CM1008-BL
8" two-way loudspeaker black
TECHNICAL SPECIFICATIONS
outside diameter in mm
244
cutout in mm
223
woofer size in inch
8
tweeter size in inch
1
colour
white
low impedance dynamic power
in watts
100
max SPL 1m in dB
107
main construction material
ABS plastic
IP rating
54
applicable in 100V
no
Net weight product in kg
1.10
depth in mm
90
loudspeaker system
2-way
woofer cone material
polypropylene
mounting system
3 screws
impedance in ohms
8
SPL 1W/1m in dB
90
frequency response in Hz
50 - 20K
grille main material
aluminium
applicable low impedance
yes
Vertical dispersion angle 1000
Hz
180°
The Apart CM1008 two-way built-in low impedance
loudspeaker can be used with a standard hi-fi or
professional amplifier. It provides you with a powerful
transparent and warm sound that covers the complete
frequency band what makes this speaker suitable for the
distribution of music at a higher volume level.
The housing of CM1008 is made of high quality ABS. It has
a 1” tweeter and the 8” enforced woofer is made out of
polypropylene, what makes it moisture-proof (IP54). The
grille is made of aluminium what makes CM1008 suitable
to be used in humid environments.
The loudspeaker is easy to install, due to its simple, quick
mounting system with 3 screws.
These screws are hidden behind the loudspeaker grill, what
gives the loudspeaker a modern and striking design.
This loudspeaker is now updated with a new Quick Fix
connector for an even faster and easier installation.
The complete redesign of the CM Series is done according
to the corporate Apart identity. Apart blue speaker clamps
and product sticker, an Apart marked transformer and
loudspeaker basket.
The CM1008 loudspeakers can be painted in any colour.
www.apart-audio.com | info@apart-audio.com
CM1008-BL
MORE PICTURES
