SPARE PARTS CATALOGUE
ERSATZTEILKATALOG
CATALOGUE PIECES DETACHEES
CATALOGO PARTI RICAMBIO
CATALOGO DE PIEZAS DE RECAMBIO
CATALOGO PECAS DE REPOSICAO
,
,
ARC
08-06-2011
TA.01
ARC
Pagina
1
75050
PANNELLO SUP EST. TRAINO PG FINITO
PANEL, UPPER OUT. FOR RACK CONV.PG FINISHED
PLATTE, OB. AUSS. FÜR KORBTR.PG MASCHINENFERTIG
PANNEAU SUP EXT. AVANC. PG FINI
PANEL SUP EXT. ACCION. PG ACAB.
2
75035
FACCIATINA ESTERNA SUP. PIEGATO FINITO
FACHADA EXTERNA SUP PG ACAB.
3
75271
KIT MOLLE SPORTELLO GOLD80/RIVER150
KIT DOOR SPRINGS GOLD80/RIVER150
KIT TÜRFEDER GOLD80/RIVER150
KIT RESSORTS VOLET GOLD80/RIVER150
KIT MUELLES PUERTA GOLD80/RIVER150
4
75225
SCATOLA SUPPORTO MOLLE SPORT. PG FINITO
CAJA SOPORTE MUELLE PUERTA PG ACAB.
5
75053
PANNELLO LATERIALE TRAINO PG FINITO
SIDE PANEL
SEITENPANEEL
PANNEAU LATERAL
PANEL LAT TRAINO PG ACAB.
6
75654
PANNELLO ANTERIORE
FRONT PANEL
FRONTPANEEL
PANNEAU AVANT
PANEL DELANTERO
7
75039
PANNELLO ANG ANT DX PG FINITO
8
75040
PANNELLO ANGOLARE POSTERIORE DESTRO PIEGATO FINITO
BACK ANGLE RIGHT PANEL
PANEL ANG TRASERO DCHO. PG ACABADO
9
75082
SPORTELLO TRAINO COMPLETO
COMPLETE DOOR
KOMPLETTE TUER
PORTE COMPLETE
PUERTA ACCION. COMPLETA
10
926014
MAGNETE 8x16x40 + CUST.xDEM201
MAGNET 8x16x40 + CUST.xDEM201
MAGNET 8x16x40 + CUST.xDEM201
AIMANT 8x16x40 + CUST.xDEM201
IMAN 8x16x40 + CUST. xDEM201
11
75244
PANNELLO POSTER.SUP. TRAINO PG FINITO
BACK PANEL
RUECKWAND
PANNEAU POSTERIEUR
PANEL TRASERO SUP. ACCION. PG ACABADO
12
75041
PANNELLO ANG POST. SX PG FINITO
BACK PANEL
RUECKWAND
PANNEAU ANGLE POSTERIEUR
PANEL ANG TRASERO IZQDO. PG ACAB.
13
75035
FACCIATINA ESTERNA SUP. PIEGATO FINITO
FACHADA EXTERNA SUP PG ACAB.
14
75043
SOST=75080+75244
15
75053
PANNELLO LATERIALE TRAINO PG FINITO
SIDE PANEL
SEITENPANEEL
PANNEAU LATERAL
PANEL LAT TRAINO PG ACAB.
1
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
16
75038
PANNELLO ANGOLARE ANTERIORE SINISTRO PIEGATO FINITO
CORNER FRONT PANEL
RUECKWAND
PANNEAU ANGLE ANTERIEUR
PANEL ANG DELANT. IZQDO. PG ACAB.
17
926117
PIEDE REGOLABILE X CAPOTT.3LINEA
FOOT, ADJUST. X CAPOTT.3LINE
VERSTELLFUSS X HAUB.3LEIT.
PIED REGLABLE POUR CAPOT.3LIGNE
PATA REGULABLE X CAPOTA 3LINEA
18
75226
GANCIO MOLLA SPORTELLO TRAINO PG FINITO
SPRING HOOK
FEDER-HAKEN
CROCHAGE RESSORT
GANCHO MUELLE PUERTA ACCION. PG ACAB.
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
TA.02
1
3
4
2
5
6
2
9
1
8
3
18
19
25
7
10
14
13
15
16
26
11
13
12
17
28
29
33
34
24
20
32
37
22
22
23
21
36
40
35
27
29
30
28
31
24
ARC
38
39
41
43
42
Pagina
1
75581
SQ. SUPPORTO TENDINA PG FINITA
CURTAIN SUPPORTING BRACKET - FINISHED PART
BEFESTIGUNGSWINKEL FUER VORHANG - FERTIGTEIL
ÉQUERRE SUPPORT RIDEAU PG - ACHEVÉE
ESC. SOPORTE CORTINA PG ACABADA
2
75121
ASTA SOSTEGNO TENDINA TRAINO
ROD, SSUPPORT FOR CURTAIN
STAB, STÜTZE FÜR VORHANG
BARRE SUPPORT RIDEAU AVANCEMENT
VARA SOSTEN CORTINA ACCION.
3
75120
TENDINE ENTRATA/USCITA TRAINO
CURTAIN, INPUT/OUTPUT
VORHANG, EINTRITT/AUSTRITT
RIDEAUX ENTREE/SORTIE AVANCEMENT
CORTINAS ENTRADA/SALIDA ACCION.
4
75124
ASTA SOSTEGNO TENDINA INERMED. TRAINO
ROD, SUPPORT FOR INTERM. CURTAIN
STAB, STÜTZE FÜR MITTL.VORHANG
BARRE SUPPORT RIDEAU INTERMED. AVANCEMENT
VARA SOSTEN CORTINA INERMED. ACCION.
5
75123
TENDINA INTERMEDIA TRAINO
CURTAIN, INTERMEDIATE
ZWISCHENVORHANG
RIDEAU INTERM. AVANCEMENT
CORTINA INTERMEDIA ACCION.
6
927088
MAGNETE PER MICROINTERRUTTORE
MAGNET FOR MICROSWITCH
MAGNET FÜR MIKROSCHALTER
AIMANT POUR MINIRUPTEUR
IMAN PARA MICROINTERRUPTOR
7
75095
LEVA ECONOMIZZATORE/AUTOTIMER TRAINO
LEVER FOR ECONOMIZER/AUTOTIMER FOR RACK C.
HEBEL FÜR SPARREGLER/AUTOTIMER KORBTR.
LEVIER ECONOMISATEUR/AUTOTIMER AVANCEMENT
PALANCA ECONOMIZADOR/AUTOTIMER ACCION.
8
75069
CARRELLO TRAINO "GOLD80" COMPLETO
CARRIAGE FOR RACK-CONVEYOR "GOLD80" COMPL.
WAGEN FÜR KORBTR. "GOLD80" KOMPL.
CHARIOT AVANCEMENT TRAINO "GOLD80" COMPLET
CARRITO ACCION. "GOLD80" COMPLETO
9
75073
MANIGLIA COLLEGAMENTO TRAINO
HANDLE, RACK CONVEYOR CONNECTION
GRIFF, KORBTRANSPORTM.VERBIND.
POIGNEE CONNECTION AVANCEMENT
MANIJA CONEXION ACCION.
10
75070
TELAIO CARRELLO TRAINO PIEGATO FINITO
FRAME TRAILER
BASTIDOR CARRO ACCION. PG ACAB.VER 75068
11
486169
VITE NOX 4MAX10/4 TBCR-SP
SCREW, INOX 4MAX10/4 TBCR-SP
SCHRAUBE, INOX 4MAX10/4 TBCR-SP
VIS NOX 4MAX10/4 TBCR-SP
TORNILLO NOX 4MAX10/4 TBCR-SP
12
75075
PATTINO CARRELLO TRAINO
SLIDING BLOCK FOR RACK-CONVEYOR
KUFEN FÜR KORBTR.
PATINS PANIER AVANC.
PATIN CARRITO ACCION.
13
75071
SALTARELLO TRAINO
DRIVE CLICK
ABLAUFVERSCHLUSS
CLIQUET D'ARRET AVANCEMENT
TRINQUETE ACCION.
14
75077
BOCCOLA SALTARELLO
BUSH, PAWL
BUCHSE, ABLAUFVERSCHLUSS
BAGUE CLIQUET D'ARRET
CASQUILLO TRINQUETE
15
75076
TAMPONE FERMO TRAINO
BUFFER FOR DRIVE STOP
PUFFER, HALTEVORRICHTUNG FÜR KORBTRANSPORTAUT.
TAMPON ARRET AVANC.
TAMPON TOPE ACCION.
2
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
16
486078
VITE TC-CE M6X40 INOX
SCREW TC-CE M6X40 INOX
SCHRAUBE TC-CE M6X40 INOX
VIS TC-CE M6X40 INOX
TORNILLO TC-CE M6X40 INOX
17
75024
GUIDA CESTELLO TRAINO COMPLETA
COMPLETE RACK TRACK SLIDE
KOMPLETTE FUEHRUNGSSCHIENE FUER KORB-TRANSPORT
GLISSIÈRE PANIER COMPLETE POUR SYSTÈME TRACTION
GUIA CESTA ACCION. COMPLETA
18
75058
ROTELLA TRAINO
ROLLER FOR RACK CONVEYOR
ROLLE FÜR KORBTR.
ROULEAUX D'AVANC.
RUEDECILLA ACCION.
19
75231
PARASPRUZZI TRAINO
SPLASHGUARD FOR RACH-CONVEYOR
SPRITZBLECH FÜR KORBTR.
ANTIECLABOUSS. AVANCEM.
ANTI-SALPICADURAS ACCION.
20
75235
ALBERO MOTORE TRAINO COMPLETO
DRIVING SHAFT, COMPLETE
ANTRIEBSWELLE KOMPL.
ARBRE MOTEUR AVANCEMENT COMPLET
EJE MOTOR ACCION. COMPLETO
21
75141
BOCCOLA TRAINO SUPERIORE
BUSH, UPPER DRIVE
BUCHSE, OB. KORBTRANSPORTMASCHINE
BAGUE AVANCEMENT SUP.
CASQUILLO ACCION. SUPERIOR
22
75168
GUARNIZIONE FLANGIA ALBERO TRAINO
GASKET, FLANGE, DRIVE SHAFT
DICHTUNG, FLANSCH, ANTRIEBSWELLE
JOINT BRIDE ARBRE AVANCEMENT
JUNTA BRIDA EJE ACCION.
23
75057
BOCCOLA TRAINO INFERIORE
BUSH, LOWER DRIVE
BUCHSE, UNT. KORBTRANSPORTMASCHINE
BAGUE AVANCEMENT INF.
CASQUILLO ACCION. INFERIOR
24
80871
MICRO MAGNETICO
MAGNETIC DOOR SWITCH
TUERKONTAKTSCHALTER
CONTACTE MAGNETIQUE
CONTACTO MAGNETICO
25
75146
FILTRO RACCOLTA CON MANIGLIA TRAINO
FILTER, COLL. WITH RACK CONVEYOR HANDLE
FILTER, SAMML. MIT KORBTR.GRIFF
FILTRE RECOLTE AVEC POIGNEE AVANCEMENT
FILTRO RECOGIDA CON MANIJA ACCION.
26
75200
FILTRO PIANO TRAINO
FILTER, FOR RACK CONVEYOR TABLE
FILTER, FÜR KORBTR.TISCH
FILTRE PLAQUE AVANCEMENT
FILTRO SUPERF. ACCION.
28
472061
RONDELLA X GUIDA CESTO CL.3
WASHER, FOR BASKET GUIDE CL.3
UNTERLEGSCHEIBE, FÜR KORBFÜHRUNG KL.3
RONDELLE POUR GUIDE PANIER CL.3
ARANDELA X GUIA CESTA CL. 3
29
42092
GUIDA FILTRO ASPIRAZIONE U70
GUIDE, EXHAUST. FILTER U70
FÜHRUNG, ABSAUG.FILTER U70
GUIDE FILTRE ASPIRATION U70
GUIA FILTRO ASPIRACION U70
30
42089
FILTRO ASPIRAZIONE POMPA U70
FILTER, SUCTION FOR PUMP U70
FILTER, ABSAUG. FÜR PUMPE U70
FILTRE ASPIRATION POMPE U70
FILTRO ASPIRACION BOMBA U70
31
75262
TROPPOP INOX COMPL TRAINO
OVERFLOW, INOX COMPL.FOR HOOD-TYPE
ÜBERLAUF, INOX KOMPL.FÜR KORBTRANSP.
TROP-PLEIN INOX COMPL AVANCEMENT
REBOSE INOX COMPL ACCION.
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
32
143005
TUBO PRESS.TP 5x11 (CASER/15/NL C4N)
PIPE, PRESSURE SWITCH TP 5x11 (CASER/15/NL C4N)
ROHR, DRUCKSCHALTER TP 5x11 (CASER/15/NL C4N)
TUYAU PRESS.TP 5x11 (CASER/15/NL C4N)
TUBO PRES. TP 5x11 (CASER/15/NL C4N)
33
926049
PRESSOSTATO 761999 180-70
PRESSURE SWITCH 761999 180-70
DRUCKSCHALTER 761999 180-70
PRESSOSTAT 761999 180-70
PRESOSTATO 761999 180-70
34
984005
GRUPPO CAMPANA PRESSOST.35/40
PRESSURE SWITCH BELL 35/40
GLOCKE, DRUCKSCHALTER 35/40
ENS.BOITE PRESSOSTAT 35/40
GRUPO CAMPANA PRESOSTATO 35/40
35
42185
PILETTA COMPL.INOX 1"1/2 (01713007)
DRAIN, COMPL., INOX 1"1/2 (01713007)
ABFLUSS, KOMPL., INOX 1"1/2 (01713007)
TUYAU DE VIDANGE COMPL.INOX 1"1/2 (01713007)
PILETA COMPL. INOX 1"1/2 (01713007)
36
75142
BOCCOLA INFERIORE TRAINO
BUSH, LOWER RACK-CONVEYOR
BUCHSE, UNTEN KORBTR.
BAGUE INF. AVANCEMENT
CASQUILLO INFERIOR ACCION.
37
75217
STAFFA MOTORE TRAINO PG FINITO
38
927246
MICROINTERRUTTORE MS30+CALOTTA VFC03
MICROSWITCH, MS30+NUT VFC03
MIKROSCHALTER, MS30+MUTTER VFC03
MINIRUPTEUR MS30+ECROU VFC03
MICROINTERRUPTOR MS30+CAPERUZA VFC03
39
CMT13
MOLLA A COMPRESS D 20 L 100 FILO 2
SPRING, COMPRESSION D 20 L 100 WIRE 2
DRUCKFEDER D 20 L 100 DRAHT 2
RESSORT A COMPRESS D 20 L 100 FIL 2
MUELLE DE COMPRESION D 20 L 100 HILO 2
40
75218
STAFFA AZIONAMENTO MICRO TRAINO PIEGATO FINITO
BRACKET
TRAGBUEGEL
ENTRIER
SOPORTE ACTIV. MICRO ACCION. PG ACAB.
41
60354
VITE REGISTRO FRIZIONE ALFA
SCREW, ADJUSTING SCREW FOR FRICTION ALFA
JUSTIERSCHRAUBE FÜR KOPPLUNG ALFA
VIS REGISTRE FRICTION ALFA
TORNILLO REGISTRO FRICCION ALFA
42
927102
RIDUTTORE MVF-49A 1/60 160/220
RED.GEAR MVF-49A 1/60 160/220
REDUZIERST. MVF-49A 1/60 160/220
REDUCTEUR MVF-49A 1/60 160/220
REDUCTOR MVF-49A 1/60 160/220
43
927104
MOTORE 180W MEC71 B5 - 8POLI 230/400 160
MOTOR 180W MEC71 B5 - 8-POLES 230/400 160
MOTOR 180W MEC71 B5 - 8-POL. 230/400 160
MOTEUR 180W MEC71 B5 - 8POLES 230/400 160
MOTOR 180W MEC71 B5 - 8 POLOS 230/400 160
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
TA.03
2
1
8
3
13
9
10
11
(5x20F4A)
14
(5x20T2A)
4
15
20
(5x20T100mA)
12
21
5
6
7
2
17
18
19
BOILER
ARC
24
25
23
22
TANK
Pagina
1
75182
PANNELLO QUADRO ELETTRICO COMPLETO
2
80350
CONTAT 230-50/60HZ 3RT1016-1AP01
CONTACT, 230-50/60HZ 3RT1016-1AP01
KONTAKT, 230-50/60HZ 3RT1016-1AP01
CONTACT 230-50/60HZ 3RT1016-1AP01
VER CODIGO 229037
3
80351
CONTATTORE TRIPOLARE 40A
CONTACTOR TRIPOLAR 40A
SCHALTSCHÜTZ DREIPOL. 40A
CONTACTEUR TRIPOLAIRE 40A
CONTACTOR TRIPOLAR 40A
4
927038
PORTAFUSIBILE TRIPOLARE GK1-DF
FUSE-HOLDER TRIPOLAR GK1-DF
SICHERUNGSTRAGER DREIPOL. GK1-DF
PORTE-FUSIBLE TRIPOLAIRE GK1-DF
PORTA-FUSIBLE TRIPOLAR GK1-DF
5
DEI35
INT AUT 3X25A 07/1A 3RV1011-0JA10
AUTOM.SWITCH 3X25A 07/1A 3RV1011-0JA10
AUTOMATIKSCHALTER 3X25A 07/1A 3RV1011-0JA10
INTERRUPT. AUT 3X25A 07/1A 3RV1011-0JA10
INT AUT 3X25A 07/1A 3RV1011-0JA10
6
DEI40
INT AUT 3X25A 2,8/4A 3RV1011-1EA10
AUTOM.SWITCH 3X25A 2,8/4A 3RV1011-1EA10
AUTOMATIKSCHALTER 3X25A 2,8/4A 3RV1011-1EA10
INTERRUPT. AUT 3X25A 2,8/4A 3RV1011-1EA10
INT AUT 3X25A 2,8/4A 3RV1011-1EA10
7
77044
VENTILATORE QUADRO COMANDI
FAN
VENTILATEUR
8
927057
TERMOSTATO 3 CONTATTI 90/110øC TYPE LS1
THERMOSTAT, 3-CONTACT 90/110øC TYPE LS1
THERMOSTAT, 3-KONTAKTE 90/110øC TYP LS1
THERMOSTAT 3 CONTACTS 90/110øC TYPE LS1
TERMOSTATO 3 CONTACTOS 90/110ºC TIPO LS1
9
H.228048
* CHIUSURA PORTA-FUSIBILE
* CLAMPING FOR FUSE-HOLDER
* SICHERUNGSTRAGER-VERSCHLUSS
* COUVERTURE PORTE-FUSIBLE
* CIERRE PORTAFUSIBLE
10
228004
FUSIBILE 5X20 4A FAST
FUSE, 5X20 4A FAST
SICHERUNG, 5X20 4A FAST
FUSIBLE 5X20 4A FAST
FUSIBLE 5X20 4A FAST
11
H.228047
* PORTA-FUSIBILE
* FUSE-HOLDER
*SICHERUNGSTRAGER
* PORTE-FUSIBLE
* PORTAFUSIBLE
12
215032
SCHEDA ELETTRONICA GET50
MAIN BOARD
KARTE
CARTE ELECTRONIQUE
TARJETA CHORROS50 MICRO 644
13
228004
FUSIBILE 5X20 4A FAST
FUSE, 5X20 4A FAST
SICHERUNG, 5X20 4A FAST
FUSIBLE 5X20 4A FAST
FUSIBLE 5X20 4A FAST
14
228011
FUSIBILE 5X20 T2A
FUSE
SICHERUNG
FUSIBLE
FUSIBLE 5X20 T2A
15
228012
FUSIBILE 5X20 T160MA
FUSE
SICHERUNG
FUSIBLE
FUSIBLE 5X20 T160MA
3
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
17
929115
RELE 16A 230V 62.82
RELAY 16A 230V 62.82
RELAIS 16A 230V 62.82
RELAIS 16A 230V 62.82
RELE 16A 230V 62. 82
18
75983
MORSETTIERA 4POLI 600V
TERMINAL BOARD 4P 600V
KLEMMLEISTE 4P 600V
BORNIER 4P 600V
BORNERO 4POLOS(125A) 600V POTENCIA
19
231016
SONDA TEMPERATURA
TEMP. PROBE
KUGEL
SONDE
SONDA TEMPERATURA (AMPOLLA ACERO)
20
80934
CAVO FLAT COMANDI INFERIORI CAPOT
CABLE FLAT CAPOT
KABEL FLAT
CABLE LIAISON
CABLE FLAT MANDOS INFERIORES CAPOT
21
227083
SCHEDA COMANDI
BUTTON PAD
TASTENFELD
CLAVIER
BOTONERA GET50 MICRO 644
22
417119
DADO M3 PLASTICA BIANCO
NUT, M3 PLASTIC WHITE
SCHRAUBENMUTTER, M3 KUNST. WEISS
ECROU M3 PLASTIQUE BLANC
TUERCA M3 PLASTICO BLANCO
23
419036
SPACER
SPACER, M3
ABSTANDSSTÜCK, M3
ENTRETOISE M3
DISTANCIADOR M3
24
75790
POLIESTERE DIAMOND TRACTION LINE
POLIESTER GL82.84DIAMOND(TRACTION LINE)
25
75654
PANNELLO ANTERIORE
FRONT PANEL
FRONTPANEEL
PANNEAU AVANT
PANEL DELANTERO
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
TA.04
30
29
24
ARC
9,5
Pagina
1
144010
DISPOSIT.A/R.(EB) CON RACCORDO SFIATO
CHECK VALVE (EB) W/DRAIN UNION
RÜCKSCHLAGVORR.(EB) MIT ENTLÜFTUNG
DISPOSIT.A/R.(EB) AVEC RACCORD DE VIDANGE
DISPOSIT. A/R. (EB) CON EMPALME ALIVIAD.
2
75131
SQUADRA SUPERIORE FISSAGGIO BRACCIO RISCIACQUO PG. F.
BRACKET
BEF.WINKEL
EQUERRE
ESC SUP. FIJACION BRAZO ENJUAGUE PG.ACAB.
3
75115
BRACCIO SUPERIORE RISCIACQUO COMPLETO
UPPER ARM, COMPL.RINSE
OB. NACHSPÜLARM, KOMPL.
BRAS SUPERIEUR RINCAGE COMPLET
BRAZO SUPERIOR ENJUAGUE COMPLETO
4
75133
SPRUZZATORE RISCIACQUO INOX
SPRAYER, RINSE, INOX
SPRITZDÜSE, NACHSPÜLEN, INOX
GICLEUR RINCAGE INOX
ROCIADOR ENJUAGUE INOX
5
75401
RACCORDO BRACCIO RISCIACQUO TRAINO
UNION, RINSE ARM TRAINO
VERBINDUNGSST., NACHSPÜLARM KORBTR.
RACCORD BRAS RINCAGE AVANCEMENT
EMPALME BRAZO ENJUAGUE ACCION.
6
77904
PORTAGOMMA CURVO 3/8F
PIPE HOLDER
TUERE
PORTE-TUYAU
PORTAGOMA CURVO 3/8F(ART.GTL6446010C38)
7
143010
TUBO PRESS.TP 12X19.5
PIPE, PRESSURE SWITCH TP 12X19.5
ROHR, DRUCKSCHALTER TP 12X19.5
TUYAU PRESS.TP 12X19.5
TUBO PRES. TP 12X19. 5
8
H.882974-001
RACCORDO A "T" IN PLASTICA
EMPALME EN"T"(TS13) DE PLASTICO
9
75125
BRACCIO INFERIORE RISCIACQUO COMPLETO
LOWER ARM, RINSE COMPLETE
UNT. ARM, NACHSPÜLEN KOMPL.
BRAS INF. RINCAGE COMPLET
BRAZO INFERIOR ENJUAGUE COMPLETO
10
75129
SQ INF. FISSAGGIO BRACCIO RISCIACQ.PG.F
BRACK., LOWER FOR RINSE ARM FIX.PG.F
BEFESTIGUNGSWINKEL, UNT. FÜR NACHSPÜLARM PG.F
EQ. INF. FIXATION BRAS RINC.PG.F
ESC. INF. FIJACION BRAZO ENJUAGUE PG ACAB
11
927013
RACCORDO OT.3/8X12 SALDATO CROMATO
UNION, BRASS 3/8X12 WELDED CHROM.-PLATED
VERBINDUNGSST., MESSING 3/8X12 GESCHW. VERCHR.
RACCORD LAITON 3/8X12 SOUDE CHROME
EMPALME LAT. 3/8X12 SOLDADO CROMADO
12
929163
RACCORDO IN OTTONE 3/8M CURVO METANO
UNION, BRASS 3/8M BEND METHANE
VERBINDUNGSST., MESSING 3/8M GEBOG. ERDGAS
RACCORD EN LAITON 3/8M COURB METHANE
EMPALME LATON 3/8M CURVO METANO
13
929172
ELETTROVALV.3/4 DOPPIA 220V(341930)P16LT
SOLENOID VALVE 3/4 DOUBLE 220V(341930)P16LT
ELEKTROVENTIL 3/4 DOPPELT 220V(341930)P16LT
ELETTROVALV.3/4 DOUBLE 220V(341930)P16LT
ELECTROVALV. 3/4 DOBLE 220V(341930)P16LT
14
108006C
PORTAGOMMA
RUBBER PIPE HOLDER
SCHLUACHHALTER
PORTE-TUYAU CAOUTCHOUC
PORTAGOMA 90° SALIDA CALENTADOR CROMADO
15
75625
BOILER TRAINO COMPATTA(17LT.)
BOILER
CALENTADOR ACCION. COMPATTA(17LT.)
4
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
16
929163
RACCORDO IN OTTONE 3/8M CURVO METANO
UNION, BRASS 3/8M BEND METHANE
VERBINDUNGSST., MESSING 3/8M GEBOG. ERDGAS
RACCORD EN LAITON 3/8M COURB METHANE
EMPALME LATON 3/8M CURVO METANO
17
75998
MANOMETRO PER RIDUTTORE(0-2,5 BAR)
MANOMETER FOR RED.GEAR(0-2,5 BAR)
MANOMETER FÜR REDUZIERST.(0-2,5 BAR)
MANOMETRE POUR REDUCTEUR (0-2,5 BAR)
MANOMETRO PARA REDUCTOR(0-2,5 BAR)
18
927150
RIDUTTORE PRESSIONE 1/2"
RED.GEAR, PRESSURE 1/2"
DRUCKMINDERER 1/2"
REDUCTEUR PRESSION 1/2"
REDUCTOR PRESION 1/2"
19
927015
RACCORDO IN OTTONE 3/8 PORTAGOMMA D12
UNION, BRASS 3/8 RUBBER-HOLDER D12
VERBINDUNGSST., MESSING 3/8 SCHLAUCHTÜLLE D12
RACCORD EN LAITON 3/8 PORTE-CAOUTCHOUC D12
EMPALME LATON 3/8 EMPALME D12
20
75283
STAFFA SOSTEGNO RIDUTTORE PRESSIONE PG.F
BRACKET, SUPP. FOR PRESSURE REDUCER PG.F
BÜGEL, HALTER FÜR DRUCKMINDERER PG.F
ETRIER SUPPORT REDUCTEUR PRESSION PG.F
SOPORTE SOSTEN REDUCTOR PRESION PG. F
21
75245
COIBENTAZ BOILER GOLD80
BOILER INSULATION GOLD 80
BOILERISOLIERUNG GOLD 80
ISOLATION CHAUDIERE GOLD80
AISLAMIENTO CALENTADOR GOLD80
22
69870
PROTEZIONE RESISTENZA BOILER
BOILER HEATING ELEMENT PROTECTION
HEIZUNGSCHUETZ DES WARMWASSERBEREITERS
PROTECTION RESISTANCE BOILER
PROTECCION RESISTENCIA CALENTADOR
23
80398C
RESISTENZA B. 9500W 230V RIVER 82/83
RESISTANCE, B. 9500W 230V RIVER 82/83
WIDERSTAND, B. 9500W 230V RIVER 82/83
RESISTANCE CH. 9500W 230V RIVER 82/83
RESISTENCIA B. 9500W 230V RIVER 82/83
24
230083C
KIT RESISTENZA REB230083 (6KW)
KIT, RESISTANCE REB230083 (6KW)
KIT, WIDERSTAND REB230083 (6KW)
KIT RESISTANCE REB230083 (6KW)
KIT RESISTENCIA REB230083 (6KW)
25
926053
TAPPO/FLANGIA CIECA 170880543
CAP/FLANGE BLIND 170880543
PFROPFEN/FLANSCH BLIND 170880543
BOUCHON/BRIDE BORGNE 170880543
TAPON/BRIDA CIEGA 170880543
29
230020C
KIT RESISTENZA REB230020 (8KW)
KIT, RESISTANCE REB230020 (8KW)
KIT, WIDERSTAND REB230020 (8KW)
KIT RESISTANCE REB230020 (8KW)
KIT RESISTENCIA REB230020 (8KW)
30
75977
KIT
KIT
KIT
KIT
KIT REDUCTOR PRESION ACCION.
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
TA.05
2
4
2
5
6
3
1
2
3
1
7
9
8
11
10
12
ARC
Pagina
1
75155
RACCORDO LAVAGGIO ESTERNO TRAINO
UNION, WASH.OUTS. RACK CONVEYOR
VERBINDUNGSST., AUSS. SPÜL. KORBTR.
RACCORD LAVAGE EXTERIEUR AVANCEMENT
EMPALME LAVADO EXTERNO ACCION.
2
437050
GUARN.GOMITO PORTAGOMMA MOD 22
GASKET, ELBOW RUBBER-HOLDER MOD 22
DICHTUNG, KNIESTÜCK SCHLAUCHTÜLLE MOD 22
JOINT COUDE PORTE-CAOUTCHOUC MOD 22
JUNTA CODO EMPALME MOD 22
3
75154
MANICOTTO MANDTA LAVAGGIO TRAINO
SLEEVE, WASH. DELIVERY FOR RACK CONVEYOR
MUFFE, SPÜL.VERSORGUNG FÜR KORBTRANSPORTM.
MANCHON REFOUL. LAVAGE AVANCEMENT
MANGUITO IMPULSION LAVADO ACCION.
4
75169
ATTACCO LANCIA SUPERIORE COMPLETO
UNION, UPPER WASH-ARM ASSB.
VERBIND., OB. LANZE KOMPL.
FIXATION RAMPE SUP. COMPLETE
CONEXION LANZA SUPERIOR COMPLETA
5
75616
BRACCIO LAVAGGIO
WASH ARM
SPUELARM
BRAZO LAVADO (TUERCA 10,5X4MM)
6
75171
ATTACCO LANCIA INFERIORE COMPLETO
UNION, LOWER WASH-ARM ASSB.
VERBIND., UNT. LANZE KOMPL.
FIXATION RAMPE INF. COMPLETE
CONEXION LANZA INFERIOR COMPLETA
7
75165
TUBO MANDATA LAVAGGIO TRAINO
PIPE, DELIVERY PIPE FOR HOOD-TYPE WASHING
ZUFLUSSROHR FÜR SPÜLEN / KORBTRANSP.
TUYAU REFOULEMENT LAVAGE AVANCEMENT
TUBO IMPULSION LAVADO ACCION.
8
80187
MANICOTTO MANDATA POMPA RIVER 82/83
SLEEVE, PUMP DELIVERY RIVER 82/83
MUFFE, ZUFUHR PUMPE RIVER 82/83
MANCHON REFOUL. POMPE RIVER 82/83
MANGUITO IMPULSION BOMBA RIVER 82/83
9
75175
EL.P 1,1 KW 230/400-240/415 50 422512725
MOTORPUMP 1,1 KW 230/400-240/415 50 422512725
ELEKTROPUMPE 1,1 KW 230/400-240/415 50 422512725
EL.P 1,1 KW 230/400-240/415 50 422512725
ELECTROBOMBA 1,1 KW 230/400-240/415 50
10
926056
GOMITO GOMMA ASPIRAZIONE POMPA 120/140
ELBOW, RUBBER, EXHAUST. PUMP 120/140
KNIESTÜCK, GUMMI, ABSAUG.PUMPE 120/140
COUDE CAOUTCHOUC ASPIRATION POMPE 120/140
CODO GOMA ASPIRACION BOMBA 120/140
11
42028
TRONCHETTO ASPIRAZIONE
TRONCO ASPIRACION (EMBUTIDO)
12
929164
GOMITO IN GOMMA P2703 SAIAG
ELBOW, RUBBER P2703 SAIAG
KNIESTÜCK, GUMMI P2703 SAIAG
COUDE EN CAOUTCHOUC P2703 SAIAG
CODO DE GOMA P2703 SAIAG
5
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
TA.06
2
4
7
3
5
6
ARC
1
Pagina
1
75175
EL.P 1,1 KW 230/400-240/415 50 422512725
MOTORPUMP 1,1 KW 230/400-240/415 50 422512725
ELEKTROPUMPE 1,1 KW 230/400-240/415 50 422512725
EL.P 1,1 KW 230/400-240/415 50 422512725
ELECTROBOMBA 1,1 KW 230/400-240/415 50
2
335003
VENTOLA 1295/2277
FAN 1295/2277
GEBL. 1295/2277
VENT. 1295/2277
ROTOR 1295/2277
3
80880
FLANGIA PER ELETTROPOMPA 4225/2
ELECTROPUMP FLANGE 4225/2
FLANSCH FUER MOTOPOMPE 4225/2
BRIDE POUR MOTOPOMPE 4225/2
BRIDA EL.BOMBA 4225/2 (PM4225320)
4
141002
TENUTA MECCANICA ROTANTE D 12
SEAL, MECH., REVOLVING D 12
DICHTUNG, MECH., ROTIER. D 12
JOINT MECANIQUE PIVOTANT 12
SELLO MECANICO GIRAT. D 12
5
456023
OR FIR 1225-41-95
O-ring FIR 1225-41-95
O-Ring FIR 1225-41-95
OR FIR 1225-41-95
OR FIR 1225-41-95
6
80881
GIRANTE EL. POMPA (TIPO 422512725)
ELECTR.PUMP IMPELLER (TYPE 422512725)
LAUFRAD ELEKTROPUMPE (TYP 422512725)
ROUE ELECTROPOMPE (TYPE 422512725)
ROTOR ELECTROBOMBA (TIPO 422512725)
7
80882
CHIOCC EL.POMPA 4225/2 1295303/B C/TAPPO
6
\\192.168.20.12\Documentazione_tecnico_commerciale\Elettrobar\ESPLOSI-PDF UNIFICATI\Temp\GL280RU.pdf
Loading...
