (54.6 lbs) 37.3 kg (82.1 lbs)
Conformance
Regulatory C-tick, CE, EN 50091-1, EN 50091-2, VDE
Warranty 3 years electronics, 2 years battery
(8) IEC320 C13 outlets
160-286V (150-300V) 140-280V
(8) IEC320 C13 (1) IEC320 C19 outlets
(3 switched outlet groups)
C-tick, CE, CSA, EN 50091-1, EN 50091-2, FCC
Part 15 Class A, GOST, IEC60950, IRAM,
UL 1778, VDE
