CM5EH
5.25" humidity proof budget
loudspeaker
TECHNICAL SPECIFICATIONS
outside diameter in mm
178
cutout in mm
163
woofer size in inch
5.25
mounting system
2 clamps
100V transformer power taps in
watts
6 - 3
low impedance dynamic power
in watts
15
max SPL 1m in dB
96
main construction material
ABS plastic
IP rating
54
applicable in 100V
yes
depth in mm
45
loudspeaker system
dual cone
woofer cone material
coated paper
colour
white
impedance in ohms
8
SPL 1W/1m in dB
89
frequency response in Hz
100 - 18K
grille main material
plastic
applicable low impedance
no
Net weight product in kg
0.47
The CM5EH is a humidity resistant new version of the
popular CM5E in-wall speaker and is suited for
bathrooms, kitchens, cool cells or other humid zones. In
principle, this product is pretty similar to the Apart CM5E
with exception to the cone and grille material. The
newest CM5EH version has a plastic grille whose outlook
will surprise you.
Most humidity resistant speakers have a somewhat
awkward appearance, but the CM5EH has the same
stylish design like the other Apart ceiling speakers. This
means the loudspeaker has a higher optical integration
and will keep consistency in buildings.
The loudspeaker is very easy to install, due to the simple
mounting system with 2 hidden spring loaded clamps.
You just need to open the clamps with your hands, carefully
slide the speaker in place and release the clamps while
positioning the speaker in the middle of the cut-out. This
easy way of installation doesn’t require any tools and saves
the installer precious time!
The CM5EH is a modern and very competitive built-in
loudspeaker, featuring a 100 Volt speaker line transformer
as well as a direct 8 ohms connection, allowing you to
connect up to 2 speakers in parallel per 4Ω stable
amplifier channel. For 100 Volt use, the CM5EH is equipped
with a high quality 3/6 Watt 100 Volt transformer.
