APart CMS15T
IN-WALL SPEAKER
The APart CMS15T is a 100 V two-way square in-wall loudspeaker that
is loved by every interior designer for its beautiful shape, ease of
integration and perfect sound quality.
This loudspeaker has a 5.25” woofer and a 1” tweeter. It makes the
CMS15T very suitable for the distribution of background music and
microphone calls. The loudspeaker is easy to install thanks to its simple,
quick mounting system with 4 screws hidden behind the grill.
The housing is made of high quality ABS, the detachable grill is made
of aluminum, and the woofer is made out of enforced polypropylene 3 elements that make this speaker moisture proof!
CMS15T is standard in white color RAL9010. From 12 pieces on, the
loudspeakers can be painted optionally in any other RAL color (REF ;
PAINTCM)
TECHNICAL SPECIFICATIONS
Type : 2-way HiFi
Woofer : 5.25” Enforced Polypropylen
Tweeter : 1 “ Silk Dome
Rated Power RMS : 15 W @ 100Volt
Music Power RMS : 25 W @ 100Volt
Rated Power RMS : 35 W @ 16 ohm
Music Power RMS : 50 W @ 16 ohm
Impedance: 16 ohm
Transformer power taps: 2.5-5-10-15 Watt
Sound Pres. Level (SPL) 1W/1M : 90 dB
Frequency range : 60 Hz - 20 kHz
Dimensions outside : 171 mm x 171 mm
Dimensions Cutout : 145 mm x 145 mm
Mounting Depth : 61 mm
Weight : 1.1 Kg
